ACS-500
AUHMI Series Fanless BOX PC
User Manual
Release Date
Revision
Jan.2024
V1.0
®2024 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883
email:
aplex@aplex.com
URL:
http://www.aplex.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUHMI Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex AUHMI Series

Summary of Contents for Aplex AUHMI Series

  • Page 1 ACS-500 AUHMI Series Fanless BOX PC User Manual Release Date Revision Jan.2024 V1.0 ®2024 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 email: aplex@aplex.com...

  • Page 2: Revision History

    Revision History Reversion Date Description 2024/01/11 Initiation ACS-500 Box PC User Manual...

  • Page 3: Warning

    Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Safety Precautions

    Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆ Prevent electric shock. Don‘t touch any components of this card when the card is power-on. Always disconnect power when the system is not in use. ◆...

  • Page 5: Table Of Contents

    Table of Contents Revision History ..........................1 Warning!_______________________________________ ..............2 Safety Precautions ..........................3 Chapter 1 System Product ......................6 Features ..........................6 Specifications .......................... 6 COM port definition ......................... 8 Power Consumption and PoE Application ................... 9 Dimensions ........................... 10 Brief Description of ACS-500 Series ..................
  • Page 6 List of Figures ACS-500 ............................... 10 IGURE IMENSIONS OF 2 AUHMI-910C MB B ..............錯誤! 尚未定義書籤。 IGURE OX KIT ATTACHES TO RONT 3 HDMI/DP IGURE PORT INSERT INSTRUCTION WARNING ......................14 ACS-500 Box PC User Manual...

  • Page 7: Chapter 1 System Product

    Chapter 1 System Product 1.1 Features ⚫ Intel® 11 Gen. Fanless BOX PC ⚫ Fanless design ⚫ DC 9~36V wide-ranging power input ⚫ 2 x 260-pin DDR4 SO-DIMM up to 64GB 3200MHz 1.2 Specifications ACS-500 System Intel 11 Gen. Core™ i7/i5/i3/Celeron SoC Processors Core i7-1185G7E (4C, 1.7GHz, up to 4.4GHz, TDP-up 28W) by project Core i5-1145G7E (4C, 1.5 GHz, up to 4.1GHz, TDP-up 28W) Core i3-1115G4E (2C, 2.2 GHz, up to 3.9GHz, TDP-up 28W)
  • Page 8 10. 1 x LAN+2 x USB2.0+ 45WPOE(TB-528E1U2UPOE) ◆ Backup Battery Pack (exclusive for high brightness model and no TB-528 series at the same time) ◆ 1 x 2W Speaker(exclusive 528 series and backup battery) ◆ Auto Dimming (Exclusive LED indicator) ◆...

  • Page 9: Com Port Definition

    Windows 11 Linux Ubuntu 18.04 with Kernel 5.0 Linux Ubuntu 20.04 Environmental Operating -20℃ to 60℃ (-30℃ to 70℃ for option) Temperature Storage Temperature -30~80°C Humidity 10 to 90% @ 40°C, non-condensing Certification CE / FCC Class A, RoHS/REACH Compliant 1.3 COM port definition Pin# COM1...

  • Page 10: Power Consumption And Poe Application

    * y* does not apply in Linux OS. * We suggest to use the adapter that Aplex approved. If you would like to adopt your own power supply or adapter, please add another 20-30% from the above power consumption to make sure the system can work correctly.

  • Page 11: Dimensions

    1.5 Dimensions Figure 1 Dimensions of ACS-500 ACS-500 Box PC User Manual...

  • Page 12: Brief Description Of Acs-500 Series

    1.6 Brief Description of ACS-500 Series The ACS-500 Industrial BOX PC in AUHMI-9XXC series, which comes with Aluminum heat-sink and black steel chassis. Intel 11 Generation Core i3/i5/i7 CPU Processors with two SO-DIMM DDR4 slot, up to 64GB 3200 MHz are installed in this model. The system supports DC 9~36V wide-ranging power input and IP30 for dust and water protection, which is ideal for Industrial Automation &...

  • Page 13: Wall Mount

    1.7 Wall Mount The ACS-500 is designed to be Wall Mounted as shown in Picture below. Figure 3 ACS-500 Mounting ACS-500 Box PC User Manual...

  • Page 14: Battery Kit Installation

    1.8 Battery Kit Installation Step1: Insert the battery kit to the MB box kit and screw it with 4pcs M3x6 screws. Step2: Connect the battery cable to the MB connector. ACS-500 Box PC User Manual...

  • Page 15: Warning Of Hdmi/Dp Port Insert

    1.9 Warning of HDMI/DP port insert Important: Please be cautious when inserting an HDMI cable into the HDMI/DP port. The HDMI male connector shall align to the left of the port as illustrated here. The insertion is fairly effortless and please reframe from forcing the insertion to prevent damage.

  • Page 16: Chapter 2 Hardware

    Chapter 2 Hardware SBC-7125 is an industrial motherboard developed on the basis of Intel Core I Processors, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual RJ45 connectors, 6-COM ports and one M.2 M-Key configuration, one DP/HDMI combo connector, one LVDS interface.
  • Page 17 USB power control by BIOS GPIO (enable/disable) Without re-driver IC 1 x USB 2.0 via 180°Pitch 2.0mm 2x5Pin DIP type header 2 USB2.0 signal 1 x SATA 3.0 connector: Data transfer rate up to 6Gb/s 1 x SATA power connector :90° pitch 2.0mm 2x5 pin male header 1 x DB9 Male Connector ◼...
  • Page 18 Support 1 clamshell nano-SIM slot 1 x Nano SIM slot via onboard micro SD+ Nano SIM combo slot for mini-PCIe Buzzer 1 x Onboard buzzer Button 1 x Power Button via pitch 2.5mm 2pin terminal block and 180° pitch 2.0mm 2pin wafer 1 x Reset Button via 180°...

  • Page 19: Board Overview

    2.2 Board Overview 2.2.1 Board Top View (units :mm) Buzzer DC IN Header ESPI Header Reset Button Battery Header Power Button SATA0 DP/HDMI SATA Power ▲USB2_3/4 TB-528 2x30 Pin Header ▼USB3_3/4 Clear CMOS ▲USB2_1/2 ▼USB3_1/2 RTC Battery LAN1 & LAN2 COM Port Audio ACS-500 Box PC User Manual...
  • Page 20 2.2.2 Board Bottom View USB Header SIM Card Slot EC Debug DIO Power Select (CN1_DIO) Audio Header ACS-500 Box PC User Manual...

  • Page 21: Jumpers Setting And Connectors

    2.3 Jumpers Setting and Connectors 2.3.1 Pin Assignment: ACS-500 Box PC User Manual...
  • Page 22 ACS-500 Box PC User Manual...
  • Page 23 ACS-500 Box PC User Manual...
  • Page 24 ACS-500 Box PC User Manual...
  • Page 25 ACS-500 Box PC User Manual...
  • Page 26 2.3.2 Expansion Slot: a) M.2 Module installation Before installing the M.2 module into the M.2 socket, please make sure that the following safety cautions are well-attended. Make sure the PC and all other peripheral devices connected to it has been powered down.
  • Page 27 Step 3: Screw tight the card onto the stand-off with a screw driver and a stand-off screw until the gap between the card and the stand-off closes up. The card should be lying parallel to the board when it’s correctly mounted. b) M-PCIe Module installation Before installing the Mini PCIe module into the Mini PCIe socket, please make sure that the fol- lowing safety cautions are well-attended.
  • Page 28 Step 2: Press the end of the card far from the socket down until against the stand-off. Step 3: Screw tight the card onto the stand- off with a screw driver and a stand- off screw until the gap between the card and the stand-off closes up. The card should be lying paral- lel to the board when it’s correctly mounted ACS-500 Box PC User Manual...

  • Page 29: Chapter 3 Bios Setup Description

    Chapter 3 BIOS Setup Description 3.1 Overview The BIOS is a program that takes care of the basic level of communication between the CPU and peripherals. It contains codes for various advanced features found in this system board. The BIOS allows you to configure the system and save the configuration in a battery-backed CMOS so that the data retains even when the power is off.
  • Page 30 <Enter> Enter the highlighted submenu + (plus key)/F6 Scroll forward through the values or options of the highlighted field - (minus key)/F5 Scroll backward through the values or options of the highlighted field <F1> Display general help <F2> Display previous values <F7>...

  • Page 31: Main Settings

    3.2 Main Settings ACS-500 Box PC User Manual...

  • Page 32: Advanced Settings

    Advanced Settings ACS-500 Box PC User Manual...
  • Page 33 ACS-500 Box PC User Manual...
  • Page 34 ACS-500 Box PC User Manual...
  • Page 35 ACS-500 Box PC User Manual...
  • Page 36 ACS-500 Box PC User Manual...
  • Page 37 ACS-500 Box PC User Manual...
  • Page 38 ACS-500 Box PC User Manual...
  • Page 39 ACS-500 Box PC User Manual...
  • Page 40 ACS-500 Box PC User Manual...
  • Page 41 ACS-500 Box PC User Manual...

  • Page 42: Chipset Settings

    3.4 Chipset Settings ACS-500 Box PC User Manual...
  • Page 43 ACS-500 Box PC User Manual...
  • Page 44 ACS-500 Box PC User Manual...
  • Page 45 ACS-500 Box PC User Manual...
  • Page 46 ACS-500 Box PC User Manual...

  • Page 47: Security Settings

    3.5 Security Settings ACS-500 Box PC User Manual...
  • Page 48 ACS-500 Box PC User Manual...

  • Page 49: Boot Settings

    3.6 Boot Settings ACS-500 Box PC User Manual...

  • Page 50: Save & Exit Settings

    3.7 Save & Exit Settings ACS-500 Box PC User Manual...
  • Page 51 ACS-500 Box PC User Manual...

  • Page 52: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 10. The software and drivers are included with the motherboard. The contents include Intel Chipset, Graphics chipset driver, Audio driver, Intel LAN Driver, Intel® Serial I/O, Intel® Management and Security Status Installer, Intel®...

  • Page 53: Intel Chipset

    4.1 Intel Chipset To install the Intel chipset driver, please follow the steps below. Step 1. Here is welcome page. Please make sure you save and exit all programs before install. Click Next. Step 2. Read the license agreement. Click Accept to accept all of the terms of the license agreement.
  • Page 54 Step 3. Click Install to begin the installation. Step 4. Click Finish to finish installation. ACS-500 Box PC User Manual...

  • Page 55: Intel® Hd Graphics Chipset

    4.2 Intel® HD Graphics Chipset To install the Intel® HD Graphics Chipset, please follow the steps below. Step 1. Click Begin installation. Step 2. Read the license agreement. Click I agree to accept all of the terms of the license agreement.
  • Page 56 Step 3. Click Start to setup program. Step 4. Click Finish to complete installation. ACS-500 Box PC User Manual...

  • Page 57: Realtek Hd Audio Driver Installation

    4.3 Realtek HD Audio Driver Installation To install the Realtek HD Audio Driver, please follow the steps below. Step 1. Click Next to continue. Step 2. Click Yes, I want to restart my computer now to complete the installation. ACS-500 Box PC User Manual...

  • Page 58: Intel Lan Driver

    4.4 Intel LAN Driver To install the LAN driver, please follow the steps below. Step 1. Click Install to start installation. Step 2. Click OK to confirm the installation procedure. ACS-500 Box PC User Manual...
  • Page 59 Step 3. Click Close to finish installation. Step 4. Choose Yes, restart the computer now to complete the installation. ACS-500 Box PC User Manual...

  • Page 60: Intel® Serial I/O

    4.5 Intel® Serial I/O To install Intel® Serial I/O, please follow the steps below. Step 1. Click Next to continue. Step 2. Choose I accept the terms in the License Agreement and click Next to begin the installation. ACS-500 Box PC User Manual...
  • Page 61 Step 3. Click Next to continue. Step 4. Click Next to continue. ACS-500 Box PC User Manual...
  • Page 62 Step 5. Click Finish to complete installation. ACS-500 Box PC User Manual...

  • Page 63: Intel® Management And Security Status Installer

    4.6 Intel® Management and Security Status Installer Step 1. Click Install to continue the installation. Step 2. Click Finish to exit setup. ACS-500 Box PC User Manual...

  • Page 64: Intel® Management Engine Components

    4.7 Intel® Management Engine Components Step 1. Click Next to continue. Step 2. Choose I accept the terms in the License Agreement and click Next to continue. ACS-500 Box PC User Manual...
  • Page 65 Step 3. Click Next to continue. Step 5. Click Finish to complete installation. ACS-500 Box PC User Manual...

  • Page 66: Intel® Hid Event Filter

    4.8 Intel® HID Event Filter Step 1. Click Next to continue. Step 2. Read the License Agreement and Click Yes to continue. ACS-500 Box PC User Manual...
  • Page 67 Step 3. Click Next to continue. Step 4. Choose Yes, I want to restart this computer now and click Finish to finish installation. ACS-500 Box PC User Manual...
