2.3
Buttons and paddle switches
On the control panel there is a total of 5 buttons and 2 paddle switches.
2.3.1
Power, mode and profile paddle
The paddle switch is used to turn on or off the control system.
Push the paddle switch forward to turn on the power.
Pull the paddle switch rearward to turn off the power.
The paddle switch can also be used to scroll through the available profiles and
modes. Push the paddle forward to scroll through the available profiles and
modes.
If your panel is equipped with an early version of the toggle switch as shown in
the figure, follow the description below.
Pull the paddle switch rearward to turn on or off the power.
The paddle switch can also be used to scroll through the available profiles and
modes. Push the paddle forward to scroll through the available profiles and
modes.
0.0
km/h
18 km
Outdoor
12:00
0.0
km/h
18 km
Outdoor
Power Platform Joystick Module for R-net - 9
