2.1

Charger socket

This socket should only be used for charging or locking the wheelchair. Do not
connect any type of programming cable into this socket. This socket should
not be used as a power supply for any other electrical device. Connecting
other electrical devices may damage the control system or affect the
wheelchair's EMC (electromagnetic compatibility) performance.
IMPORTANT! Use only the supplied battery charger
2.2

Jack sockets

The external on/off switch jack
system using an external device such as a buddy button.
The external profile switch jack
external device, such as a buddy button. To change the profile while driving,
simply press the button.
8 - Power Platform Joystick Module for R-net
allows the user to turn on or off the control
allows the user to select profiles using an
