Tool use

read section titled "Safety Warnings" before using tool.
2
1
Do not load with trigger depressed.
Use only genuine SENCO fasteners (see Fastener Specifications).
1
2
WarNiNG: These tools are not required to have a workpiece contact. uSe CauTiON, as these tools will
Clearing Jams:
Should a fastener jam occur, disconnect air supply.
1
2
lOaDiNG THe TOOl:
➀ Place strip of fasteners into magazine with points resting on fastener guide.
➁ Push rail forward until it latches.
NOTe: Make sure the arrow printed on the fastener is pointing toward the the nose of the
tool.
TO Drive faSTeNerS:
➀ Position tool against work surface.
3
drive a fastener when the trigger is pulled.
① Push latch and slide rail open.
② Remove fasteners.
Remove jammed fastener.
If you are still unable to remove jammed fastener, use the on-board wrench to undo the
bottom two front screws and remove the front plate for better access to the jammed
fastener.
WarNiNG: Before removing the front plate, disconnect air and make sure the
magazine is OPeN. removing the front plate with the magazine ClOSeD could cause
fasteners to be ejected under pressure.
Push rail forward until it latches.
This tool is equipped with a secondary trigger.
➁ Using your middle finger, pull secondary trigger clear of
primary trigger.
③ Using your first finger, pull the primary trigger to actuate
the tool.
NOTe: Order of operation is important.
