Teldat S.A.
2.4.3 Underside panel
The underside panel features the router identification label and various perforations to accommodate different mount-
ing options. The following figure depicts the underside panel in detail:
Underside Panel
Fig. 6:
The following elements can be found on the underside panel:
Underside Panel elements
Item
A
B
Regesta Smart PLC
For more information about the Cellular interface, please refer to:
-
WWAN antenna connections (RF connectors)
-
WWAN/RF connectors
on page 34.
-
Wireless WAN interface
on page 36.
For more information about SIM installation for the Cellular interface, please refer to
stalling the SIM card
on page 24.
Description
Slots for the accessories to attach the device to a DIN rail mount. For further in-
formation on this accessory, please see section
The platform on which the product information label is affixed. This label contains
details such as the device model, MAC address, serial number, and more.
on page 21.
Wall mounting
on page 16.
2 Product Overview
In-
11
