Lifting the protective case
Fig. 9:
To reattach the protective case, follow these instructions:
Slide the case back down into its original position:
Replacing the protective case
Fig. 10:
Lock the case in place by rotating the fastening mechanism back to a horizontal position and gently pushing down
until you hear a clicking sound.
Warning
Please ensure that the connector protective casing is installed before powering on the device.

3.3 Installing a DIN rail mount accessory

The Regesta Smart PLC can easily be mounted on a standard DIN rail using a special kit included with the device.
The kit contains all the necessary components, including 2 screws for securely attaching the rail mount to the device.
The bottom of the device features strategically placed holes that allow for flexible positioning of the DIN rail mount in
two different positions:
