TASKING iSystem ST SPC58 Hardware User Manual page 12

P2: Power supply configuration
EA Power supply is configured via the unshrouded 26-pin 2.54 mm header (P2).
Signal direction
Not connected
Target
Target VDD_HV_ADV_S
Target VDD_HV_ADR_C
Target VDD_HV_IO_MAIN
Target
Target VDD_HV_IO_FLEX
Not connected
Not connected
Not connected
Ground
Ground
Ground
Refer to the microcontroller user's manual for more details which power supply designation in
the above table belongs to which power supply.
By default, all jumpers are set and connect target power supply coming from the target to the
microcontroller residing on the Emulation Adapter. In principle, pins 3-4, 5-6, 7-8, 9-10, 11-12 and
13-14 must be bridged only but for the convenience and ease of use all jumpers are set, except
for pins 25-26. Pin 26 is the polarizer key preventing incorrect connection of the IEA-PS power
supply, when being connected.
If a different power source is to be used (e.g., in case of a standalone operation), all jumpers
must be removed and power source must be applied to:
·
CVDD_HV_OSC (pin 4),
·
CVDD_HV_ADV (pin 6),
·
CVDD_HV_ADR_S (pin 8),
·
CVDD_HV_IO_MAIN (pin 10),
The EA comes delivered together with the IEA-PS emulation adapter power supply, which simply
plugs into the P2 header row, providing the necessary power supply for Emulation Adapter stan-
dalone operation. Double check that the power supply is configured properly for this particular
Emulation Adapter.
Signal
NC
VDD_HV_OSC
VDD_HV_FLA
NC
NC
NC
GND
GND
GND
P2 Signal description
Pin Pin
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
·
CVDD_HV_FLA (pin 12),
·
CVDD_HV_IO_FLEX (pin 14),
·
GND (pins 22, 24, 26) signals.
Signal Signal direction
NC Not connected
CVDD_HV_OSC Emulation device
CVDD_HV_ADV_S Emulation device
CVDD_HV_ADR_C Emulation device
CVDD_HV_IO_MAIN Emulation device
CVDD_HV_FLA Emulation device
CVDD_HV_IO_FLEX Emulation device
NC Not connected
NC Not connected
NC Not connected
GND
GND
KEY
Ground
Ground
