2 Product Overview
PLC interface
P
Cellular interface
S
Cellular interface
C
Cellular interface
L
corresponding to
the active SIM.
Ethernet LAN inter-
LAN
face
Ethernet WAN in-
WAN
terface (RJ45)
Ethernet WAN in-
SFP
terface (SFP)
Multi standard seri-
S1
al interface 1
8
Off PRIME PLC interface is disabled, unavailable or not installed.
PRIME PLC is running but no SNs are currently detected.
Red
PRIME PLC is running and SNs are detected, but the DC
(Data Concentrator) connection is not established.
Amber
PRIME PLC is running, SNs are detected and DC connection
is working. PRIME traffic can be sent through PLC interface.
Green
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Green SIM1 operating SIM. This is processing traffic through the car-
rier for the SIM installed in this tray.
Amber
SIM2 operating SIM. This is processing traffic through the car-
rier for the SIM installed in this tray.
Red Cellular interface is unavailable, not installed or not registered.
The device has registered in the network and is establishing
Amber
the PDP connection.
The device is registered, PDP connection is established and
Green
IP traffic can be sent through the CELLULAR interface.
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off Cellular interface is not active.
Red Coverage level below -100dBm.
Amber Coverage level between -90dBm and -100dBm.
Green Coverage level above -90dBm.
Off The Ethernet LAN is currently disabled or there is no estab-
lished connection.
Green
Ethernet connection (link) established:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off The Ethernet WAN is currently disabled or there is no estab-
lished connection.
Green
Ethernet connection (link) established:
• Steady: Data is not being transferred.
• Flashing: Data is being transferred.
Off SFP is not used.
Green Ethernet SFP connection (link) is established
Off Serial port 1 is disabled or not initialized.
Green Port is in active state, shows interface activity:
• Steady: Data is not being transferred.
