A.2.7 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.2.8 RS-232 serial interface
STANDARDS
SPEED
CONNECTOR
A.2.9 RS-485 serial interface
STANDARDS
SPEED
CONNECTOR
A.2.10 Power supply specifications
NOMINAL
ABSOLUTE MAXIMUM
FREQUENCY
MAXIMUM POWER
CONNECTOR
A.2.11 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.2.12 Environmental specifications
TEMPERATURE RANGE
RELATIVE HUMIDITY
Regesta Smart PLC
V.24 115200-8-N-1-without flow control.
RJ-45 female on the connector panel.
RS-232. Asynchronous serial port with control signals.
From 300 to 115200 bps.
RJ-45 female on the connector panel (optional).
2-4 wire RS-485/RS-422 configurable via software. Bus termination configurable
via software.
From 300 to 115200 bps.
RJ-45 female on the connector panel (optional).
110-240 V AC.
85-264 V AC.
50-60 Hz
10 W
2-pole 5.08 mm pitch terminal block .
Plastic ruggedized casing with optional DIN rail mount.
140 x 80 x 190 mm.
1 Kg.
OPERATION: -20 ºC to +70 ºC
STORAGE: -25º to +70 ºC
5 % to 93 %
