Teldat S.A.
4.2.2.1 Laser information
Warning
Laser Radiation. Do not use optical instruments directly or without proper protection. CLASS 1 LASER
PRODUCT.
The SFP modules to be installed in the card socket should be class 1 devices that comply with the IEC/
EN 60825-1:2007 standard.
4.2.3 PLC connection
The Regesta Smart PLC is equipped with a Power Line Communication (PLC) interface, allowing seamless commu-
nication with compatible PLC devices through the power line. The device facilitates PLC signal injection using the
power supply connector. A LED labeled "P" indicates the connection status.
PLC and Power connector
Fig. 17:
4.2.4 WWAN antenna connections (RF connectors)
Certain models of the Regesta Smart PLC router have a pair of RF antenna connectors. The antennas are seam-
lessly attached and detached by securely screwing and unscrewing them into the designated RF1 or RF2 connectors
located on the device's connector panel.
Specifically, the RF1 connector is directly connected to the MAIN connector of the module, whereas the RF2 con-
Regesta Smart PLC
Please ensure that the SFP transceivers you choose adhere to the following regu-
lations:
• Class 1
• IEC/EN60825-1:2007 2nd Edition or any later European standard
• FCC 21 CFR Chapter 1, Subchapter J (in accordance with FDA and CDRH re-
quirements)
• 2014/30/EU EMC Directive and the 2014/35/EU Low Voltage Directive for the
application of CE marking
• UL and/or CSA registered components for use in North America
• 47 CFR Part 15, Class A
4 Connecting the Router
21
