Installation -
Installation
Waterproof cap installation:
The waterproof cap set comes with two rubber rings. Use the rubber ring best sized for your network cable's
diameter.
NOTE:
Cables with ø4.5mm to ø5.5mm thickness should use the black rubber ring. Cables over ø5.5mm in thickness
should use the white rubber ring.
NOTE:
To ensure moisture seal, make sure the o-ring
use of an outdoor rated sealer is recommended.
is in place between
c
and
d
10
. In extreme environments
e
