10.5 Specifications

Electrical Connections
Power Requirements
Approvals
Physical Dimensions
Weight
Operating Temperature
Humidity
"This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
•
This device may not cause harmful interference
•
This device must accept any interference received, including interference that may cause undesired
operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his expense.
Modifications not expressly approved by FieldServer could void the user's authority to operate the
equipment under FCC rules."
1
Specifications subject to change without notice.
ProtoNode FPC-N64
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
Two Ethernet 10/100 BaseT ports
Input Voltage: 9-30VDC or 24VAC
Max Power: 3 Watts
CE and FCC Class B & C Part 15, UL 62368-1, WEEE compliant,
IC Canada, RoHS3 compliant, REACH compliant
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing

Figure 36: Specifications

ProtoNode Start-up Guide
Additional Information
1
Current draw: 24VAC 0.125A
9-30VDC 0.25A @12VDC
