10-pin DAP2 to 22-pin ERF8 DAP2 Converter

A converter connecting at the end of the 10-pin 1.27 mm DAP debug cable is available for Infineon
22-pin ERF8 Aurix pinout. This converter must be ordered separately.
The following pinout is valid on the target side:
Signal Dir-
Signal Description
ection
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Ground
Not Connected
Not Connected
Signal Direction is described from the BlueBox perspective.
When initially connecting the BlueBox to a target, ensure the debug adapter pinout
matches the Target connector to avoid potential hardware failure.
This debug adapter features resettable fuses on pins 2, 4, 5, 6, 10, 11, 12, 17 and 22. These fuses
protect debug signals against overcurrent and cycle back to a conductive state after the excessive
current fades away.
The debug adapter connects to the target via a 22-pin ERF8 connector, Samtec ASP-137971-02.
The target must have populated a matching part, for example Samtec ASP-137969-01, Samtec
Series ERF8, Rugged High Speed Socket.
Ordering code
IA10PINDAP22PINSAM
Signal
Pin
NC
NC
GND
NC
NC
GND
11
NC
13
NC
15
GND
17
NC
19
NC
21
22-pin ERF8 AURIX target pinout
Pin
Signal
1
2
Vref
3
4
DAP0
5
6
DAP1
7
8
NC
9
10
DAP2
12
nTRST
14
NC
16
NC
18
NC
20
NC
22
RESET
Signal Description
Reference Voltage
DAP Clock
DAP Data pin
Not Connected
Optional 2nd Data pin
JTAG
Not Connected
Not Connected
Not Connected
Not Connected
Reset
www.tasking.com
Signal Dir-
ection
I
O
I/O
I/O
O
I/O
