Aplex ACS-2330 User Manual

Intel 6th gen. core i fanless box pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

ACS-2330/2332
th
Intel 6
Gen. Core i Fanless Box PC
User Manual
Release Date
Revision
May.2017
V1.1
®2017 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883
URL:
www.aplextec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACS-2330 and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex ACS-2330

Summary of Contents for Aplex ACS-2330

  • Page 1 Gen. Core i Fanless Box PC User Manual Release Date Revision May.2017 V1.1 ®2017 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 URL: www.aplextec.com...

  • Page 2: Revision History

    Revision History Reversion Date Description 2017/02/18 Official Version  2017/05/03 Modify product image  Remove 1xmSATA  Modify COM port position  Modify SSD spec. up to 32GB  Add LAN LED light description for LAN1~4 ACS-2330/2332 User Manual...

  • Page 3: Warning/Disclaimer

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) ACS-2330/2332 User Manual...

  • Page 5: Safety Precautions

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ACS-2330/2332 User Manual...

  • Page 6: Table Of Contents

    4.1 Intel(R) 100 Series Chipset Driver…..….………..…….………………………52 4.2 Intel(R) HD Graphics 530 Chipset Driver…………………….……………..56 4.3 Realtek ALC269 HD Audio Driver…...………………………..…………..….…...60 Figures Figure 1.1: Dimensions of ACS-2330………..……..…….……………………………..9 Figure 1.2: Dimensions of ACS-2332..…..……………..…..……………….……9 Figure 1.3: Front view of ACS-2330………….……….………………………………….10 Figure 1.4: Front view of ACS-2332………….……….………………………………….10 ACS-2330/2332 User Manual...
  • Page 7 Figure 1.5: I/O rear view of ACS-2330………….……….…………………………….11 Figure 1.6: I/O rear view of ACS-2332………….………….………………………….11 Figure 2.1: Motherboard Dimensions…………………………………………………..15 Figure 2.2: Jumpers and Connectors Location-Board Top……………………..16 Figure 2.3: Jumpers and Connectors Location-Board Bottom……………….17 ACS-2330/2332 User Manual...

  • Page 8: Getting Started

    2 x 2.5” SATA3 HDD bay (Easy accessible) Expansion Expansion Slot 3 x Mini PCIe slots full size (one shared with mSATA) (Only for ACS-2332) 2 x PCIe slot via TB-554E41E11:1 x PCIe x4 or 2 x PCIe x1 slot for option Wireless LAN ACS-2330/2332 User Manual...
  • Page 9 Storage Temperature -40~85 °C Storage Humidity 10 to 90% @ 40 °C , non-condensing Certification CE / FCC Class A Operating System Windows Embedded 8.1 Industry Pro, Support Windows Embedded 8 Standard Pro, Windows 10 IOT 2016 ACS-2330/2332 User Manual...

  • Page 10: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of ACS-2330 Figure 1.2: Dimensions of ACS-2332 ACS-2330/2332 User Manual...

  • Page 11: Brief Description Of Acs-2330/2332

    (one shared with mSATA) slots for expansion. The model is plating titanium gray aluminum heatsink and black steel chassis design, and can be wall mounted. The ACS-2330/2332 works very well along with any of our display series and it absolutely can provide an easy way to perform control and field maintenance.

  • Page 12: Figure 1.5: I/O Rear View Of Acs-2330

    Figure 1.5: I/O rear view of ACS-2330 Figure 1.6: I/O rear view of ACS-2332 ACS-2330/2332 User Manual...

  • Page 13: Chapter 2 Hardware

    Up to 4096 x 2304 for Display Port Up to 2560 x 1600 for DVI-I Up to 1920 x 1200 for VGA Three Display HDMI + DVI-I + DP HDMI + DVI-I +VGA（option) DVI-I + DP + VGA（option) Super I/O Nuvoton NCT6106D ACS-2330/2332 User Manual...
  • Page 14 1x PS/2 mouse Expansion 1x PCI-express x4 extend by 4x20 pin socket (PCIE_4X) 2x mini-PCI-express slot (M-PCIE1/MPCIE2) 1x CRT 2x5 Pin Header (VGA1) Power 1x 3-pin power input connector (Wide range DC+9V~36V) Management DC5V/12V output by 1x4 pin Connectors ACS-2330/2332 User Manual...
  • Page 15 1x SIM Socket 1x LPT Port by DF13-20P (LPT1) Operating: -20℃ to 70℃ Temperature Storage: -40℃ to 85℃ Humidity 10% - 90%, non-condensing, operating Power 12V/5.2A(Intel i5-6500TE 2.30 GHz Processor with 16GB DDR4/HDD) Consumption EMI/EMS Meet CE/FCC class A ACS-2330/2332 User Manual...

  • Page 16: Figure 2.1: Motherboard Dimensions

    (units :mm) Figure 2.1: Motherboard Dimensions ACS-2330/2332 User Manual...

  • Page 17: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top ACS-2330/2332 User Manual...

  • Page 18: Figure 2.3: Jumpers And Connectors Location-Board Bottom

    Figure 2.3: Jumpers and Connectors Location- Board Bottom ACS-2330/2332 User Manual...

  • Page 19: Jumpers Setting And Connectors

    (1.25mm Pitch 1x2 wafer Pin Header) 3.0V Li battery is embedded to provide power for CMOS. 3. PS_ON2: (2.0mm Pitch 1x2 Wafer Pin Header),ATX Power and Auto Power on jumper setting. 4. PS_ON1: (2.0mm Pitch 1x2 Wafer Pin Header) ,Power on/off, They are used to connect power switch ACS-2330/2332 User Manual...
  • Page 20 (2.0mm Pitch 2x2 Pin Pin Header), DC12V System only power input jumper setting. 【 】 *please contact technical support 8. DC_OUT: (2x2 Pin Connector),DC+12V and DC+5V System power output connector. Pin# Power output Pin1 DC+12V（DC12V_S0） Pin2 Ground Pin3 Ground Pin4 DC+5V(DC5V_S0) ACS-2330/2332 User Manual...
  • Page 21 CPU_FANPWM ○ ● Note: Output power of cooling fan must be limited under 5W. 12. PCH1: (BGA,Package Size:23x24mm),Intel H170 Chipset. PCH1（Chipset） Model SBC-7113HB Intel H170 SBC-7113HT Intel H170 13. H7/H8 (option): PCH1 HeatSink Screw holes. 14. DDR4_1/DDR4_2: ACS-2330/2332 User Manual...
  • Page 22 (CRT 2.0mm Pitch 2X6 Pin Header), Video Graphic Array Port, Provide 2x6Pin cable to VGA Port.The IT6515FN is a high-performance single-chip DisplayPort to VGA converter. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE CRT_SENSE CRT_H_SYNC CRT_DDCDATA ACS-2330/2332 User Manual...
  • Page 23 Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP1 select Setting (RI/5V/12V) RS422 (option): Pin# Signal Name ACS-2330/2332 User Manual...
  • Page 24 (2.0mm Pitch 2x3 Pin Header),COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. JP2 Pin# Function Close 1-2 COM2 Pin9 RI (Ring Indicator) (default) Close 3-4 COM2 Pin9=+5V (option) Close 5-6 COM2 Pin9=+12V (option) 23. JP_C2(option): ACS-2330/2332 User Manual...
  • Page 25 DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP2 select Setting (RI/5V/12V) RS422 (option): Pin# Signal Name 422TX- 422TX+ 422RX+ 422RX- Ground RS485 (option): Pin# Signal Name 485- ACS-2330/2332 User Manual...
  • Page 26 (Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. RS232 (Default): Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) ACS-2330/2332 User Manual...
  • Page 27 CTS (Clear To Send) JP4 select Setting (RI/5V/12V) 29. USB3_LAN1/USB3_LAN2: USB3-3/USB3-4/USB3-1/USB3-2 ：(Double stack USB typeA),Rear USB connector, it provides up to 4 USB3.0 ports,USB 3.0 allows data transfers up to 5.0Gb/s ,support USB2.0 and full-speed and low-speed signaling. ACS-2330/2332 User Manual...
  • Page 28 Gbe LAN 31. USB78: USB5/USB6：(Double stack USB type A), Rear USB connector, it provides up to 2 USB2.0 ports, High-speed USB 2.0 allows data transfers up to 480 Mb/s ,support USB full-speed and low-speed signaling. ACS-2330/2332 User Manual...
  • Page 29 34. SATA_P1/SATA_P2: (2.5mm Pitch 1x2 Wafer Pin Header), Two onboard 5V output connectors are reserved to provide power for SATA devices. Pin# Signal Name +DC5V_S0 Ground Note: Output current of the connector must not be above 1A. ACS-2330/2332 User Manual...
  • Page 30 43. BUZZER1: Onboard buzzer. 44. PS2: (2.0mm Pitch 1x6 Wafer Pin Header), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard and mouse, via a dedicated cable for direct used. Pin# Signal Name ACS-2330/2332 User Manual...
  • Page 31 (DF13-20P Connector),For expand output connector,a standard 20 pin parallel port is provided to connect parallel peripherals as required. Signal Name Pin# Signal Name Ground Ground LPT_AFD- LPT_STB- LPT_ERR- LPT_D0 LPT_INIT- LPT_D1 LPT_SLIN- LPT_D2 LPT_D4 LPT_D3 LPT_D6 LPT_D5 LPT_ACK- LPT_D7 ACS-2330/2332 User Manual...
  • Page 32 COM6：RS232 RXD6 DCD6- or 422 422TX+ 422TX- or 422 or 485 485+ 485- or 485 COM6：RS232 COM6：RS232 DTR6- TXD6 or 422 422RX- 422RX+ or 422 COM6：RS232 COM6：RS232 DSR6- RTS6- COM6：RS232 COM6：RS232 CTS6- RI6- USB_5V 5V_USB1112 5V_USB1112 USB_5V ACS-2330/2332 User Manual...
  • Page 33 5V_USB0506 5V_USB0506 5V_USB0506 5V_USB0506 5V_USB0506 5V_USB0506 USB8_N USB7_N USB8_P USB7_P USB3.0/USB2.0 USB3.0/USB2.0 Ground Ground USB3_RX5_N USB3_RX6_N USB3_RX5_P USB3_RX6_P Ground Ground USB3_TX5_N USB3_TX6_N USB3_TX5_P USB3_TX6_P HDD LED Ground Ground Power LED HDD_LED ALL_PWR_LED- Power Button MIO_PSON- BUZZER+ BUZZER ACS-2330/2332 User Manual...
  • Page 34 52. PCIE_4X (option): (4x20 Pin connector), Riser Card expansion connector. Can expand support one PCIeX4 or four PCIeX1 Signal. SBC-7113HT：PCIE_4X connector in the top. SBC-7113HB：PCIE_4X connector in the Bottom. MODEL PC1E_4X SBC-7113HT SBC-7113HB Bottom Riser Card Function SBC-7113HB SBC-7113HT ACS-2330/2332 User Manual...
  • Page 35 TB-554E41 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides one PCIE X4 slot. 54. TB-554E12: TB-554E12 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides two PCIE X1 slot. ACS-2330/2332 User Manual...
  • Page 36 TB-526E11 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides one PCIE X1 slot. 56. TB-526E12: TB-526E12 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides two PCIE X1 slot. ACS-2330/2332 User Manual...
  • Page 37 57. TB-526P1: TB-526P1 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides one PCI slot. 58. TB-526P2: TB-526P2 connect to SBC-7113HB PCIE_4X connector, PCIE_4X is located at the Bottom, It provides two PCI slot. ACS-2330/2332 User Manual...
  • Page 38 TB-525E11 connect to SBC-7113HT PCIE_4X connector, PCIE_4X is located at the top, It provides one PCIE X1 slot. 60. TB-525E12: TB-525E12 connect to SBC-7113HT PCIE_4X connector, PCIE_4X is located at the top, It provides two PCIE X1 slot. ACS-2330/2332 User Manual...
  • Page 39 61. TB-525P1: TB-525P1 connect to SBC-7113HT PCIE_4X connector, PCIE_4X is located at the top, It provides one PCI slot. ACS-2330/2332 User Manual...

  • Page 40: Chapter 3 Bios Setup

    BIOS Date: 11/16/2016 17:27:53 Ver: 7113A 1.07 X64 Press 〈DEL〉or〈ESC〉to enter setup After optimizing and exiting CMOS Setup 3.2 BIOS SETUP UTILITY Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. ACS-2330/2332 User Manual...

  • Page 41: Main Settings

    Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. ACS-2330/2332 User Manual...

  • Page 42: Advanced Settings

    01 to 31 Year: 1998 to 2099 3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [S3 (Suspend to RAM) ] [Suspend Disabled] Lock Legacy Resources: [Disabled] ACS-2330/2332 User Manual...
  • Page 43 [Enabled] [Disabled] Device Settings IO=2F8h； IRQ=3； Change Settings [Auto] F75111 COM2 Config [RS-232 Mode] [RS-485 Mode] [RS-422 Mode] Serial Port 3 Configuration Serial port [Enabled] [Disabled] Device Settings IO=3E8h； IRQ=7； Change Settings [Auto] Serial Port 4 Configuration ACS-2330/2332 User Manual...
  • Page 44 [RS-232 Mode] [RS-485 Mode] [RS-422 Mode] Power Failure [Power OFF] [Power ON] [Last state] Parallel Port Configuration Parallel port [Enabled] [Disabled] Device Settings IO=378h； IRQ=5； Change Settings [Auto] Device Mode [STD Printer Mode] 3.4.3 NCT6106D HW Monitor ACS-2330/2332 User Manual...
  • Page 45 CPU C10 state Supported L1 Date Cache 32KB x 4 L1 Code Cache 32KB x 4 L2 Cache 256 KB x 2 L3 Cache 4 MB L4 Cache Not Present 3.4.5 SATA Configuration SATA Controller（S） [Enabled] [Disabled] SATA Mode ACS-2330/2332 User Manual...
  • Page 46 [Immediate] Boot option filter [UEFI and Legacy] [Legacy only] [UEFI only] Network [Do not launch] [UEFI] [Legacy] Storage [UEFI] [Do not launch] [Legacy] Video [Legacy] [UEFI] [Do not launch] Other PCI devices [UEFI] [Do not launch] [Legacy] ACS-2330/2332 User Manual...

  • Page 47: Chipset Settings

    System Agent Bridge Name Skylake SA PCIe Code Version 1.7.0.0 VT-d Supported ►Graphics Configuration ►Memory Configuration Graphics Configuration IGFX VBIOS Version 1034 Graphics Turbo IMON Current ►LCD Control Primary IGFX Boot Display [VBIOS Default] [DP] [CRT] [DVI] [HDMI] ACS-2330/2332 User Manual...

  • Page 48: Security Settings

    Active CRT [No CRT] [CRT] Memory Information Memory RC Version 1.7.0.0 Memory Frequency 2133 MHz Total Memory 4096 MB(DDR4) 1200 DIMM#0 4096 MB DIMM#1 Not Present 3.6 Security Settings ACS-2330/2332 User Manual...
  • Page 49 Advanced BIOS Features. If Security Option is set to System, you will be requested to enter the password before system boot and when entering BIOS setup; if Security Option is set to Setup, you will be requested for password for entering BIOS setup. ACS-2330/2332 User Manual...

  • Page 50: Boot Settings

    3.7 Boot Settings Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Boot Option Priorities Boot Option #1 Sets the system boot order Hard Drive BBS Priorities [P4：TFS46S3MT25064G] Disabled ACS-2330/2332 User Manual...

  • Page 51: Save & Exit Settings

    Fast Boot [Disabled] [Enabled] New Boot Option Policy [Default] [Place First] [Place Last] Hard Drice BBS Priorities 3.8 Save & Exit Settings Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] ACS-2330/2332 User Manual...
  • Page 52 Save the changes done so far as User Defaults? [Yes] [No] Restore user Defaults Restore the User Defaults to all the setup options? [Yes] [No] Boot Override P4：TFS46S3MT25064G Launch EFI Shell from filesystem device WARNING Not Found [ok] ACS-2330/2332 User Manual...

  • Page 53: Chapter 4 Installation Of Drivers

    Intel(R) HD Graphics 530 chipset driver, Realtek ALC269 HD Audio Driver, and other Driver. Installation instructions are given below. Important Note: After installing your Windows operating system, you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. ACS-2330/2332 User Manual...
  • Page 54 4.1 Intel(R) 100 Series Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select 4.1 Intel(R) 100 Series Chipset from the list Step 2. Click Next to setup program. ACS-2330/2332 User Manual...
  • Page 55 Step 3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step 4. Click Install to begin the installation. ACS-2330/2332 User Manual...
  • Page 56 Step 5. Click Restart Now to complete the setup process. You must restart the computer which has been installed for the changes to take effects. ACS-2330/2332 User Manual...

  • Page 57: Intel(R) Hd Graphics 530 Chipset Driver

    Intel(R) HD Graphics 530 Chipset Driver To install the HD Graphics 530 Chipset drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) HD Graphics 530 Chipset from the list. Step 2. Click Next to setup program. ACS-2330/2332 User Manual...
  • Page 58 Step 3. Click Next to setup program. Step 4. Click Yes for agree the license in Intel Agreement. ACS-2330/2332 User Manual...
  • Page 59 Step 5. Click Next to continue. Step 6. You can choose Accept or Decline for join the intel® product improvement program. The Intel Company may collect information about how you use your system and software. ACS-2330/2332 User Manual...
  • Page 60 Step7. Click Next to continue. Step8. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. ACS-2330/2332 User Manual...

  • Page 61: Realtek Alc269 Hd Audio Driver

    4.3 Realtek ALC269 HD Audio Driver To install the Realtek ALC269 HD Audio Driver, please follow the steps below. Step 1. Select Realtek ALC269 HD Audio Driver from the list Step 2. Click Next to continue. ACS-2330/2332 User Manual...
  • Page 62 Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. ACS-2330/2332 User Manual...
