Connections and connector pin assignments

Connections for
robot controls to
Robacta FB
8I_8O (Robacta
CTC)
Connections to Robacta FB 8I_8O
Connections for
robot controls
on the outside of
Robacta TX, TX
10i, TX/i TWIN
34
(1)
(2)
(1) Supply connection +24 V AIDA
for supplying the fieldbus coup-
ler and the fieldbus terminals
(2) Standard I/O 1 connecting
plug
for connecting to Robacta CTC
(3) Profinet connection RJ 45 AI-
(3)
DA
(4)
(4) Profinet connection RJ 45 AI-
DA
(1) Supply connection +24 V AIDA
for supplying the bus coupler
and the field bus terminals
(1)
(2) Profinet connection RJ 45 AI-
DA
(3) Profinet connection RJ 45 AI-
(2)
DA
(3)
