  • Page 2 Stainless steel BOX PC for Hazardous Locations ATEX/IECEX/CID2 Certified BOX PC User Manual Release Date Revision May. 2018 V1.2 ®2018 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan URL: http://www.aplextec.com/zh/home.php...

  • Page 3: Revision History

    Revision History Reversion Date Description 2017/11/24 For Preliminary Release 2018/01/02 Official version 2018/03/27 Modify power pin defined 2018/05/16 Modify power pin description AEx-2410 User Manual...

  • Page 4: Warning!/Caution

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 5: Packing List

    Refer to the section titled "Markings" to get information about the permitted zones of protection and the types of protection. • AEx-2410 is installed in zones 2 hazardous areas must be certified and bear the marking. • Ensure with the marking that the terminals are compatible with the conditions permitted for the hazardous area at the site where it is being used.

  • Page 6: Safety Precautions

    Warning- Do not use USB while the circuit is live unless the area is known to be non-hazardous. Markings ATEX and markings, applied to the AEx-2410 Graphic Operator Interface, are as follows: AEx-2410 II 3G Ex nA IIC T4 Gc and CID2 IP66 Temperature <...

  • Page 7: Table Of Contents

    Packing List…………………………………….……………………………………………………………………..3 Safety Precautions…………………………………………………………………….…..……………………..4 Chapter 1 Getting Started 1.1 Features………………………..………………………...…………………………..7 1.2 Specifications…………………...………………………………………………….7 1.3 Dimensions………………………..…………………………………………..….9 1.4 Brief Description of AEx-2410……….……………………….……….…10 1.5 VESA mounting and Wall mounting………………….….……….……11 Chapter 2 Hardware 2.1 Motherboard Introduction……………………...……………..………..12 2.2 Specifications…………………………..…………………………………………12 2.3 Jumpers and Connectors Location……………………………………...16 2.4 Jumpers Setting and Connectors…………………………………..……17...
  • Page 8 Figures Figure 1.1: Dimensions of AEx-2410……..…………….…………..………………..9 Figure 1.2: Overview of AEx-2410.………..…………..…………………….…….….10 Figure 1.3: VESA mount of AEx-2410………………….…………………….…….….11 Figure 1.4: Wall mount of AEx-2410……………………..…………………….…….11 Figure 2.1: Motherboard Dimensions………………………………………….…….15 Figure 2.2: Jumpers and Connectors Location-Board Top……………….….16 Figure 2.3: Jumpers and Connectors Location-Board Bottom…………..…16...

  • Page 9: Getting Started

    1 x 2.5” SATA HDD or SSD space 1 x Internal SD Card slot on board Expansion Expansion 1 x Mini PCIe full size slot (For option WLAN/BT module) Power Power Input DC 9~36V Power Consumption MAX: 15.9W AEx-2410 User Manual...
  • Page 10 Meet CE / FCC Class A Certification ATEx / IECEx / CID2 Zone 2 Operating System Support OS Support Windows 7 Embedded Standard Windows Embedded Standard 7 Windows Embedded 8.1 Pro Windows Embedded 8.1 Industry Pro Windows 10 IOT Enterprise LTSB 2016 AEx-2410 User Manual...

  • Page 11: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of AEx-2410 AEx-2410 User Manual...

  • Page 12: Brief Description Of Aex-2410

    9KHZ to 60GHZ. The model is plating stainless steel chassis and full IP66 grade design. The AEx-2410 works very well along with any of our display series and it absolutely can provide an easy way to perform control and field maintenance.

  • Page 13: Vesa Mounting And Wall Mounting

    1.5 VESA mounting and Wall mounting Figure 1.3: VESA mount of AEx-2410 Figure 1.4: Wall mount of AEx-2410 AEx-2410 User Manual...

  • Page 14: Chapter 2 Hardware

    Up to 1920 x 1200 for HDMI Resolution Up to 1920 x 1200 for LVDS (PS8625) Up to 1920 x 1200 for CRT Dual Display HDMI + LVDS HDMI + CRT LVDS + CRT Super I/O ITE IT8518E Fintek F81216AD AEx-2410 User Manual...
  • Page 15 Expansion Bus 1 x mini-PCI-express slot 1 x PCI-express (CN3) Touch Ctrl 1 x Touch ctrl header for TCH1 (PM6000 for USB4 or COM6) Power Management Wide Range DC6V~36V input 1 x 3-pin power input connector (DC_IN1/DC6~36V) AEx-2410 User Manual...
  • Page 16 12V /0.80A (Intel Atom E3845 processor with 4GB DDR3L DRAM) Power Consumption 12V /0.60A (Intel Atom E3815 processor with 2GB DDR3L DRAM) 12V /0.70A (Intel Celeron N2930 processor with 4GB DDR3L DRAM) EMI/EMS Meet CE/FCC class A AEx-2410 User Manual...

  • Page 17: Figure 2.1: Motherboard Dimensions

    (units :mm) Figure 2.1: Motherboard Dimensions AEx-2410 User Manual...

  • Page 18: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom AEx-2410 User Manual...

  • Page 19: Jumpers Setting And Connectors

    (Switch), ATX Power and Auto Power on jumper setting. S-422(Switch) Mode Pin6 (Off) Manual Power on Pin6 (On) Auto Power on (Default) 5. BAT1: (1.25mm Pitch 1x2 Wafer Pin Header) 3.0V Li battery is embedded to provide power for CMOS. AEx-2410 User Manual...
  • Page 20 SBC-7111-N2930-4G-SW 180°Connector SBC-7111-N2930-2G 180°Connector SBC-7111-N2930-8G 180°Connector SBC-7111-E3845-4G 180°Connector SBC-7111-N2930P-4G 45°Connector SBC-7111-N2930P-CN3V-2G 45°Connector 7. DC_IN2 (option): (2.0mm Pitch 1x4 wafer Pin Header) DC12V System power input connector. Pin# Signal Name VCC_BAT (DC+12V input) VCC_BAT (DC+12V input) Ground Ground AEx-2410 User Manual...
  • Page 21 BIOS CMOS Setup. Pin# Signal Name Ground Rotation detection Note: Output power of cooling fan must be limited under 5W. Model FAN1 SBC-7111-N2930-4G ○ SBC-7111-N2930-4G-SW ○ SBC-7111-N2930P-4G ○ SBC-7111-N2930P-CN3V-2G ○ ○ SBC-7111-E3845-4G ○ SBC-7111-N2930-2G ○ SBC-7111-N2930-8G 10. VGA1: AEx-2410 User Manual...
  • Page 22 Pin3-Pin4 (Close) 8/24 bit (Default) Pin3-Pin4 (Open) 6/18 bit 13. U18: AT24C02-DIP8,The EEPROM IC（U18）is the set of LVDS resolution. If you need other resolution settings, please upgrade U18 data. Model LVDS resolution SBC-7111-N2930-4G 1280*1024 (Default) SBC-7111-N2930-4G-SW 800*480 (option) AEx-2410 User Manual...
  • Page 23 LCD panels. Function Signal Name Pin# Pin# Signal Name Function 12V_S0 12V_S0 BKLT_EN_OUT BKLT_CTRL Ground Ground LVDS_VDD5 LVDS_VDD5 LVDS_VDD3 LVDS_VDD3 Ground Ground LA_D0_P LA_D0_N LVDS LVDS LA_D1_P LA_D1_N LA_D2_P LA_D2_N LA_D3_P LA_D3_N LA_CLKP LA_CLKN LB_D0_P LB_D0_N AEx-2410 User Manual...
  • Page 24 Touch Interface Setting EC(U44) Data TCH1(PM6000) Option A CN1(E2-USB8) Option B 18. JP1: (2.0mm Pitch 2x3 Pin Header), COM1 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM1 port. JP1 Pin# Function AEx-2410 User Manual...
  • Page 25 No.1~6 of JP1, select output Signal RI or 5V or 12V, for details, please refer to description of JP1 and S_232 and S_422 setting. RS232 (Default) Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) AEx-2410 User Manual...
  • Page 26 Signal Name 422_RX+ 422_RX- 422_TX- 422_TX+ Ground BIOS Setup: Advanced/F81216SEC Super IO Configuration/Serial Port 1 Configuration 【RS-422】 RS485 (option) Pin# Signal Name 485- 485+ Ground BIOS Setup: Advanced/F81216SEC Super IO Configuration/Serial Port 1 Configuration 【RS-485】 22. JP2: AEx-2410 User Manual...
  • Page 27 LED3: LED STATUS. Green LED for EC Power status. LED4: LED STATUS. Green LED for Motherboard Power Good status. 25. SATA_P(option): (2.5mm Pitch 1x2 box Pin Header), One onboard 5V output connector are reserved to provide power for SATA devices. Pin# Signal Name +DC5V Ground AEx-2410 User Manual...
  • Page 28 (Socket 52Pin), mini PCIe socket, it is located at the top, it supports mini PCIe devices with USB2.0 and LPC and SMBUS and PCIe signal. MPCIe card size is 30x50.95mm. 30. H1/H2: MPCIE1 SCREW HOLES, H1and H2 for mini PCIE card (30mmx50.95mm) assemble. AEx-2410 User Manual...
  • Page 29 ● SBC-7111-N2930-2G ● SBC-7111-N2930-8G ● SBC-7111-E3845-4G SBC-7111-N2930P-CN3V-2G ○ SBC-7111-N2930-4G-SW ● 33. USB3: USB0/USB3: (Double stack USB type A), Rear USB connector, it provides up to two USB3.0 ports, one USB2.0 port, supports USB full-speed and low-speed signaling. AEx-2410 User Manual...
  • Page 30 RS422 or RS485, one USB2.0, one Power on/off, one Reset. Function Signal Name Pin# Pin# Signal Name Function 5V_S5 5V_S5 SOC_GPIO10 GPIO_IN2 GPIO_IN1 SOC_SPIO09 SOC_GPIO26 GPIO_IN4 GPIO_IN3 SOC_GPIO17 SOC_GPIO05 GPIO_OUT2 GPIO_OUT1 SOC_GPIO04 SOC_GPIO08 GPIO_OUT4 GPIO_OUT3 SOC_GPIO06 Ground Ground AEx-2410 User Manual...
  • Page 31 Backlight manual dimming ○ 38. CN3: (1.27mm Pitch 2X30 Female Header), for expand output connector, it provides four GPIO, two USB 2.0,one PS/2 mouse, one PS/2 keyboard, two uart, one PCIex1, one SMbus. connected to the TB-528 riser Card. AEx-2410 User Manual...
  • Page 32 Ground PCIE_TX0_DN PCIE_TX0_DP PCIE_RX0_DN PCIE_RX0_DP PCIE PCIE Ground Ground PCIE_REFCLK0_DN PCIE_REFCLK0_DP PCIE0_WAKE_N PLTRST_3P3_N SMBUS SMB_CLK_S0 SMB_DATA_S0 SMBUS PCIE PCIE_CLKREQ0_N Ground 3P3V_S5 PWRBTN_ON- Power Auto on 3P3V_S5 3P3V_S5 12V_S0 12V_S0 Model CN3(connector) SBC-7111-N2930-4G 90°Connector SBC-7111-N2930-4G-SW 90°Connector SBC-7111-N2930-2G 90°Connector AEx-2410 User Manual...
  • Page 33 SBC-7111-N2930-8G 90°Connector SBC-7111-E3845-4G 90°Connector SBC-7111-N2930P-4G 90°Connector SBC-7111-N2930P-CN3V-2G 1805°Connector AEx-2410 User Manual...

  • Page 34: Bios Setup

    BIOS, CPU, memory, and storage devices. 3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. AEx-2410 User Manual...

  • Page 35: Main Settings

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 AEx-2410 User Manual...

  • Page 36: Advanced Settings

    Day: Note that the ‘Day’ automatically changes when you set the date. Month: 01 to 12 Date: 01 to 31 Year: 1998 to 2099 3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] Enable Hibernation: AEx-2410 User Manual...
  • Page 37 Change Settings [Auto] 3.4.3 IT8518 Super IO Configuration Super IO chip IT8518/IT8519 Serial Port 1 Configuration Backlight PWM Controller（COM5）： [RS-485] [RS-422] Serial Port 2 Configuration (COM6) Change Settings [Auto] 3.4.4 Intel（R）Smart Connect Technology ISCT Support [Disabled] [Enabled] AEx-2410 User Manual...
  • Page 38 Intel HT-X Technology Supported L1 Data Cache 24KB x 4 L1 Code Cache 32KB x 4 L2 Cache 1024KB x 2 L2 Cache Not Present CPU Thermal configuration CPU Speed 1918 MHz 64-bit Supported Hyper-Threading: [Enabled] [Disabled] AEx-2410 User Manual...
  • Page 39 3.4.7 PPM Configuration CPU C State Report [Enabled] [Disabled] Max CPU C-state [C7] [C6] [C1] SOix [Disabled] [Enabled] 3.4.8 Thermal Configuration Parameters 3.4.9 IDE Configuration Serial-ATA(SATA) [Enabled] [Disabled] SATA Test Mode [Disabled] [Enabled] SATA Speed Support [Gen2] [Gen1] AEx-2410 User Manual...
  • Page 40 SATA Mode [AHCI Mode] [IDE Mode] Serial-ATA Port 0 [Enabled] [Disabled] SATA Port0 Hotplug [Disabled] [Enabled] Serial-ATA Port 1 [Enabled] [Disabled] SATA Port1 Hotplug [Disabled] [Enabled] SATA Port0 Not Present SATA Port1 Not Present 3.4.10 Miscellaneous Configuration AEx-2410 User Manual...
  • Page 41 [Enabled] MIPI HSI Support [Disabled] LPSS Configuration LPSS DMA #1 Support [Enabled] LPSS DMA #2 Support [Enabled] LPSS I2C #1 Support [Enabled] LPSS I2C #2 Support [Enabled] LPSS I2C #3 Support [Enabled] LPSS I2C #4 Support [Enabled] AEx-2410 User Manual...
  • Page 42 GateA20 Active [Upon Request] [Always] Option ROM Messages [Force BIOS] [Keep Current] Boot option filter [UEFI and Legacy] [Legacy only] [UEFI only] Network [UEFI] [Do not launch] [Legacy] Storage [UEFI] [Do not launch] [Legacy] Video [Legacy] [UEFI] AEx-2410 User Manual...
  • Page 43 USB Mass Storage Driver Support [Enabled] [Disabled] USB hardware delays and time-outs： USB transfer time-out: [20 sec] [10 sec] [5 sec] [1 sec] Device reset time-out: [20 sec] [10 sec] [30 sec] [40 sec] Device power-up delay [Auto] [Manual] AEx-2410 User Manual...

  • Page 44: Chipset Settings

    Force Lid Status [On] [Off] [Auto] ALS Support [Disabled] IGD Flat Panel [Auto] Pannel Scaling [Auto] ►Memory Frequency and Timing ►Graphics Power Management Control Memory Information Total Memory 4096 MB(DDR3L) Memory Slot0 4096 MB(DDR3L) DIMM#1 Not Present AEx-2410 User Manual...
  • Page 45 XHCI Mode [Smart Auto] USB2 Link Power Management [Enabled] USB 2.0(EHCI) Support [Enabled] USB EHCI debug [Disabled] USB Per Port Control [Enabled] USB Port 0 [Enabled] USB Port 1 [Enabled] USB Port 2 [Enabled] USB Port 3 [Enabled] AEx-2410 User Manual...

  • Page 46: Security Settings

    You may press key to abandon password entry operation. To clear the password, just press Enter key when password input window pops up. A confirmation message will be shown on the screen as to whether the password AEx-2410 User Manual...

  • Page 47: Boot Settings

    System, you will be requested to enter the password before system boot and when entering BIOS setup; if Security Option is set to Setup, you will be requested for password for entering BIOS setup. 3.7 Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] AEx-2410 User Manual...

  • Page 48: Save & Exit Settings

    Sets the system boot order Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***… ****** Disabled 3.8 Save & Exit Settings Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] AEx-2410 User Manual...
  • Page 49 Restore User Defaults Restore User Defaults? [Yes] [No] Launch EFI Shell from filesystem device WARNING Not Found [ok] Reset System with ME disable ModeMEUD000 ME will runs into the temporary disable mode, Ignore if ME Ignition FWMEUD001. AEx-2410 User Manual...

  • Page 50: Chapter 4 Installation Of Drivers

    Intel chipset driver, VGA driver, Audio driver, Com, and TXE driver Installation instructions are given below. Important Note: After installing your Windows operating system, you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. AEx-2410 User Manual...

  • Page 51: Intel(R) Atomtm Soc Chipset

    To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) AtomTM SoC Chipset from the list Step 2. Here is welcome page. Please make sure you save and exit all programs before install. Click Next. AEx-2410 User Manual...
  • Page 52 Step 3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step 4. Click Install to begin the installation. AEx-2410 User Manual...
  • Page 53 Step 5. Click Finish to exit the wizard. AEx-2410 User Manual...

  • Page 54: Intel(R) Vga Chipset

    4.2 Intel(R) VGA Chipset To install the Intel (R) VGA Chipset, please follow the steps below. Step 1. Select Intel(R) VGA Chipset from the list. Step 2. . Click Next. AEx-2410 User Manual...
  • Page 55 Step 3. Choose automatically run function and Click Next to setup program. Step 4. Read the license agreement. Click Yes to accept all of the terms of the license agreement. AEx-2410 User Manual...
  • Page 56 Step 5. Click Next to continue. Step 6. Click Next to continue. AEx-2410 User Manual...
  • Page 57 Step 7. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. AEx-2410 User Manual...

  • Page 58: Realtek Alc662 Hd Audio Driver Installation

    4.3 Realtek ALC662 HD Audio Driver Installation To install the Realtek ALC662 HD Audio Driver, please follow the steps below. Step 1. Select Realtek AL662 HD Audio Driver from the list Step 2. Click Next to continue. AEx-2410 User Manual...
  • Page 59 Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. AEx-2410 User Manual...

  • Page 60: Com Driver

    4.4 Com Driver To install the Com Driver, please follow the steps below. Step 1. Select Com Driver from the list Step 2. Select setup language you need. Click Next to continue. AEx-2410 User Manual...
  • Page 61 Step 3. Click Next to begin the installation. Step 4. Choose Yes, I want to restart my computer now. Click Finish to complete the installation. AEx-2410 User Manual...

  • Page 62: Intel_Txe(Win) Driver

    4.5 Intel_TXE(Win) Driver To install the Intel_TXE(Win) Driver, please follow the steps below. Step 1. Select Intel_TXE(Win) Driver from the list Step 2. Click Next to continue. AEx-2410 User Manual...
  • Page 63 Step 3. Read the license agreement. Choose Accept and click Next to accept all of the terms of the license agreement. Step 4. Click Next to continue. AEx-2410 User Manual...
  • Page 64 Step 5. Click Finish to complete the installation. AEx-2410 User Manual...
