Digital Watchdog MEGApix Ai DWC-XSBE05Li User Manual page 43

Setup - Network Setup
RTSP Information
1
2
3
4
5
6
7
Target Stream - Select the stream you want to set.
1
Time out - Set, in seconds, the time limit for the RTSP stream to disconnect. The RTSP time-out is disabled by
2
default.
RTSP Options - Check the box to include audio and/or metadata with the RTSP stream.
3
QoS Setting - Set the quality of service to ensure data transfer performance. Select from 0~255. The function
4
is disabled by default.
RTP Multicast - Check RTP Multicast Start/Stop. RTP multicast is disabled by default.
5
To activate RTP Multicast:
1. Click on the "Start" button to enable.
2. Enter an IP address, port for video stream control, and packet TTL information for the RTP Multicast.
3. Click 'Apply' to save all settings.
Users can set separate RTP multicasts for each stream.
Click 'Apply' to save all settings.
6
Click this button after completing the setup for each channel.
The table shows all active RTP settings.
7
