2.6

Display

The status of the control system is shown on the display. The control system
is on when the display is backlit.
2.6.1

Screen symbols

The R-net drive screen has common components that always appear, and
components that only appear under certain conditions.
Profile name
Left turn signal and leg rest tilt
Maximum speed indicator
Hazard lights and seat lift
Battery indicator
Clock
Lights and backrest tilt
Current speed or limitations in seat mode
Right turn signal and seat tilt
20 - Power Platform Joystick Module for R-net
45%
12:00
0.0
km/h
18 km
Outdoor
