10.7 Specifications

ProtoCarrier FPC-C34/C38/C40/C42
One 6-pin Phoenix connector with:
Port (+ / - / gnd) - see Interface Table below
Electrical
Power port (+ / - / Frame-gnd)
Connections One 3-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
FCC Part 15 certified, DNP 3.0 and Modbus conformance tested, BTL marked, WEEE compliant,
REACH compliant, RoHS compliant, UKCA and CE compliant, ODVA conformant
Approvals
CAN ICES-003
FPC-C42
(A)/ NMB-003(A)
CAN ICES-003
FPC-C34, FPC-C35, FPC-C38, FPC-C39, FPC-C40, FPC-C41, FPC-C43
(B)/ NMB-003(B)
Power
9-30VDC or 12-24VAC - see Section
Requirements
Physical
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
Dimensions
Weight 0.2 kg (0.4 lbs)
Operating
-20 to 70°C (-4 to 158°F)
Temperature
Surge
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Suppression
Humidity 5-90% RH (non-condensing)
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this equipment
may cause radio interference.
FPC-C34
FPC-C35
FPC-C38
FPC-C39
ProtoCarrier
FPC-C40
FPC-C41
FPC-C42
FPC-C43
1. Tx/Rx/GND
39
4 Power up the ProtoCarrier
NOTE: Specifications subject to change without notice.
RS-232 1 RS-485 2
1
1
2. +/-/Frame Ground
ProtoCarrier Start-up Guide
ProtoCarrier FPC-C35/C39/C41/C43
One 6-pin Phoenix connector with:
Port (+ / - / gnd) - see Interface Table below
Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port
LonMark Certified
Interface Connections
Ethernet 3
2 1
1 1
1 1
1
1 1
1
1 1
1
3. 10/100 BaseT
for power draw per model
LonWorks 4 KNX 2
1
1
1
1 1
1
4. FTT 10
M-Bus 2
1
1
