LCD Functions Continued
4. Menu Mode Summary
The menu selections for the various menu modes are displayed in the structure below�
A. OPERATION
1� PRESSURE
• PSI (Default setting)
• BAR
• MPa
2� TORQUE
• Lb� ft� (Default setting)
• Nm
TORQUE (AUTOCYCLE MODE)
• ON
• OFF (Default setting)
• EXIT
B. CLEAR DISPLAY
1� ZERO DISPLAY
C. LCD BACKLIGHT
1� LOW
2� MEDIUM
3� HIGH (Default setting)
4� EXIT
D. LCD HEATER
1� LOW (Default setting)
2� MEDIUM
3� HIGH
4� EXIT
© SPX FLOW, Inc.
E. FAULTS
F. DIAGNOSTIC
1� RUN SYSTEM TEST
2� EXIT
G. HISTORY
1� MOTOR RUN TIME
2� POWER DISRUPTIONS
3� POWER UP CYCLES
4� BRUSH INSPECTIONS
5� BRUSH REPLACEMENTS
6� POWER ON
7� HIGH PRESSURE
8� OIL REPLACEMENTS
9� TOTAL FAULTS
10� "A" SOLENOID
11� "B" SOLENOID
12� EXIT
H. FACTORY RESET
• PRESS ENTER TO SET DEFAULT VALUES
(NOTE: THIS DOES NOT CLEAR HISTORY OR
FAULTS DATA)
I. EXIT
