2.6.2

Battery indicator

The battery level is displayed as follows:
Green 45–100%
Yellow 25–44%
Red 0–24%
The battery bar flashes when it changes from green to yellow and between
yellow levels. It flashes repeatedly at red level.
The battery level is also shown in percentage to the right of the battery bar.
The percentage changes in steps of five.
When the levels are lighting up incrementally, the wheelchair is being charged.
The wheelchair cannot be driven until the charger is disconnected and the
control system may need to be turned off and on again.
