Radio Information

Appendix B Radio Information
B.1 RF WWAN specifications
The Regesta Smart PLC model, equipped with the EC25 module, offers network connectivity across multiple radio
frequency bands, in line with the latest 3GPP Standards.
• LTE (3GPP Release 10),
• DC-HSPA+ (3GPP Release 8),
• HSPA+ (3GPP Release 7),
• HSUPA (3GPP Release 6),
• HSDPA (3GPP Release 5),
• and GSM, GPRS, EDGE (3GPP Release 99 with Feature Package#1).
Please note that this product does not come with antennas included. The operator has the freedom to select suitable
antennas, but it is their responsibility to ensure compliance with local regulations.
Technology: LTE.
Bands
Band 1
Band 3
Band 7
Band 20
Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+.
Bands
Band 1
Band 8
Technology: GSM / GPRS / EDGE.
Bands
EGSM 900 (900 MHz)
DCS 1800 (1800 MHz)
38
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 880–915 MHz
Rx: 925–960 MHz
Frequencies
Tx: 880–915 MHz
Rx: 925–960 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Conducted Transmit Power
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+24 dBm +1/-3 dB
+24 dBm +1/-3 dB
Conducted Transmit Power
+33 dBm ± 2 dB
+27 dBm ± 3 dB
+30 dBm ± 2 dB
+26 dBm ± 3 dB
