Aplex AVS-600 User Manual

Vertical application system 8/9th gen. intel core-i and xeon e platform
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AVS-600
th
APLEX Vertical Application System 8/9
Gen. Intel
Core-I and Xeon® E Platform
User Manual
Release Date
Revision
FEB 2022
V1.0
®2022 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235,Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVS-600 and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex AVS-600

Summary of Contents for Aplex AVS-600

  • Page 1 Core-I and Xeon® E Platform User Manual Release Date Revision FEB 2022 V1.0 ®2022 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235,Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw URL:...

  • Page 2: Revision History

    Revision History Reversion Date Description 2022/02/24 Official Version AVS-600 APLEX Vertical Application System User Manual...

  • Page 3: Warning

    Electric Shock Hazard – Do not operate the machine with its back cover removed. There are dangerous high voltages inside. AVS-600 APLEX Vertical Application System User Manual...

  • Page 4: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) AVS-600 APLEX Vertical Application System User Manual...

  • Page 5: Safety Precautions

    ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. AVS-600 APLEX Vertical Application System User Manual...

  • Page 6: Table Of Contents

    3.8 Save & Exit Settings………………………..……………..…………………..78 Chapter 4 Installation of Drivers 4.1Intel® C246 Chipset……………………….…………………….……81 4.2 Intel® UHD Graphics 63 Chipset…..……………….……..…….……...83 4.3 Realtek HD Audio Driver Installation………………...……..………….86 4.4 LAN Driver………...............88 Chapter 5 Mounting Suggestions 5.1 Wall Mount….….………………...…………………..………….……………….91 AVS-600 APLEX Vertical Application System User Manual...
  • Page 7 Figure 1.1: Dimensions of AVS-600…..….……….………….………………………...10 Figure 1.2: Overview of AVS-600……….….…..……..…………………..…………….11 Figure 2.1: Motherboard ASB-M8371 Dimensions………..……………………..16 Figure 2.2: Jumpers and Connectors Location-Board Top……………………..17 Figure 2.3: Jumpers and Connectors Location-Board Bottom……………….18 Figure 5.1: Wall Mount of AVS-600……….….……..……..………..…………………91 AVS-600 APLEX Vertical Application System User Manual...

  • Page 8: Getting Started

    2 x USB2.0 (typeA) 1 x USB2.0 (Internal Type A in backside for Dongle) 2 x GbE LAN RJ-45 1 x DP 1.2 port 1 x HDMI port 2 x RS-232/422/485 (COM1/COM2, DB9, default RS-232) AVS-600 APLEX Vertical Application System User Manual...
  • Page 9 3 x SMA holes for Wi-Fi or Wireless 4G LTE/GPS antennas Mechanical Construction Titanic Metal color for the aluminum Heat-sink. Standard Black for the metal steel chassis. Mounting Desktop (default)/Wall Mount(bracket-optional) Dimensions 350 x 200 x 200 mm (LxWxH) AVS-600 APLEX Vertical Application System User Manual...
  • Page 10 10 to 90% @ 30 °C , non-condensing Operating Humidity 10 to 90% @ 40 °C , non-condensing Storage Humidity Certification CE / FCC Class A(CCC, UL, and other options by request) Operating System Microsoft® Win10 IoT, Linux 4.20.2 Support AVS-600 APLEX Vertical Application System User Manual...

  • Page 11: Dimensions

    1.3 Dimensions Figure 1.1: Dimension of AVS-600 AVS-600 APLEX Vertical Application System User Manual...

  • Page 12: Brief Description Of Avs-600

    They come with 4 x USB 3.1 Type A, 2 x USB 2.0 Type A, 2 x GbE LAN, 1 x DP, 1 x HDMI, 2 x COM ports, 1 x Line-out, and 1 x Mic-in. AVS-600 supports easy-accessible 4 x 2.5”...

  • Page 13: Chapter 2 Hardware

    Intel® Xeon E-2278GEL 2.00GHz (up to 3.90 GHz) 35W Chipset Intel®C246 Chipset Memory Support 2 x SO-DIMM (260pins) up to 64GB DDR4 2666 MHz FSB(I7-8700T/I7-8700) up to 32GB DDR4 2400 MHz FSB (I3-9100TE/I3-9100E) up to 64GB DDR4 2666 MHz FSB (I5-9500TE/I5-9500E/I7-9700TE/I7-9700E) AVS-600 APLEX Vertical Application System User Manual...
  • Page 14 4 x RS232 select header for internal MIO2 (COM3/4/5/6) Digital I/O 8-bit digital I/O by pin header (MIO1) 4-bit digital input 4-bit digital output Battery Support CR2477 Li battery by 2-pin header (1000mAh) AVS-600 APLEX Vertical Application System User Manual...
  • Page 15 1 x Pin header bi MIO1 (CPU FAN) Operating: -20℃ to 70℃ (PCBA) Storage: -40℃ to 85℃ (PCBA) Temperature Operating: -20℃ to 60℃ (for AVS-600, WT1) Operating: 0℃ to 50℃ (for AVS-600, Fanless) Humidity 10% - 90%, non-condensing, operating Power...
  • Page 16 Support Line-in by Jack 1 x 4Pin wafer for CPU FAN Board Size: 250x130mm (R1.00) 2x PCIe x4 Slot (98Pin) TB-594E42E161 1x PCIe x16 Slot (164Pin) 2x 2*4 pin power DC12V output connector AVS-600 APLEX Vertical Application System User Manual...

  • Page 17: Motherboard Dimensions

    2.3 Motherboard Dimension (units :mm) Figure 2.1: Motherboard ASB-M8371 Dimensions AVS-600 APLEX Vertical Application System User Manual...

  • Page 18: Jumpers And Connectors Location

    2.4 Jumpers and Connectors Location Figure 2.2: ASB-M8371 Jumpers and Connectors Location- Board Top AVS-600 APLEX Vertical Application System User Manual...
  • Page 19 Figure 2.3: ASB-M8371 Jumpers and Connectors Location- Board Bottom AVS-600 APLEX Vertical Application System User Manual...

  • Page 20: Jumpers Setting And Connectors

    Pin2 VCC_RTC 3. SW1-1: Switch, DC Power input setting, Power on/off button and Auto Power on switch setting. Function（DC input /DC_IN1） Pin1 ON Auto Power on (Default) Pin1 OFF Power On/Off button (option) AVS-600 APLEX Vertical Application System User Manual...
  • Page 21 If it is used in visual system of light control, please use DC24V power adapter. Note: The power consumption of power supply needs different combination tests. Power Input（DC_IN1） Pin# Pin1 DC+12V~36V Pin2 Ground Pin3 AVS-600 APLEX Vertical Application System User Manual...
  • Page 22 (2.54mm Pitch 1x4 Pin Header), FAN connector, cooling fans can be connected directly for use. Pin# Signal Name FAN_1 FAN_2 ● ● Ground ● ● ● ○ SYS_FANTACH ● ● SYS_FANPWM Note: Output power of cooling fan must be limited under 5W. AVS-600 APLEX Vertical Application System User Manual...
  • Page 23 (2.0mm Pitch 2x3 Pin Header), COM1 jumper setting, pin1~6 are used to select signal out of pin 9 of COM1 port. JP1 Pin# Function Close 1-2 COM1 Pin9 RI (Ring Indicator) (Default) Close 3-4 COM1 Pin9 =+5V (option) Close 5-6 COM1 Pin9 =+12V (option) AVS-600 APLEX Vertical Application System User Manual...
  • Page 24 TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP1 select Setting (RI/5V/12V) RS422 (option) Pin# Signal Name 422_TX- 422_TX+ 422_RX+ 422_RX- Ground AVS-600 APLEX Vertical Application System User Manual...
  • Page 25 RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP2 select Setting (RI/5V/12V) RS422 (option) Pin# Signal Name 422_TX- 422_TX+ AVS-600 APLEX Vertical Application System User Manual...
  • Page 26 Ground BIOS Config: [RS-232 Mode] [RS-485 Mode] [RS-422 Mode] 17. MIO2: (DF 13-40P Connector), for expand output connector, it provides 6x RS-232 ports, via a dedicated cable connected to AVS-600 case. Function Signal Name Pin# Signal Name Function 5V_S0 12V_S0...
  • Page 27 Corporate LAN product with support for Intel® AMT2 technology BIOS (U12/U88) Intel AMT2 Technology Remarks ○ U88 (32MB) Default ● U88 (32MB) option LAN2: (RJ45 Connector), Rear LAN port, one standard 10/100/1000M RJ-45 Ethernet port are provided. Use Intel I210AT chipset. AVS-600 APLEX Vertical Application System User Manual...
  • Page 28 Before connection, make sure that pinout of the USB cable is in accordance with that of the said tables. Any inconformity may cause system down and even hardware damages. Each USB Type A Receptacle (2 Ports) Current limited value is 2.0A. AVS-600 APLEX Vertical Application System User Manual...
  • Page 29 (SATA 7P), SATA Connectors, Four SATA connectors are provided, SATA1, SATA2, SATA3 and SATA4 transfer speed up to 6.0Gb/s. RAID controller supports: RAID0/RAID1/RAID5/RAID10. 25. M-PCIE1: (Socket 52Pin), mini PCIe socket, it is located at the bottom. It supports mini AVS-600 APLEX Vertical Application System User Manual...
  • Page 30 M.2 M-Key devices with four PCIe and SATA and SMbus signal. It also supports 2242/2280 size cards. 31. H5/H6: M2_M1 SCREW HOLES, H5 and H6 for M2_M1 card (30mm x 50.95mm) assemble. AVS-600 APLEX Vertical Application System User Manual...
  • Page 31 FAN port, one CPU FAN port, 8 GPIO ports, via a dedicated cable connected to TB-595 MIO1. Function Signal Name Pin# Signal Name Function 3P3V_S5 12V_S5 3P3V_S5 3P3V_S0 Ground Ground (F75111RG) FT_GPIO_20 FT_GPIO_24 (F75111RG) AVS-600 APLEX Vertical Application System User Manual...
  • Page 32 PCIex8 or two PCIex4 Signals. PCI express x8 supports GEN1 and GEN2 and GEN3 mode. PCI express x4 supports GEN1 and GEN2 and GEN3 mode. Model PCIE_8x1 slot ASB-M8371CB Bottom Riser Card Function ASB-M8371CB AVS-600 APLEX Vertical Application System User Manual...
  • Page 33 DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- DC_IN- AVS-600 APLEX Vertical Application System User Manual...
  • Page 34 *Note: Only support Windows 10 IoT SLB 9665 TT2.0 MODEL TPM Function ● ASB-M8371CB 40. PB-429 R1.10 (option): This board provides power for AVS-600 expansion cards. DC_IN1: (7.62mm Pitch 1x3 Pin Connector), DC 12~36V System power input connector. AVS-600 APLEX Vertical Application System User Manual...
  • Page 35 (4.20mm Pitch 2x2 Pin Connector), DC9~36V System power output connector. Pin# Power Input (ATX_DCOUT2) Pin1 Ground Pin2 Ground Pin3 DC+12~36V Pin4 DC+12~36V ATX_DCOUT3: (4.20mm Pitch 2x2 Pin Connector), DC12~36V System power output connector. Pin# Power Input (ATX_DCOUT3) Pin1 Ground AVS-600 APLEX Vertical Application System User Manual...
  • Page 36 DC+12~36V Pin4 DC+12~36V 41. TB-595 R0.20 (option): I/O Expansion Board for AVS-600, via a dedicated cable connected to ASB-M8371 MIO1. MIO1: (DF13-40P Connector), for expand output connector, it provides one CPU FAN port, one CPU FAN port, 8 GPIO ports, via a dedicated cable connected to ASB-M8371 MIO1.
  • Page 37 Pin1 OFF Pin2 OFF NC (Default) CN1: (3.5mm Pitch 1x10 Pin Connector), General-purpose input/output port, it provides 8 groups of self-programming interfaces to customers for flexible use. Pin# Function 24V_GND_GPIO GND_24V_GPIO GP_IN1 GP_IN2 AVS-600 APLEX Vertical Application System User Manual...
  • Page 38 TB-594E42E161 connects to ASB-M8371 PCIE_16x1 and PCIE_8x1 and PCIE_4x1 connectors that are located at the bottom. This transfer board provides two PCIEx4 slots and one PCIEx16 slot. Slot# Connect Signal Name 98Pin Slot PCIex4 AVS-600 APLEX Vertical Application System User Manual...
  • Page 39 Pin7 Ground Pin8 Ground ATX2: (4.20mm Pitch 2x4Pin Connector), DC12V power input connector. Pin# Power output (ATX2) Pin1 DC+12V Pin2 DC+12V Pin3 DC+12V Pin4 Ground Pin5 Ground Pin6 Ground Pin7 Ground Pin8 Ground AVS-600 APLEX Vertical Application System User Manual...

  • Page 40: Bios Setup

    After CMOS discharge or BIOS flashing operation, press [Delete] key to enter CMOS Setup. After optimizing, exits CMOS Setup. 3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. AVS-600 APLEX Vertical Application System User Manual...

  • Page 41: Main Settings

    System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. Month: 01 to 12 Date: 01 to 31 Year: 1998 to 2099 AVS-600 APLEX Vertical Application System User Manual...

  • Page 42: Advanced Settings

    3.4 Advanced Settings 3.4.1 CPU Configuration Type Intel® Core™i7-9700T CPU@2.00GHz 0x906ED Speed 2000MHz L1 Date Cache 32KBx8 L1 Instruction Cache 32KBx8 L2 Cache 256KBx8 L3 Cache 12MB L4 Cache Supported SMX/TXT Not Supported AVS-600 APLEX Vertical Application System User Manual...
  • Page 43 ►CPU – Power Management Control Boot performance mode [Max Non-Turbo Performance] Intel® SpeedStep™ [Enabled] Race To Halt (RTH) [Enabled] Intel® Speed Shift Technology [Enabled] HDC Control [Enabled] ► View/Configure Turbo Options Configure Turbo Settings AVS-600 APLEX Vertical Application System User Manual...
  • Page 44 Configurable TDP Boot Mode [Nominal] Configurable TDP Lock [Disabled] CTDP BIOS control [Disabled] Config TDP Levels Config TDP Turbo Activation Ratio 19(Unlocked) Power Limit 1 35.0W (MSR: 35.0) Power Limit 2 92.0W (MSR: 92.0) AVS-600 APLEX Vertical Application System User Manual...
  • Page 45 Timed MWAIT [Disabled] ►Custom P-state Table Energy Performance Gain [Disabled] EPG DIMM Idd3N EPG DIMM Idd3P ►Power Limit 3 Settings Power Limit 3 Override [Disabled] ►CPU Lock Configuration CFG Lock [Enabled] Overclocking Lock [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 46 [55 C] Active Trip Point 1 Fan Speed Passive Trip Point [95 C] Passive TC1 Value Passive TC2 Value Passive TSP Value Active Trip Points [Enabled] Passive Trip Poinst [Disabled] Critical Trip Points [Enabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 47 3.4.5 AMT Configuration ASF Support [Disabled] USB Provisioning of AMT [Disabled] ►CIRA Configuration ►ASF Configuration ►Secure Erase Configuration ►OEM Flags Settings ►MEBX Resolution Settings 3.4.6 Trusted Computing TPM20 Device Found Firmware Version: 5.62 Vendor: AVS-600 APLEX Vertical Application System User Manual...
  • Page 48 Lock Legacy Resources: [Disabled] [Enabled] S3 Video Repost: [Disabled] [Enabled] 3.4.8 NCT6106 Super IO Configuration Super IO Chip NCT6106 ►Serial Port 1 Configuration Serial port [Enabled] [Disabled] Device Settings IO=3F8h IRQ=4； Change Settings [Auto] AVS-600 APLEX Vertical Application System User Manual...
  • Page 49 Serial port [Enabled] [Disabled] Device Settings IO=2F0h； IRQ=6； Change Settings [Auto] ►Serial Port 6 Configuration Serial port [Enabled] [Disabled] Device Settings IO=2E0h； IRQ=6； Change Settings [Auto] WatchDog Controller Settings WatchDog Mode Select [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 50 System Temperature 2 System Temperature 3 System Temperature 4 System Duty Cycle 1 System Duty Cycle 2 System Duty Cycle 3 System Duty Cycle 4 3.4.11 Serial Port Console Redirection COMO Console Redirection [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 51 1 Keyboard, 1Mouse Legacy USB Support [Enabled] XHCI Hand-off [Enabled] USB Mass Storage Driver Support [Enabled] USB Hardware delays and time-outs: USB transfer time-out [20 sec] Device reset time-out [20 sec] Device power-up delay [Auto] AVS-600 APLEX Vertical Application System User Manual...
  • Page 52 Other PCI devices [UEFI] 3.4.14 Network Stack Configuration Network Stack [Disabled] 3.4.15 RAM DISK Configuration Disk Memory Type: [Boot Service Data] ►Create raw ►Create from file Created RAM disk list : Remove selected RAM disk(s). AVS-600 APLEX Vertical Application System User Manual...

  • Page 53: Chipset Settings

    Type C Support [Platform-FOR] 3.5.1 System Agent (SA) Configuration SA PCIe Code Version 7.0.108.64 VT-d Supported ►Memory Configuration ►Memory Thermal Configuration ►Memory Thermal Algorithms Memory RC Version 0.7.1.111 Memory Frequency 2667MHz Memory Timings (Tcl-Trcd-TRP-TRAS) 19-19-19-43 AVS-600 APLEX Vertical Application System User Manual...
  • Page 54 Probeless Trace [Disabled] Enable/Disable IED (Intel Enhanced Debug) [Disabled] Ch Hash Support [Enabled] Ch Hash Mask Ch Hash Interleaved Bit [BIT8] VC1 Read Metering [Enabled] Strong Weak Leaker Memory Scrambler [Enabled] Force ColdReset [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 55 [8MB] Aperture Size [256MB] PSMI SUPPORT [Disabled] DVMT Pre-Allocated [32M] DVMT Total GFx Mem [256M] Intel Graphics Pei Display Peim VDD Enable [Disabled] VDD Enable [Enabled] PM Support [Enabled] Cdynmax Clamping Enable [Enabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 56 ►Gen3 Endpoint Hint value for each Lane Lane 0 Lane 1 Lane 2 Lane 3 ►Gen3 RxCTLE Control Bundle0 Bundle1 DMI Link ASPM Control [LosL1] DMI Extended Sync Control [Disabled] DMI De-emphasis Control [-3.5 dB] DMI IOT [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 57 ►PEG Port Feature Configuration Detect Non-Compliance Device [Disabled] Program PCIe ASPM after opROM [Disabled] Program Static Phase1 Eq [Enabled] ►Gen3 Root Port Preset value for each Lane Lane 0 Lane 1 Lane 2 AVS-600 APLEX Vertical Application System User Manual...
  • Page 58 Lane 10 Lane 11 Lane 12 Lane 13 Lane 14 Lane 15 ►Gen3 Endpoint Hint value for each Lane Lane 0 Lane 1 Lane 2 Lane 3 Lane 5 Lane 6 Lane 7 AVS-600 APLEX Vertical Application System User Manual...
  • Page 59 Jitter Error Target VOC Dwell Time 10000 VOC Error Target Generate BDAT PEG Margin Date [Disabled] PCIe Rx CEM Test Mode [Disabled] PCIe Spread Spectrum Clocking [Enabled] 3.5.2 PCH-IO Configuration ►PCI Express Configuration AVS-600 APLEX Vertical Application System User Manual...
  • Page 60 PCIE6 Cp PCIE7 Cm PCIE7 Cp PCIE8 Cm PCIE8 Cp PCIE9 Cm PCIE9 Cp PCIE10 Cm PCIE10 Cp PCIE11 Cm PCIE11 Cp PCIE12 Cm PCIE12 Cp PCIE13 Cm PCIE13 Cp PCIE14 Cm PCIE14 Cp AVS-600 APLEX Vertical Application System User Manual...
  • Page 61 ►PCI Express Root Port 3 PCI Express Root Port 3 [Enabled] Disable Gen2 P11 Shutdown and L1 [Disabled] Controller Power gating Connection Type [Slot] ASPM2 [Auto] L1 SubStates [L1.1&L1.2] Gen3 Eq Phase3 Method [Software Search] UPTP AVS-600 APLEX Vertical Application System User Manual...
  • Page 62 [Disabled] ►Extra options Detect Non-Compliance Device [Disabled] Prefetchable Memory Reserved Memory Alignment Prefetchable Memory Alignment ►PCI Express Root Port 4 PCI Express Root Port 4 [Enabled] Disable Gen2 P11 Shutdown and L1 [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 63 Detect Timeout Extra Bus Reserved Reserved Memory Reserved I/O PCH PCIe LTR Configuration [Enabled] Snoop Latency Override [Auto] Non-Snoop Latency Override [Auto] Force LTR Override [Disabled] ►Extra options Detect Non-Compliance Device [Disabled] Prefetchable Memory AVS-600 APLEX Vertical Application System User Manual...
  • Page 64 [Disabled] SEFE [Disabled] SENFE [Disabled] SECE [Disabled] PME SCI [Enabled] Hot Plug [Disabled] Advanced Error Reporting [Enabled] PCIe Speed [Auto] Transmitter Half Swing [Disabled] Detect Timeout Extra Bus Reserved Reserved Memory Reserved I/O AVS-600 APLEX Vertical Application System User Manual...
  • Page 65 [Software Search] UPTP DPTP [Enabled] [Enabled] [Enabled] EDPC [Enabled] [Disabled] [Disabled] NFER [Disabled] [Disabled] [Disabled] SEFE [Disabled] SENFE [Disabled] SECE [Disabled] PME SCI [Enabled] Hot Plug [Disabled] Advanced Error Reporting [Enabled] PCIe Speed [Auto] AVS-600 APLEX Vertical Application System User Manual...
  • Page 66 [Disabled] Controller Power gating Connection Type [Slot] ASPM7 [Auto] L1 SubStates [L1.1&L1.2] Gen3 Eq Phase3 Method [Software Search] UPTP DPTP [Enabled] [Enabled] [Enabled] EDPC [Enabled] [Disabled] [Disabled] NFER [Disabled] [Disabled] [Disabled] SEFE [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 67 PCI Express Root Port 9 [Enabled] Disable Gen2 P11 Shutdown and L1 [Disabled] Controller Power gating Connection Type [Slot] ASPM8 [Auto] L1 SubStates [L1.1&L1.2] Gen3 Eq Phase3 Method [Software Search] UPTP DPTP [Enabled] [Enabled] [Enabled] EDPC [Enabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 68 PCI Express Root Port 13 Lane configured as USB/SATA PCI Express Root Port 14 Lane configured as USB/SATA PCI Express Root Port 15 Lane configured as USB/SATA PCI Express Root Port 16 Lane configured as USB/SATA AVS-600 APLEX Vertical Application System User Manual...
  • Page 69 PCIe Speed [Auto] Transmitter Half Swing [Disabled] Detect Timeout Extra Bus Reserved Reserved Memory Reserved I/O PCH PCIe LTR Configuration [Enabled] Snoop Latency Override [Auto] Non-Snoop Latency Override [Auto] Force LTR Override [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 70 EDPC [Enabled] [Disabled] [Disabled] NFER [Disabled] [Disabled] [Disabled] SEFE [Disabled] SENFE [Disabled] SECE [Disabled] PME SCI [Enabled] Hot Plug [Disabled] Advanced Error Reporting [Enabled] PCIe Speed [Auto] Transmitter Half Swing [Disabled] Detect Timeout AVS-600 APLEX Vertical Application System User Manual...
  • Page 71 Serial ATA Port 0 Empty Software Preserve Unknown Port 0 [Enabled] Hot Plug [Disabled] Configured as ESATA Hot Plug supported Spin Up Device [Disabled] SATA Device Type [Hard Disk Drive] SATA Port 0 DevSlp [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 72 Software Preserve Unknown Port 3 [Enabled] Hot Plug [Disabled] Configured as ESATA Hot Plug supported Spin Up Device [Disabled] SATA Device Type [Hard Disk Drive] SATA Port 3 DevSlp [Disabled] DIT0 Configuration [Disabled] AVS-600 APLEX Vertical Application System User Manual...
  • Page 73 Port 6 [Enabled] Hot Plug [Disabled] Configured as ESATA Hot Plug supported Spin Up Device [Disabled] SATA Device Type [Hard Disk Drive] SATA Port 6 DevSlp [Disabled] DIT0 Configuration [Disabled] DIT0 Value DM Value AVS-600 APLEX Vertical Application System User Manual...
  • Page 74 XDCI Support [Disabled] USB2 PHY Sus Well Power Gating [Enabled] USB Overcurrent [Enabled] USB Overcurrent Lock [Enabled] USB Port Disable Override [Disabled] Serial IRQ Mode [Continuous] State After G3 [S0 State] [S5 State] AVS-600 APLEX Vertical Application System User Manual...

  • Page 75: Security Settings

    ESC: Exit Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. 3.6.1 Administrator Password 3.6.2 User Password Type the password with up to 20 characters and then press <Enter> key. This will clear all AVS-600 APLEX Vertical Application System User Manual...
  • Page 76 ►Key Management Vendor Keys Valid Factory Key Provision Disabled ►Restore Factory Keys ►Restore To Setup Mode ►Export Secure Boot variables ►Renroll Efi Image Device Guard Ready ►Remove ‘UEFI CA’ from DB ►Restore DB defaults AVS-600 APLEX Vertical Application System User Manual...
  • Page 77 ► Key Exchange Keys |1560| 1 | Factory ► Authorized Signatures|3143| 2 | Factory ►Forbidden Signatures |3724| 77 | Factory ► Authorized TimeStamps| 0 | No Key ► OS Recovery Signatures | 0 | No Key AVS-600 APLEX Vertical Application System User Manual...

  • Page 78: Boot Settings

    F2: Previous Values F3:Optimized Defaults F4:Save and Exit ESC: Exit Version 2.20.1275. Copyright (C) 2020 American Megatrends, Inc. Setup Prompt Timeout Bootup Numlock State [Off] Quiet Boot [Disabled] Boot Option Priorities Fast Boot [Disabled] AVS-600 APLEX Vertical Application System User Manual...

  • Page 79: Save & Exit Settings

    Save Changes and Exit Save & Exit Setup save Configuration and exit? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save configuration and Reset [Yes] [No] AVS-600 APLEX Vertical Application System User Manual...
  • Page 80 Load Previous Values? [Yes] [No] Default Options Restore Default Load Optimized Defaults? [Yes] [No] Save as User Default Save configuration? [Yes] [No] Restore User Default Restore User Defaults? [Yes] [No] Boot Override ---------------------------------------------------------------------------------------------------------- AVS-600 APLEX Vertical Application System User Manual...

  • Page 81: Chapter 4 Installation Of Drivers

    DPTF Driver Installation instructions are given below. Important Note: After installing your Windows operating system, you must install Intel Chipset Software Installation Utility before proceeding with the installation of drivers. AVS-600 APLEX Vertical Application System User Manual...

  • Page 82: Intel® C246 Chipset

    ® Intel C246 Chipset To install the Intel C246 chipset driver, please follow the steps below. Step1. Select Intel C246 Chipset from the list Step2. Click Next to setup program. AVS-600 APLEX Vertical Application System User Manual...
  • Page 83 Step3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step4. Click Restart Now to finish the installation. AVS-600 APLEX Vertical Application System User Manual...

  • Page 84: Intel® Uhd Graphics 63 Chipset

    4.2 Intel® UHD Graphics 63 Chipset To install the Intel® UHD Graphics 63 Chipset, please follow the steps below. Step1. Select Intel® UHD Graphics 63 Chipset from the list. Step2. Click Next. AVS-600 APLEX Vertical Application System User Manual...
  • Page 85 Step3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step4. Read the Readme files. Click Next to continue. AVS-600 APLEX Vertical Application System User Manual...
  • Page 86 Step5. Click Next to continue. Step6. Select Yes, I want to restart this computer now. Click Finish to complete installation. AVS-600 APLEX Vertical Application System User Manual...

  • Page 87: Realtek Hd Audio Driver Installation

    Realtek HD Audio Driver To install Realtek HD Audio Driver, please follow the steps below. Step1. Select Realtek HD Audio Driver from the list. Step2. Click Next to continue. AVS-600 APLEX Vertical Application System User Manual...
  • Page 88 Step3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. AVS-600 APLEX Vertical Application System User Manual...

  • Page 89: Lan Driver

    LAN Driver To install the LAN Driver, please follow the steps below. Step1. Select LAN Driver from the list Step2. WinRAR self-extracting archive running. AVS-600 APLEX Vertical Application System User Manual...
  • Page 90 Step3. Choose I accept the terms in the License Agreement and click Next to begin the installation. Step4. Click Next to continue. AVS-600 APLEX Vertical Application System User Manual...
  • Page 91 Step5. Click Install to begin the installation. Step6. Click Finish to complete the installation. AVS-600 APLEX Vertical Application System User Manual...

  • Page 92: Chapter 5 Mounting Suggestions

    Chapter 5 Mounting Suggestions 5.1 Wall Mount 5.1.1 AVS-600 Wall Mount Figure 5.1 Wall Mount of AVS-600 AVS-600 APLEX Vertical Application System User Manual...
  • Page 93 Dodavatelem tohoto produktu jsou FCC průmyslové systémy s. r. o. Informace o cenách, dostupnosti a dalších naleznete v našem e-shopu nebo se v případě jakéhokoliv dotazu obraťe přímo na nás. FCC průmyslové systémy s.r.o. U Výstaviště 138/3, Holešovice, 170 00 Praha 7 +420 472 774 173 info@fccps.cz www.fccps.cz...
