4 Connecting the Router
Chapter 4 Connecting the Router
This chapter provides a detailed guide on connecting the Regesta Smart PLC router to Ethernet devices and net-
works. Within this chapter, you will find the following sections:
4.1 Power source
Note
Before connecting the router, we kindly ask you to carefully read and follow the instructions provided
below.
4.1.1 Power connector pins
The power connector is located on the connector panel of the router.
Power Supply Connector
Fig. 14:
The power connector on this router is a 5.08 mm pitch 2-wire terminal block.
There is no Phase and Neutral signal assignment.
18
•
Power source
on page 18.
•
Data connections
on page 19.
•
Installing the SIM card
on page 24.
•
RST button
on page 26.
•
Troubleshooting
on page 27.
•
Updating the software
on page 28.
Teldat S.A.
Regesta Smart PLC
