NV-266XC
Fanless Box PC
Box PC User Manual
Revision
Date
Version
Remark
July. 2014
V1.1
NV-266XC User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NV-266 C Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex NV-266 C Series

Summary of Contents for Aplex NV-266 C Series

  • Page 1 NV-266XC Fanless Box PC Box PC User Manual Revision Date Version Remark July. 2014 V1.1 NV-266XC User Manual...
  • Page 2 Warning!___________________________________ This equipment generates, uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions manual, it may cause interference to radio communications. It has been tested and found to comply with the limits for a Class A computing device pursuant to FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment.

  • Page 3: Table Of Contents

    Table of Contents______________________ Warning!…………………………………………………………………………….……..….2 Chapter 1 Getting Started 1.1 Specifications……………………………………….……………………..5 1.2 Dimensions………………………………...…………………………..6 1.3 Brief Description…………………………………………………….……10 Chapter 2 Hardware 2.1 Specifications……………..…….……………………………………..…..13 2.2 Board Dimensions…………………………………………………………15 2.2 Jumpers and Connectors Location……………………………………...17 2.3 Jumpers and Connectors………………………...………………………19 Chapter 3 BIOS Setup 3.1 Operations after POST Screen............44 3.2 BIOS SETUP UTILITY................44 3.3 Main Settings…..................45 3.4 Advanced Settings................
  • Page 4 Figure 1.6: Front view of NV-2664C…………………………………………11 Figure 1.7: Rear view of NV-2664C…………………………………………11 Figure 1.8: Front view of NV-2665C…………………………………………11 Figure 1.9: Rear view of NV-2665C………………………….…………….12 NV-266XC User Manual...

  • Page 5: Specifications

    Chapter 1 System 1.1 Specifications Model NV-2663C NV-2664C NV-2665C System Processor Intel Atom Processor D2550 1.86GHz , L2 Cache 1MB System chipset Intel NM10 Express System memory 1 x SO-DIMM 204pin, up to 4GB DDR3 800/1066MHz FSB IO Port 4 x USB 2.0 type A Serial/Parallel 3 x RS-232, 1 x RS-422/485 selectable default RS-485 Audio...

  • Page 6: Dimensions

    Environment Standard: 0℃ to 50℃ Operating Option WT1: -20℃ to 60℃ (with Industrial HDD/SSD/CF) temperature(°C) Option WT2: -20℃ to 70℃ (with Industrial HDD/SSD/CF) Storage temperature(°C) -20 ℃ ~ 60 ℃ 10 to 90%@ 40℃, non-condensing Storage humidity Certification CE / FCC Class A Operating System Support Win 7, WES7, XP, WIN CE 6.0 1.2 Dimensions...

  • Page 7: Figure 1.1:Dimensions Of Nv-2663C

    Figure 1.1: Dimensions of NV-2663C NV-266XC User Manual...

  • Page 8: Figure 1.2:Dimensions Of Nv-2664C

    Figure 1.2: Dimensions of NV-2664C NV-266XC User Manual...

  • Page 9: Figure 1.3:Dimensions Of Nv-2665C

    Figure 1.3: Dimensions of NV-2665C NV-266XC User Manual...

  • Page 10: Brief Description

    1.3 Brief Description of NV-266XC NV-266XC is a Fan-less wall mounting and ultra-compact standalone Box PC, powered by an Intel Atom Processor D2550 1.86GHz , L2 Cache 1MB and supporting 4 x USB, 1 x SATA HDD space, DC 9~32V DC etc. NV-266XC works very well along with any of our Display Monitor series and it absolutely can provide an easy way to perform control and field maintenance.

  • Page 11: Figure 1.6 Front View Of Nv-2664C

    Figure 1.6 Front view of NV-2664C Figure 1.7 Rear view of NV-2664C Figure 1.8:Front view of NV-2665C NV-266XC User Manual...

  • Page 12: Figure 1.9:Rear View Of Nv-2665C

    Figure 1.9:Rear view of NV-2665C NV-266XC User Manual...

  • Page 13: Chapter 2 Hardware

    Chapter 2 Hardware ASB-M7101 is a Mini-ITX industrial motherboard developed on the basis of Intel D2550 and NM10, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual 1000M LAN port, 6-COM port and one Mini PCIE configuration. To satisfy the special needs of high-end customers, PC104+ socket (capable of adjusting IO voltage) richer extension functions.
  • Page 14 1 x Compact Flash II Slot for TB-522 or TB-523 (option） Ethernet 2 x PCIe Gbe LAN by Intel 82583V 4 x USB 2.0 stack ports for external 3 x USB 2.0 box Pin header for MIO1 1 x USB 2.0 internal for mini PCIe 1 x RS232/422/485 port, DB9 connector for external (COM1) pin 9 w/5V/12V/Ring select 1 x RS232 port, DB9 connector for external (COM2)
  • Page 15 1 x CRT DB15 Port 1 x Audio Ports (mic, line out) Software programmable 1 – 255 second by Super I/O Watchdog Timer Operating: -20℃ to 70℃ Temperature Storage: -40℃ to 85℃ 10% - 90%, non-condensing, operating Humidity 12V /1.25A (Intel Atom D2550 processor with 2GB DDR3 DRAM) Power 12V /1.18A (Intel Atom N2800 processor with 2GB DDR3 DRAM) Consumption...

  • Page 16: Board Dimensions

    2.2 Board Dimensions NV-266XC User Manual...

  • Page 17: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Board Top NV-266XC User Manual...
  • Page 18 Board Bottom NV-266XC User Manual...

  • Page 19: Jumpers And Connectors

    2.4 Jumpers Setting and Connectors 1. JP1: (2.0mm Pitch 1X3 Pin Header)CMOS clear jumper, CMOS clear operation will permanently reset old BIOS settings to factory defaults. CMOS Close 1-2 NORMAL (Default) Close 2-3 Clear CMOS Procedures of CMOS clear: a) Turn off the system and unplug the power cord from the power outlet. b) To clear the CMOS settings, use the jumper cap to close pins2 and 3 for about 3 seconds then reinstall the jumper clip back to pins open.
  • Page 20 5. DCIN: (5.08mm Pitch 1x3 Pin Connector),DC9V ~ DC32V System power input connector。 Pin# Power Input Pin1 DC+9V~32V Pin2 Ground Pin3 Power Mode Location : DCIN Location: ATX12V Location: ATX1 (5.4.5.) (5.4.6.) (5.4.7.) DC INPUT input output (Default) DC9~32V DC 12V ATX Power Input (DC12V) PSON,GND,5VSB...
  • Page 21 MODEL ASB-M7101T-D2550 Intel Atom D2550 1.86GHz ASB-M7101B-D2550 (option) Intel Atom D2550 1.86GHz ASB-M7101T-N2800 (option) Intel Atom N2800 1.86GHz ASB-M7101B-N2800 (option) Intel Atom N2800 1.86GHz ASB-M7101T-N2600 (option) Intel Atom N2600 1.60GHz ASB-M7101B-N2600 (option) Intel Atom N2600 1.60GHz 9. CPU_FAN/SYS_FAN: (2.54mm Pitch 1x3 Pin wafer connector),Fan connector, cooling fans can be connected directly for use.
  • Page 22 12. VGA_PH(option): (CRT 2.0mm Pitch 2X6 Pin Header), Video Graphic Array Port, Provide 2x5Pin cable to VGA Port, they can not work at the same time for VGA and VGA_PH. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE VGA_EN CRT_H_SYNC...
  • Page 23 14. LVDS1: (1.25mm Pitch 2x20 Connector, DF13A-40DP-1.25V),For 18/24-bit LVDS1 output connector, Fully supported by U2 Intel Processor, the interface features single channel 18/24-bit output. Low Voltage Differential Signaling, A high speed, low power data transmission standard used for display connections to LCD panels. Signal Name Pin# Pin#...
  • Page 24 +DC12V +DC12V Ground Ground BKLT_EN BKLT_CTRL Note: Pin6 is backlight control signal, support DC or PWM mode, mode select at BIOS CMOS menu. 17. LVDS2(option): (1.25mm Pitch 2x20 Connector, DF13A-40DP-1.25V), For 18/24-bit LVDS2 output connector, Fully supported by Parad PS8625(DP to LVDS), the interface features dual channel 24-bit output. Low Voltage Differential Signaling, A high speed, low power data transmission standard used for display connections to LCD panels.
  • Page 25 disconnected under normal condition. You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state. 20. JP2: (2.0mm Pitch 2x3 Pin Header),COM1 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM1 port.
  • Page 26 RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) RI/5V/12V (JP2 select Setting) COM1/RS422 (option): Pin# Signal Name 422_RX+ 422_RX- 422_TX- 422_TX+ Ground 5V/12V (JP2 select Setting) COM1/RS485 (option): Pin# Signal Name...
  • Page 27 Close 5-6 COM2 Pin9=+12V (option) 24. COM2: (Type DB9), Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready)
  • Page 28 (2.0mm Pitch 2X5 Pin Header), COM6 Port, standard RS232 ports are provided. They can be used directly via COM cable connection. COM6 port is controlled by pins No.1~6 of JP4,select output Signal 5V or 12v, For details, please refer to description of JP4. Signal Name Pin# Pin#...
  • Page 29 31. AUDIO(option): (2.0mm Pitch 2X6 Pin Header), Front Audio, An onboard Realtek ALC662 codec is used to provide high-quality audio I/O ports. Line Out can be connected to a headphone or amplifier. Line In is used for the connection of external audio source via a Line in cable. MIC is the port for microphone input audio.
  • Page 30 ASB-M7101B-N2800 (option) Bottom (option) ASB-M7101T-N2600 ASB-M7101B-N2600 (option) Bottom 35. PCIE1X (option) (4x10 Pin), PCIe bus connector, it conforms to standard PCI Express x1 specification. Can expand support two PCIe devices. PCIe1 Signal for PCIE1X or MPCIE Socket. PCIe4 Signal for PCIE1X Socket. Model PCIE1X Connector ASB-M7101T-D2550...
  • Page 31 5V_S5 5V_S5 DCD4- RXD4 TXD4 DTR4- COM4 COM4 Ground DSR4- RS232 RS232 RTS4- CTS4- RI4- 5V_S5 5V_S5 5V_USB_01 USB3_N USB0_N USB3 USB0 USB3_P USB0_P Ground Ground Ground Ground 5V_USB_01 PWR_LED+ Power USB1_N PWR_LED- USB1 USB1_P MIO_PSON Power Button Ground Ground AUTO_PS_ON 40.
  • Page 32 Ground Ground Pin1/Ground: HDD LED, They are used to connect hard disk activity LED. The LED blinks when the hard disk is reading or writing data. Pin2/Pin4: POWER LED, They are used to connect power LED. When the system is powered on or under S0/S1 state, the LED is normally on, when the system is under S4/S5 state, the LED is off.
  • Page 33 42. SATA1/SATA2: (SATA 7P), SATA Connectors, Two SATA connectors are provided, with transfer speed up to 3.0Gb/s. 43. CON1(option): (2.0mm Pitch 1x4 Pin wafer connector),Smbus Signal connector. Pin# Signal Name SMB_CLK_MAIN_IO 3.3V Ground SMB_DATA_MAIN_IO 44. SIM1(option): (SIM Socket 7Pin), Support SIM Card devices. 45.
  • Page 34 PWR BT: POWER on/off Button, They are used to connect power switch button. The two pins are disconnected under normal condition. You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state. PWR LED: POWER LED status. COM3: (Type DB9 I/O serial port, it provides selectable RS422/RS485 serial signal output.
  • Page 35 DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) RI (Ring Indicator) USB10,USB11: (Double stack USB type A), I/O USB connector, it provides up to 2 USB2.0 ports, speed up to 480Mb/s.
  • Page 36 5V_S5 DCD4- RXD4 TXD4 DTR4- Ground DSR4- RTS4- CTS4- RI4- 5V_S5 5V_S5 5V_USB01 USB3_N USB0_N USB3_P USB0_P Ground Ground Ground Ground 5V_USB01 PWR_LED+ USB1_N PWR_LED- USB1_P PS_ON- Ground Ground Ground Ground 48. TB-520P1: TB-520P1 connect to ASB-M7101T PC104+ connector, PC104+ is located at the top, It provides one PCI slot.
  • Page 37 50. TB-520P1E1: TB-520P1E1 connect to ASB-M7101T PC104+ and PCIE1X connector,PC104+ and PCIE1X are located at the top, It provides one PCI slot and one PCIE slot. 51. TB-520E1: TB-520E1 connect to ASB-M7101T PCIE1X connector, PCIE1X are located at the top, It provides one PCIE slot.
  • Page 38 53. TB-521P2: TB-521P2 connect to ASB-M7101B PC104+ connector, PC104+ is located at the Bottom, It provides two PCI slots. 54. TB-521P1E1: TB-521P1E1 connect to ASB-M7101B PC104+ and PCIE1X connector,PC104+ and PCIE1X are located at the Bottom, It provides one PCI slot and one PCIE slot. NV-266XC User Manual...
  • Page 39 55. TB-521P1E12: TB-521P1E12 connect to ASB-M7101B PC104+ and PCIE1X connector,PC104+ and PCIE1X are located at the Bottom, It provides one PCI slot and two PCIE slots. PCIe1 Signal for PCIE1X or MPCIE Socket. 56. TB-523: ASB-M7101 I/O Card, via a dedicated cable connected to ASB-M7101 MIO1 and MIO2. TB-523 Top：...
  • Page 40 LED2: CF Card LED status. PWR BT: POWER on/off Button, They are used to connect power switch button. The two pins are disconnected under normal condition. You may short them temporarily to realize system startup & shutdown or awaken the system from sleep state. PWR LED: POWER LED status.
  • Page 41 [RS-485] [RS-422] JP4: (2.0mm Pitch 2x10 Pin Header) COM4 function setting jumper. Function JP4 Pin# RS232 Close: 3-5,4-6,10-12,11-13 (Default) RS422 Close: 1-3,2-4,5-7,8-10,9-11,12-14,18-20 (option) RS485 Close: 5-7,8-10,9-11,12-14,16-18 (option) COM4: (Type DB9), I/O serial port, it provides selectable RS232/RS422/RS485 serial signal output. COM4 RS232 Type (Default)：...
  • Page 42 USB10: (Single stack USB type A), I/O USB connector, it provides one USB2.0 port, speed up to 480Mb/s. USB11: (2.0mm Pitch 1x4 box Pin Header), I/O USB connector, it provides one USB2.0 port, speed up to 480Mb/s. USB10 and USB11 connected to ASB-M7101 MIO1 USB0 and USB1. Pin# Signal Name 5V_USB01...
  • Page 43 Ground GPIO_IN1 GPIO_IN2 GPIO_IN3 GPIO_IN4 GPIO_OUT1 GPIO_OUT2 GPIO_OUT3 GPIO_OUT4 MIO1: (DF13-40P) TB-523 MIO1 via a dedicated Y cable connected to ASB-M801 MIO1 and MIO2. Signal Name Pin# Signal Name 422_RX+ 485+_422TX+ 422_RX- 485-_422TX- Ground GPIO_IN1 GPIO_IN2 GPIO_IN3 GPIO_IN4 5V_S5 DCD4- RXD4 TXD4 DTR4-...

  • Page 44: Chapter 3 Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation,.Press [Delete] key to enter CMOS Setup. Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. BIOS Date: 05/14/2013 22:29:02 Ver: M7101V006 Press 〈DEL〉or〈ESC〉to enter setup After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices.

  • Page 45: Main Settings

    Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit BIOS Information Intel Reference Code BIOS Vendor American Megatrends Version Core Version 4.6.5.3 Compliancy UEFI 2.3; PI 1.2 Project Version 7101V006 ►Intel RC Version →←: Select Screen System Language [English]...

  • Page 46: Advanced Settings

    →←: Select Screen System Language [English] ↑↓ : Select Item System Date [Sun 01/01/2012] Enter: Select System Time [00:00:09] +/- : Charge Opt. F1 : General Help Access Level Administrator F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC Exit Version 2.15.1226.
  • Page 47 ►W83627UHG HW Monitor →←: Select Screen ►Serial Port Console Redirection ↑↓ : Select Item ►PPM Configuration Enter: Select +/- : Charge Opt. F1 : General Help F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends , Inc. 3.4.1 PCI Subsystem Settings PCI Bus Driver Versio V2.05.02 PCI Common Settings:...
  • Page 48 Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [Both S1 and S3 available for OS to choose from] [Suspend Disabled] [S1 only (CPU Stop Clock）] [S3 only (Suspend to RAM) ] Lock Legacy Resources: [Disabled] [Enabled] S3 Video Repost: [Disabled] [Enabled] 3.4.3 CPU Configuration Processor Type...
  • Page 49 Limit CPUID Maximum: [Disabled] [Enabled] 3.4.4 Thermal Configuration CPU Thermal Configuration DTS SMM [Disabled] [Enabled] Platform Thermal Configuration Critical Trip Point [15C] Active Trip Point Lo [55 C] Active Trip Point Hi [71C] Passive Trip Point [95] Passive TC1 Value Passive TC2 Value Passive TSP Value 3.4.5...
  • Page 50 USB hardware delays a USB transfer time-out: [20 sec] [10 sec] [5 sec] [1 sec] Device reset time-out: [20 sec] [10 sec] [30 sec] [40 sec] Device power-up delay [Auto] [Manual] 3.4.7 W83627UHG Super IO Ch Configuration W83627UHG Super IO ch W83627UHG Serial Port 1 Configuration Serial Port 2 Configuration Serial Port 3 Configuration...
  • Page 51 COM0 Console Redirection [Enabled] [Disabled] Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection [Disabled] [Enabled] Console Redirection Settings 3.4.10 PPM Configuration PPM Configuration EIST: [Enabled] [Disabled] CPU C state Report [Enabled] [Disabled] Enhanced C state [Enabled] [Disabled] CPU Hard C4E...

  • Page 52: Chipset Settings

    Chipset Settings Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Host Bridge Parameters ►Host Bridge ►South Bridge →←: Select Screen ↑↓ : Select Item Enter: Select +/- : Charge Opt. F1 : General Help F2: Previous Values F3:Optimized Defaults...
  • Page 53 [1.25GB] [1.5GB] [1.75GB] [2GB] [2.25GB] [2.5GB] [2.75GB] [3GB] [3.25GB] Intel IGD Configuration IGFX – Boot Type [VBIOS Default] [CRT] [LVDS1] [LVDS2] [VGA + LVDS] LCD Panel Type [VBIOS Default] [640x480,18bit] [800x480,18bit] [800x600,18bit] [1024x600,18bit] [1024x768,18bit] [1280x768,18bit] [1280x800,18bit] [1280x1024,18bit] [1366x768,18bit ] [1024x768,24bit ] [1280x768,24bit ] [1280x800,24bit ] [1280x1024,24bit ]...
  • Page 54 Fixed Graphics Memory [128MB] [256MB] ALS Support [Disabled] [Enabled] Back light Control [DC] [PWM] Backlight Logic [Positive] [Negative] Backlight Control Lev [Level 8] [Level 0] [Level 1] [Level 2] [Level 3] [Level 4] [Level 5] [Level 6] [Level 7] [Level 9] [Level 10] [Level 11] [Level 12]...

  • Page 55: Boot Settings

    PCI Express Root Port 1 PCI Express Root Port 2 PCI Express Root Port 3 DMI Link ASPM Control [Enabled] [Disabled] PCI-Exp. High Priorit [Disabled] [Enabled] High Precision Event Timer Configuration High Precision Timer [Enabled] [Disabled] SLP_S4 Assertion Widt [1-2 Seconds] [2-3 Seconds] [3-4 Seconds] [4-5 Seconds]...
  • Page 56 →←: Select Screen ↑↓ : Select Item Driver Option Priorities Boot Option Priorities Enter: Select Boot Option #1 [SATA PM: Hitachi…] +/- : Charge Opt. Boot Option #2 […] F1 : General Help Hard Drive BBS Priorities F2: Previous Values F3:Optimized Defaults ►CSM Parameters F4:Save and Exit...

  • Page 57: Security Settings

    Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***… ****** Disabled CSM Parameters Launch CSM [Always] [Never] Boot option filter [UEFI and Legacy] [Legacy only] [UEFI only] Launch PXE OpROM poli [Legacy only] [Do not Launch] [UEFI only] Launch Storage OpROM [Legacy only]...
  • Page 58 Password Description Set Administrator Password If ONLY the Administrator’s password is set, Then this only limits access to Setup and is Only asked for when entering Setup. If ONLY the User’s password is set, then this Is a power on password and must be entered to Is a power on password and must be entered to Boot or enter Setup.

  • Page 59: Save & Exit Settings

    the password before system boot and when entering BIOS setup; if Security Option is set to Setup, you will be requested for password for entering BIOS setup. Save & Exit Settings Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset...
  • Page 60 Reset Without Saving Reset without saving? [Yes] [No] Save Changes Save Setup Values Save configuration? [Yes] [No] Discard Changes Load Previous Values Load Previous Values? [Yes] [No] Restore Defaults Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? [Yes] [No]...

  • Page 61: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows XP. The software and drivers are included with the motherboard. The contents include Intel chipset driver, VGA driver, LAN drivers, Audio driver. Installation instructions are given below.

  • Page 62: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel(R) Chipset Atom D525 + Intel ICH8M from the list Step 2. Click Next to setup program. NV-266XC User Manual...
  • Page 63 Step 3. Read the license agreement. Click Yes to accept the terms of the license agreement. Step 4. Click Next to continue. NV-266XC User Manual...
  • Page 64 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drivers. NV-266XC User Manual...

  • Page 65: Intel Graphics Media Accelerator Driver

    4.2 Intel Graphics Media Accelerator Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1. Select Intel (R) GMA 3150 VGA Chipset. Step 2. Click Next to continue. NV-266XC User Manual...
  • Page 66 Step 3. Click I agree. Step 4. Click Continue Anyway. NV-266XC User Manual...
  • Page 67 Step 5. Click Continue Anyway. Step 6. Click Yes to restart the computer. NV-266XC User Manual...

  • Page 68: Intel 82583V Network Adapter

    4.3 Intel(R) 8253V Network Adapter To install the Intel (R) 8253V Network Adapter connect device driver, please follow the steps below. Step 1. Select Intel (R) 8253V Network Adapter from the list Step 2. Click Next to continue. NV-266XC User Manual...
  • Page 69 Step 3. Read the license agreement. Select I accept the terms in the license agreement then click Next to continue. Step 4. Select Drivers, Intel(R) PROSet for Windows* Device Manager, Advanced Network Services. Click Next to continue. NV-266XC User Manual...
  • Page 70 Step 5. Click Install to begin installation. Step 6. Click Finish to complete the installation. NV-266XC User Manual...

  • Page 71: Realtek Hd Audio Driver Installation

    4.4 Realtek HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Driver from the list Step 2. Click Next to continue the installation. NV-266XC User Manual...
  • Page 72 Step 3. Click Yes. NV-266XC User Manual...
