Aplex ARMPAC-6 A Series User Manual

Industrial plastic chassis, fanless hmi, w/nxp i.mx8m+, 4xcortex-a53
Hide thumbs Also See for ARMPAC-6 A Series:
Table of Contents

Advertisement

Quick Links

Download this manual
ARMPAC-6XXA Series
Industrial Plastic Chassis, Fanless HMI, w/NXP® i.MX8M+, 4xCortex-A53
User Manual
Release Date
Revision
Dec. 2023
V1.0
®2023 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 URL: http://www.aplextec.com/zh/home.php

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARMPAC-6 A Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplex ARMPAC-6 A Series

Summary of Contents for Aplex ARMPAC-6 A Series

  • Page 1 Industrial Plastic Chassis, Fanless HMI, w/NXP® i.MX8M+, 4xCortex-A53 User Manual Release Date Revision Dec. 2023 V1.0 ®2023 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 URL: http://www.aplextec.com/zh/home.php...
  • Page 2 Revision History Reversion Date Description 2023/12/19 Official Version ARMPAC-6XXA Series User Manual...
  • Page 3 This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) ARMPAC-6XXA Series User Manual...

  • Page 5: Safety Precautions

    Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆ Prevent electric shock. Don‘t touch any components of this card when the card is power-on. Always disconnect power when the system is not in use.

  • Page 6: Table Of Contents

    Table of Contents Revision History…………………………………………………………………………………………………….1 Warning!.............…………………………….……………………2 Caution/Disclaimer…………………..………………………………………………………………………3 Packing List…………………………………….…………………………………………………....4 Safety Precautions………………………………….……………….…..……………………....5 Chapter 1 Getting Started 1.1 Features……..…………………..………………………...…………………………..6 1.2 Specifications…..………………...………………………………………………….6 1.3 Dimensions……..…………………..……………………………………………...8 1.4 Brief Description of ARMPAC-6XXA…..….…..…………………….……..9 1.5 VESA Mounting……………….…………..………..…...…………………..…..11 Chapter 2 Hardware 2.1 Motherboard Jumpers Setting and Connectors…………………...12 Chapter 3 Software images 3.1 Update Linux for ARMPAC-607B/610B………...……………………...18 3.2 Update Android Firmware….………....……………………...31...

  • Page 7: Getting Started

    Chapter 1 Getting Started 1.1 Features ⚫ ARM based HMI ⚫ Fanless design ⚫ Flat front panel touch screen ⚫ NXP® i.MX8M Plus Quad, w/4xCortex-A53 processor ⚫ Onboard 4GB LPDDR4 DRAM ⚫ Onboard 16GB/32GB eMMC Flash ⚫ DC 24V power input 1.2 Specifications ARMPAC-607A(P) ARMPAC-610A(P)
  • Page 8 CAN_L 485- 485- 485+ 485+ 1 x GbE Lan,RJ45 (LAN1),support optional PoE+(IEEE 802.3AT) PD via module (Model: Silvertel_AG5300) 1 x GbE Lan,RJ45 (LAN2) Power 1 x 24V DC power input via 1 x 3-pin terminal block Option Onboard Wifi/BT module 2.4GHz, 5.0 GHz IEEE 802.11 b/g/n/ac wireless Bluetooth 5.0, BLE RTC Battery...
  • Page 9 Backlight Lifetime 20,000 hrs 30,000 hrs Touch Screen – Projected Capacitive Type Interface Light Transmission 88±2% Power Power Input DC24V Connector Pitch 3.5mm 3pin Phoenix Connector Power MAX: 8.9W (607A) MAX: 10.29W (610A) Consumption Mechanical Front Bezel Metal Plastic/Panel Mount Rear Panel Metal Plastic/VESA 75 Plastic/VESA 75...

  • Page 10: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of ARMPAC-607A(P) Figure 1.2: Dimensions of ARMPAC-610A(P) ARMPAC-6XXA Series User Manual...

  • Page 11: Brief Description Of Armpac-6Xxa

    1.4 Brief Description of ARMPAC-6XXA ARMPAC-6A series have 7”, and 10.1” in fanless designed ARM based HMI, which comes with flat front panel LED backlight touch designed. They are powered by NXP® i.MX8M Plus Quad, 4x Cortex-A53 processor, 4GB LPDDR4 onboard memory, and 16GB eMMC or 32GB eMMC NAND flash onboard.
  • Page 12 Figure 1.3: Front View of ARMPAC-6XXA Series Figure 1.4: Rear View of ARMPAC-6XXA Series ARMPAC-6XXA Series User Manual...

  • Page 13: Vesa Mounting

    1.5 VESA Mounting The ARMPAC-6XXA series is designed to be VESA mounted as shown in Picture. Just carefully place the unit through the hole and tighten the given screws from the rear to secure the mounting. Figure 1.5: ARMPAC-6XXA Series VESA Mounting ARMPAC-6XXA Series User Manual...

  • Page 14: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Motherboard Introduction SBC-7132 is an industrial motherboard developed on the basis of NXP i.MX8M plus processor, which designed for Aplex standard system the ARMPAC-6A & ViTAM-6A series. 2.2 Motherboard Specifications SBC-7132_Industrial Motherboard Form Factor 3.5” ECX...
  • Page 15 1 x Pitch 3.5mm 2x5pin Terminal Block with ➢ 1 x RS232(RX,TX,RTS,CTS)/2W RS485(D+,D-),select via jumper ➢ 1 x 2W RS485(D+,D-) Serial Port & CAN bus ➢ 1 x CAN bus 2.0b(CAN_H,CAN_L) 1 x RS232 via 2x5pin header 1 x CAN via 1x4 wafer (CAN_H,CAN_L,GND,5V) (Optional) Line-in, mic-in, line-out via 2x6pin header Audio...
  • Page 16 2.3 Motherboard Dimensions Board Top Board Bottom ARMPAC-6XXA Series User Manual...
  • Page 17 2.4 Motherboard Jumpers and Connectors Location Board Top Board Bottom ARMPAC-6XXA Series User Manual...

  • Page 18: Motherboard Jumpers Setting And Connectors

    2.5 Motherboard Jumpers and Connectors 1. DC_IN1: (3.50mm Pitch Dinkle_ECH350RM-03P), For DC 24V system power input. Pin# Signals DC_IN- DC_IN+ 2. CN1: (USB type A), USB3.0/USB2.0 3. CN2: (1.25mm pitch Hirose_DF13-40DP-1.25V), Provides 18/24-bits dual channel LVDS, LCD backlight power and control, system LED and USB2.0 for touch screen. Function Signal Name Pin#...
  • Page 19 LB_D2_P LB_D2_N LB_D3_P LB_D3_N LB_CLKP LB_CLKN USB3 USB3 USB3_CN1_P USB3_CN1_N ERRLED+ PWR_LED+ *JP2 JP2 Pin# Function 1-2 Close LVDS_VCC=5V 2-3 Close LVDS_VCC=3.3V 4. INVT1: 5. CN3： (3.50mm pitch Dinkle_0221-2210THT), Provides 2xCOM(COM1:RS232/485,COM2:RS485) and 1xCAN Bus. ARMPAC-6XXA Series User Manual...
  • Page 20 Function Signal Name Pin# Pin# Signal Name Function CAN0_H COM1_CTS COM2* COM1* (JP5) CAN0_L COM1_RTS (JP3/JP4) CAN Bus 485- COM1_TX 485- 485+ COM1_RX 485+ *JP3 JP3 Pin# Function 1-2 Close COM1 Add Terminal *JP4 JP4 Pin# Function 1-3/2-4 COM1 RS232 Close 3-5/4-6 COM1 RS485...
  • Page 21 7. CN5： (2.00mm pitch 2x5pin header), Provides COM3 RS232. Signal Name Pin# Signal Name 8. CN6: (2.00mm pitch 2x5pin header), Provides 8-bits GPIO. Signal Name Pin# Signal Name GPIO1_IO00 GPIO1_IO12 GPIO1_IO01 GPIO1_IO13 GPIO1_IO05 GPIO1_IO14 GPIO1_IO06 GPIO1_IO15 9. CN1: (2.00mm pitch 4pin wafer), Provides 1xCAN Bus. Pin# Signal Name Pin1...
  • Page 22 *LAN1 supports PoE+ module Silvertel_AG5300 IEEE802.3at and IEEE802.3af compliant Maximum 30W peak output power 11. F_AUDIO1 (Optional): (2.00mm pitch 2x6 pin header), Provides line-in/line-out/mic-in. Signal Name Pin# Pin# Signal Name GND_AUD HP_OUTL HP_OUTR LINE_OUT_DET LINE_IN_L LINE_IN_R MIC_IN_L MIC_IN_R GND_AUD 12. SPKL1/SPKL2 (Optional): (2.00mm pitch 2 pin header), Provides up to 2x2W speakers out.
  • Page 23 15. M2_B1: (M.2 B-Key), With USB3.0/USB2.0 signals. Support 3042/3052 M.2 B- Key expansion cards. 16. SIM1: (Clam-shell type micro-SIM slot), Support micro SIM card for M2_B1. 17. M2_E1: (M.2 E-Key), With PCIe3.0x1/USB2.0 signals. Support 2230 M.2 E-Key expansion cards. 18. SD1: (Micro SD slot), Support SDXC.
  • Page 24 23. DEBUG1 : (1.25mm pitch 4pin wafer)),For console debug message only. Pin# Signal Name 3P3V_S0 UART0_TXD UART0_RXD ARMPAC-6XXA Series User Manual...

  • Page 25: Chapter 3 Software Images

    Chapter 3 Software images 3.1 ANDROID11 ARMPAC-6XXA Series User Manual...
  • Page 26 3.1.1. Android 11 Dual Ethernet Connect Check: 1. DHCP Dual Ethernet Connect Check: Settings => Network & Internet ➢ Note: When dual network ports are configured for DHCP connection under the Android 11 operating system, first network port (LAN1) will be used to connect to the external Internet.
  • Page 27 Ethernet AUX(LAN2) PC-2 pin Android 11 LAN2: ARMPAC-6XXA Series User Manual...
  • Page 28 2. Static IP Dual Ethernet Connect Check: Settings => Network & Internet Ethernet (LAN1) PC-1 pin Android 11 LAN1: Ethernet AUX (LAN2) ARMPAC-6XXA Series User Manual...
  • Page 29 PC-2 pin Android 11 LAN2: 3.2. Yocto Linux 4.0 (kirkstone) 1. System Login & Setup ➢ Press the “Setup” button to enter the setup login page. ➢ Default login username/password Username: root Password: rootroot ARMPAC-6XXA Series User Manual...
  • Page 30 ARMPAC-6XXA Series User Manual...
  • Page 31 ➢ While not in the Kiosk mode, press the “Apps” button on Chromium. 2. Brightness Setting ARMPAC-6XXA Series User Manual...
  • Page 32 ➢ Brightness can be set from 1~100% via slide bar or directly fill the value. ➢ Time to sleep mode can be set from 0~30mins or fill 0 to disable. 3. Date & Time Setting ➢ Date 、 time and time zone can be set manually, or can be synchronized automatically by connecting the NTP server.
  • Page 33 4. Login Password Setting ➢ Please note: 1. Password must contain at least eight characters 2. Password must contain at least one uppercase letter A-Z 3. Password must contain at least one lowercase letter a-z 4. Password must contain at least one numeric character 0-9 ARMPAC-6XXA Series User Manual...
  • Page 34 5. Homepage Setting ➢ Enter the URL you want to set as the homepage and press the “Apply” button. 6. Network Setting ARMPAC-6XXA Series User Manual...
  • Page 35 ➢ Network setting for LAN1(eth0) & LAN2(eth2). 7. Terminal Mode ARMPAC-6XXA Series User Manual...
  • Page 36 8. Screen Rotation ° ° ° ➢ Screen rotation for 90 /180 /270 ARMPAC-6XXA Series User Manual...
  • Page 37 9. Gesture Key for Exit Kiosk Mode ➢ While under Kiosk mode, touch the left down corner for 5 times to exit it. 10. System Information ARMPAC-6XXA Series User Manual...
  • Page 38 11. Return to Homepage ➢ Return to the homepage of user settings. ARMPAC-6XXA Series User Manual...
  • Page 39 12. Return to System Login & Setup ARMPAC-6XXA Series User Manual...
  • Page 40 13. SSH Login ➢ System also supports remote SSH login. 14. CAN Bus/COM Port/Touch Screen Test Tool ➢ COM port tool ARMPAC-6XXA Series User Manual...
  • Page 41 ➢ CANBus tool ➢ Touch screen draw test tool ARMPAC-6XXA Series User Manual...
  • Page 42 ARMPAC-6XXA Series User Manual...

This manual is also suitable for:

Armpac-607aArmpac-607apArmpac-610aArmpac-610ap
