A.1.4 WWAN/RF connectors
Devices featuring this interface are equipped with two SMA female connectors.
SMA Female
A.1.5 Configuration connector
RJ45 CONFIGURATION
A.1.6 RS-232 serial port connectors
RJ45
34
PIN
Internal
External
PIN
1
2
3
4
5
6
7
8
PIN
1
2
3
4
5
6
7
8
ANT
RF in/out
GND
CONF
--
TxD (input)
GND
--
--
GND
RxD (output)
--
SERIAL
RTS
DTR
TxD
GND
CD
RxD
DSR
CTS
