7.4

LED Functions

Tag
The SS LED will flash once a second to indicate that the bridge is in operation.
SS
The SYS ERR LED will go on solid indicating there is a system error. If this occurs, immediately report the related
ERR
"system error" shown in the error screen of the FS-GUI interface to support for evaluation.
PWR This is the power light and should always be steady green when the unit is powered.
The RX LED will flash when a message is received on the serial port on the 3-pin connector.
RX If the serial port is not used, this LED is non-operational. RX1 applies to the R1 connection while RX2 applies to
the R2 connection.
The TX LED will flash when a message is sent on the serial port on the 3-pin connector.
TX If the serial port is not used, this LED is non-operational. TX1 applies to the R1 connection while TX2 applies to
the R2 connection.
7.5

Factory Reset Instructions

For instructions on how to reset a FieldServer back to its factory released state, see
Recovery.
7.6

Internet Browser Software Support

The following web browsers are supported:
• Chrome Rev. 57 and higher
• Firefox Rev. 35 and higher
• Microsoft Edge Rev. 41 and higher
• Safari Rev. 3 and higher
NOTE: Internet Explorer is no longer supported as recommended by Microsoft.
NOTE: Computer and network firewalls must be opened for Port 80 to allow FieldServer GUI to function.
US
Description
Lochinvar ProtoNode FPC-N54 Guide
7 Troubleshooting
ENOTE FieldServer Next Gen
25
