Teldat S.A.
4.1.2 Power connector cable
Warning
The router does not come with a power cable. The estimated peak consumption for 230V AC operation
is 100 mA. You can use any cable that has a gauge equal to or greater than 0.75 mm2 (AWG18 con-
ductor) and is approved by IEC 60227.
Warning
All interconnected communication devices should be plugged into THE SAME GROUNDED POWER
OUTLET. The power outlet should also be of good quality with a resistance lower then 10 ohms.
It is highly recommended to connect all data devices to the same power source, regardless of the work-
place having an uninterrupted power supply (UPS), a regulated supply, or being independent of other
power supplies (such as lighting). This practice helps prevent malfunctions and premature aging of the
drivers and other components.
4.1.3 Connecting
4.1.4 Disconnecting
4.2 Data connections
The data connections found in the Regesta Smart PLC include.
4.2.1 LAN connection
The Regesta Smart PLC comes equipped with a 10/100/1000 BaseT Gigabit Ethernet port. This port supports auto-
matic MDI/MDIX to connect to a local area network (LAN).
Please ensure that you carefully read the labeling of this port to distinguish it from other types of ports:
Regesta Smart PLC
• Ensure that the power supply is NOT connected to either the electricity supply
or the router.
• Connect all data cables.
• Connect the power supply cable to the device.
• Install the protection case for connectors.
• Connect the power supply cable to the electricity supply.
• Disconnect the power supply from the electricity supply.
• Remove the protective case.
• Disconnect the power supply from the router.
• Disconnect the data cables.
4 Connecting the Router
19
