Screws

Slot screw

The Slot screw (30mm) is used to fix the Conversion board to the Solder part. The setup be-

comes mechanically more robust.Screw the Conversion board to the Solder part first, before the

Emulation Adapter is attached on top and watch out not to break out the Solder part, e.g., if you

accidentally hit the Emulation Adapter from the side.

Short Hexagon socket screw

Short Hexagon socket screw, which comes with the Solder part, is not applicable with this Emu-

lation Adapter setup.
