ACS-2160 Box PC
User Manual
Release Date
Revision
Feb. 2014
V1.0
® 2014 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw
ACS-2160 User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACS-2160 and is the answer not in the manual?

Questions and answers

Related Manuals for Aplex ACS-2160

Summary of Contents for Aplex ACS-2160

  • Page 1 ACS-2160 Box PC User Manual Release Date Revision Feb. 2014 V1.0 ® 2014 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...

  • Page 2: Warning

    Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 3: Packing List

    Always disconnect power when the system is not in use. ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. ACS-2160 User Manual...

  • Page 4: Table Of Contents

    3.8 Save and Exit Settings……………............35 3.9 Exit Options..................41 Chapter 4 Installation of Drivers 4.1 Intel Chipset Driver.…………………………...………..…………………44 4.2 Intel Graphics Media Accelerator Driver...……………..………………..47 4.3 Intel(R) Network Adapter………………………………………………….50 4.4 Realtek ALC662 HD Audio Codec Driver Installation…….……….…52 Apendix Installation of Mounting 54 ACS-2160 User Manual...
  • Page 5 Figures Figure 1.1: Dimensions of the ACS-2160…………………………….…..…..7 Figure 1.2: Front View of ACS-2160..............8 Figure 1.3: Rear View of ACS-2160..............8 Figure 2.1: Mainboard Dimensions…………………………………..….…..11 Figure 2.2: Jumpers and Connectors Location_ Board Top………………...12 Figure 2.3: Jumpers and Connectors Location_ Board Bottom…………..12 ACS-2160 User Manual...

  • Page 6: Specifications

    15 W(MAX) Mechanical Construction Silver aluminum chassis Chassis Color RAL 9007 Dimensions 139.8 x 246.25 x 29.2 mm Net Weight 1.8 kg Environmental Specifications Operating Temperature -20~60 °C Storage Temperature -40~85 °C 10%~90%@ 40℃, non-condensing Storage Humidity ACS-2160 User Manual...

  • Page 7: Dimensions

    50G Half sine(11 msec. duration)/operation with SSD Drop 92cm(1 Corner, 3 Edge, 6 Surface) Certificate Meet CE / FCC Windows 32-bit XP Pro, Windows 7 32-bit, Windows CE OS Support 7.0, Fedora 14 1.2 Dimensions 1.1 Dimension of the ACS-2160 ACS-2160 User Manual...

  • Page 8: Brief Description

    The ACS-2160 works very well along with any of our Display series and it absolutely can provide an easy way to perform control and field maintenance.

  • Page 9: Installation Of Hdd

    There are two screws which connect to the chassis. Gently remove 2 screws. Step 2 Pull out the chassis after unscrewing as shown in the picture ACS-2160. Step 3 You can remove HDD by unscrewing the screw in the HDD bracket.
  • Page 10 Step 4 Draw the HDD bracket out as shown in the picture ACS-2160. Step 5 That’s how it should look after it has been installed. ACS-2160 User Manual...

  • Page 11: Chapter 2 Hardware

    Also, it features dual GbE ports, 3-COM ports and one Mini PCIE configuration, one VGA port, one HDMI port, one LVDS interface. To satisfy the special needs of high-end customers, CN1 and CN2 and CN3 richer extension functions. The product is widely used in various sectors of industrial control. ACS-2160 User Manual...

  • Page 12: Jumpers Setting And Connectors

    2.2.1 Jumpers Setting and Connectors Figure 2.2: Jumpers and Connectors Location_ Board Top Figure 2.3: Jumpers and Connectors Location_ Board Bottom ACS-2160 User Manual...
  • Page 13 Pin2 Ground Pin3 4. VGA1: (CRT 2.0mm Pitch 2X6 Pin Header), Video Graphic Array Port, Provide 2x6Pin cable to VGA Port. Signal Name Pin# Pin# Signal Name CRT_RED Ground CRT_GREEN Ground CRT_BLUE Ground CRT_H_SYN CRT_DDCDAT CRT_V_SYNC CRT_DDCCL ACS-2160 User Manual...
  • Page 14 Pin1, Pin2, Pin3, Pin4 7. RS-422: (Switch),COM1 setting, it provides selectable RS232 or RS422 or RS485 serial signal output. Function RS_422 Pin# RS232 OFF: Pin1, Pin2, Pin3, Pin4 (Default) RS422 Pin1, Pin2, Pin3, Pin4 (option) RS485 Pin1, Pin2, Pin3, Pin4 ACS-2160 User Manual...
  • Page 15 DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP1 select Setting (RI/5V/12V) BIOS Setup： Advanced/W83627UHG Super IO Configuration/Serial Port 1 Configuration【RS-232】 RS422 (option): Pin# Signal Name 422_RX+ 422_RX- 422_TX- 422_TX+ Ground BIOS Setup： ACS-2160 User Manual...
  • Page 16 COM1 RI (Ring Indicator) (default) Close 3-4 COM1 Pin9=+5V (option) Close 5-6 COM1 Pin9=+12V (option) 10. COM2: (Type DB9 Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. Pin# Signal Name ACS-2160 User Manual...
  • Page 17 I/O ports. Line Out can be connected to a headphone or amplifier. 15. USB45: USB4/USB5：(Double stack USB type A), Rear USB connector, it provides up to 4 USB2.0 ports, High-speed USB 2.0 allows data transfers up to480 Mb/s ,support USB full-speed and low-speed signaling. ACS-2160 User Manual...
  • Page 18 20. CN3 (1.27mm Pitch 2X30 Pin Header), For expand output connector, It provides four GPIO, Two USB 2.0,one PS/2 mouse，one PS/2 keyboard,two uart,one PCIe x1,one SMbus. Function Signal Name Pin# Pin# Signal Name Function 5V_S5_USB 5V_S5_USB 5V_S5_USB 5V_S5_USB ACS-2160 User Manual...
  • Page 19 DTRCOM5_CTS- GPIO24 ICH_GPIO24 ICH_GPIO13 GPIO13 GPIO26 ICH_GPIO26 ICH_GPIO27 GPIO27 Ground Ground PE1_TX_N0 PE1_TX_P0 PE1_RX_N0 PE1_RX_P0 PCIE PCIE Ground Ground CLK_100M_PE1_P CLK_100M_PE1_N PLTRST_BUF- PM_PCIE_WAKE SMBUS SMB_CLK_S SMB_DATA_S SMBUS PE1_CLKRE Ground PCIE PCIE 3P3V_S5 3P3V_S5 3P3V_S5 3P3V_S5 12V_S0 12V_S0 ACS-2160 User Manual...

  • Page 20: Bios Setup

    Advanced Chipset Boot Security Save & Exit BIOS Information Intel Reference Code BIOS Vendor American Megatrends Version Core Version 4.6.5.3 Compliancy UEFI 2.3; PI 1.2 Project Version 7106V002 Build Date and Time 12、17、2012 03:22:46 ►Intel RC Version ACS-2160 User Manual...

  • Page 21: Main Settings

    Second : 0 to 59 System Date: Set the system date, the date format is: Note that the ‘Day’ automatically changes when you set the date. Day: Month: 01 to 12 Date: 01 to 31 Year: 1998 to 2099 ACS-2160 User Manual...

  • Page 22: Advanced Settings

    [32 PCI Bus Clocks] [64 PCI Bus Clocks] [96 PCI Bus Clocks] [128 PCI Bus Clocks] [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop: [Disabled] [Enabled] PERR# Generation: ACS-2160 User Manual...
  • Page 23 S3 Video Repost: [Disabled] [Enabled] 3.4.3 CPU Configuration Processor Type Intel(R) Atom(TM) CPU N2600 EMT64 Not Supported Processor Speed 1600 MHz System Bus Speed 400MHz Ratio Status Actual Ratio System Bus Speed 400 MHz Processor Stepping 30661 Microcode Revision ACS-2160 User Manual...
  • Page 24 Active Trip Point Hi [71C] Passive Trip Point [95] Passive TC1 Value Passive TC2 Value Passive TSP Value 3.4.5 IDE Configuration SATA Port0 Not Present SATA Port1 Not Present SATA Controller(S): [Enabled] [Disabled] Configure SATA as: [IDE] ACS-2160 User Manual...
  • Page 25 [40 sec] Device power-up delay [Auto] [Manual] Mass Storage Devices： Multiplecard Reader 1 [Auto] [Floppy] [Forced FDD] [Hard Disk] [CD-ROM] 3.4.7 W83627UHG Super IO Configuration W83627UHG Super IO ch W83627UHG Serial Port 1 Configuration UART Mode Selection： [RS-232] ACS-2160 User Manual...
  • Page 26 VCC5V : +5.216 V VSB5 : +5.203 V VBAT : +3.334 V 3.4.9 Serial Port Console Redirection COM0 Console Redirection [Enabled] [Disabled] Console Redirection Settings Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Console Redirection ACS-2160 User Manual...

  • Page 27: Chipset Settings

    [Slow] C-state POPDOWN [Enabled] [Disabled] C-state POPUP [Enabled] [Disabled] 3.5 Chipset Settings Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Host Bridge Parameters ►Host Bridge ►South Bridge ACS-2160 User Manual...
  • Page 28 800 MHz(DDR3) Total Memory 2048 MB DIMM#0 Not Present DIMM#1 2048 MB Memory Frequency and Timing MRC Fast Boot [Enabled] [Disabled] Max TOLUD [Dynamic] [1GB] [1.25GB] [1.5GB] [1.75GB] [2GB] [2.25GB] [2.5GB] [2.75GB] [3GB] [3.25GB] Intel IGD Configuration ACS-2160 User Manual...
  • Page 29 [1280x800，18bit ] [1280x1024，18bit] [1366x768，18bit] [1024x768，24bit] [1280x768，24bit] [1280x800，24bit] [1280x1024，24bit] Panel Scaling [Auto] [Force Scaling] [off] [Maintain Aspect Ratio] Active LFP [LVDS] [No LVDS] [EDP] IGD Clock Source [External Clock] [Internal Clock] Fixed Graphics Memory [128MB] [256MB] ALS Support ACS-2160 User Manual...
  • Page 30 [Level 13] [Level 14] [Level 15] 3.5.2 South Bridge TPT Devices PCI Express Root Port 0 PCI Express Root Port 1 PCI Express Root Port 2 PCI Express Root Port 3 DMI Link ASPM Control [Enabled] [Disabled] ACS-2160 User Manual...

  • Page 31: Boot Settings

    Bootup Numlock State [On] Activation key. 65535(0xFFFF)means Quiet Boot [Disabled] Indef inite waiting. Fast Boot [Enabled] Skip USB [Disabled] Skip PS2 [Disabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] Option ROM Messages [Force BIOS] Interrupt 19 Capture [Enabled] ACS-2160 User Manual...
  • Page 32 Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Enabled] [Disabled] Skip VGA [Enabled] [Disabled] Skip USB [Disabled] [Enabled] Skip PS2 [Disabled] [Enabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] [Always] ACS-2160 User Manual...
  • Page 33 [UEFI and Legacy] [Legacy only] [UEFI only] Launch PXE OpROM poli [Do not Launch] [UEFI only] [Legacy only] Launch Storage OpROM [Legacy only] [Do not Launch] [UEFI only] Launch Video OpROM po [Do not Launch] [UEFI only] ACS-2160 User Manual...

  • Page 34: Security Settings

    F4:Save and Exit ESC Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends , Inc. 3.7.1 Administrator Password 3.7.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all ACS-2160 User Manual...

  • Page 35: Save And Exit Settings

    Enter Go to sub screen General Help F10 Save and Exit ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Note: Due to limited address length of BIOS, only a portion of panel parameters are listed in ACS-2160 User Manual...
  • Page 36 ► Video Function Configuration ESC Exit V02.61 © Copyright 1985-2006 American Mega trends , Inc. Memory Remap Feature: [Enabled] [Disabled] Memory Hole: [Disabled] [15MB-16MB] Initate Graphic Adapter: Select which graphics controller to use as the primary boot device. [IGD] [PCI/IGD] ACS-2160 User Manual...
  • Page 37 ↑↓ Select Item [VBIOS-Default] +- Charge option Backlight Control Level [Level 5] F1 General Help Backlight Control Mode [DC] F10 Save and Exit Backlight Image Adaptation ESC Exit [VBIOS-Default] V02.61 © Copyright 1985-2006 American Mega trends , Inc. ACS-2160 User Manual...
  • Page 38 [1024x 768 24bit 2ch] [1440x900 24bit 2ch] [1600x900 24bit 2ch] [1680x1050 24bit 2ch] [1920x1080 24bit 2ch] Backlight Control Support [VBIOS-Default] [Both BLC & BIA Disabled] [BLC Enabled] Backlight Control Control: [Level5] [Level0] [Level1] [Level2] [Level3] [Level4] [Level6] [Level7] ACS-2160 User Manual...
  • Page 39 Boot Override F1 : General Help MultipleCard Reader 1.00 F2: Previous Values SATA PM:*** … F3:Optimized Defaults Launch EFI Shell from filesystem device F4:Save and Exit ESC Exit Version 2.15.1226. Copyright (C) 2012 American Megatrends , Inc. ACS-2160 User Manual...
  • Page 40 Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? [Yes] [No] Restore user Defaults Restore User Defaults Restore User Defaults? [Yes] [No] Launch EFI Shell from filesystem device WARNING Not Found [ok] ACS-2160 User Manual...

  • Page 41: Exit Options

    F10 key can be used for this operation) [OK] [Cancel] Discard Changes and Exit: Discard Changes and Exit setup? ESC key can be used for this operation) [OK] [Cancel] Discard Changes: Discard changes? F7 key can be used for this operation) [OK] [Cancel] ACS-2160 User Manual...
  • Page 42 Load Optimized Defaults: Load Optimized Defaults? F9 key can be used for this operation) [OK] [Cancel] Load Fail-Safe Defaults: Load Fail-Safe Defaults? F9 key can be used for this operation) [OK] [Cancel] ACS-2160 User Manual...

  • Page 43: Chapter 4 Installation Of Drivers

    VGA driver, LAN drivers, Audio driver Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. ACS-2160 User Manual...

  • Page 44: Intel Chipset Driver

    4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) Chipset NM10 Express from the list Step 2. Click Next to setup program. ACS-2160 User Manual...
  • Page 45 Step 3. Read the license agreement. Click Yes to accept all of the terms of the license agreement. Step 4. Click Next to continue. ACS-2160 User Manual...
  • Page 46 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. ACS-2160 User Manual...

  • Page 47: Intel Graphics Media Accelerator Driver

    To install the VGA drivers, follow the steps below to proceed with the installation. 1. Step 1.Select Intel(R) VGA Chipset Driver. Step 2. Select Automatically run WinSAT and enable the Windows Aero desktop theme (if supported). Click Next. ACS-2160 User Manual...
  • Page 48 Step 3. Click Yes. Step 4. Click Next. ACS-2160 User Manual...
  • Page 49 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish, then remove any installation media from the drives. ACS-2160 User Manual...

  • Page 50: Intel(R) Network Adapter

    4.3 Intel (R) Network Adapter To install the Intel (R) Network Adapter device driver, please follow the steps below. Step 1. Select Realtek RTL8111D Driver. Step 2. Click Next to continue. ACS-2160 User Manual...
  • Page 51 Step 3. Click Install to begin the installation. Step 4. Click Finish to exist the wizard. ACS-2160 User Manual...

  • Page 52: Realtek Alc662 Hd Audio Codec Driver Installation

    4.4 Realtek ALC662 HD Audio Codec Driver Installation To install the Realtek ALC662 HD Audio Codec Driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Driver from the list Step 2. Click Next to continue. ACS-2160 User Manual...
  • Page 53 Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. ACS-2160 User Manual...

  • Page 54: Apendix Installation Of Mounting

    Appendix A: Installation of Mounting Step 1 Prepare your display, VESA 75x75 or VESA 100x100. Rear and Front side of conversion (transfer) kit, supporting VESA 75 and 100. ACS-2160 User Manual...
  • Page 55 Screw the conversion (transfer) kit by VESA 75 or 100. Step 3 Attach 2160 to conversion (transfer) kit. Step 4 Be sure to fit the mounting holes, and screw it tight. This is how it looks like when finished. ACS-2160 User Manual...
  • Page 56 This is how it looks like when finished. ◎When adding a stand, please remember to screw it tight. ACS-2160 User Manual...
