Set up - Video & Audio Set up
Video Configuration
1
2
3
4
5
Live Video Channel Set up - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the camera's
performance will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alphanumeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
1st stream 3840x2160, 2592x1944, 2560x1440, 1920x1080
2nd stream
800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360,
3rd stream
352x288, 352x240
1st stream
2592x1944, 2560x1440, 1920x1080
2nd stream 800x600, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360,
3rd stream
352x288, 352x240
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different, although the same codecs were set up.
4K Cameras
5MP Cameras
