ENGLISH
Fujitsu VRF systems with KNX, Serial and IP support
IN775FGL00XO000 GATEWAY
USER MANUAL
Version 1.0.7
Publication date 2023-12-20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Intesis IN775FGL00XO000 and is the answer not in the manual?

Questions and answers

Related Manuals for HMS Networks Intesis IN775FGL00XO000

Summary of Contents for HMS Networks Intesis IN775FGL00XO000

  • Page 1 ENGLISH Fujitsu VRF systems with KNX, Serial and IP support IN775FGL00XO000 GATEWAY USER MANUAL Version 1.0.7 Publication date 2023-12-20...
  • Page 2 The information in this document shall therefore not be construed as a commitment on the part of HMS Networks and is subject to change without notice. HMS Networks makes no commitment to update or keep current the information in this document.

  • Page 3: Table Of Contents

    Fujitsu VRF systems with KNX, Serial and IP support Table of Contents 1. Description and Order Codes ..................... 1 2. Licensing ..........................2 3. General Information ........................ 3 3.1. Intended Use of the User Manual ..................3 3.2. General Safety Information ....................3 3.3.

  • Page 4: Description And Order Codes

    Description and Order Codes Fujitsu VRF systems with KNX, Serial and IP support 1. Description and Order Codes IN775FGL00xO000 Gateway. Modbus®, KNX®, BACnet®, and Home Automation® gateway for Fujitsu® air conditioning systems. ORDER CODE LEGACY ORDER CODE INMBSFGL016O000 IN775FGL00xO000 INKNXFGL016O000 The x stands for S or M, depending on the license you have purchased.

  • Page 5: Licensing

    Fujitsu VRF systems with KNX, Serial and IP support Licensing 2. Licensing Distribution license(s) for the IN775FGL00xO000 gateway: Maximum AC units Order Code License Indoor units Outdoor units IN775FGL00SO000 Small IN775FGL00MO000 Medium NOTE The order code may vary depending on the product seller and the buyer's location. Page 2 of 41 USER MANUAL Version 1.0.7...

  • Page 6: General Information

    General Information Fujitsu VRF systems with KNX, Serial and IP support 3. General Information 3.1. Intended Use of the User Manual This manual contains the main features of this Intesis gateway and the instructions for its appropriate installation, configuration, and operation. The contents of this manual should be brought to the attention of any person who installs, configures, or operates this gateway or any associated equipment.
  • Page 7 Fujitsu VRF systems with KNX, Serial and IP support Admonition Messages and Symbols IMPORTANT Instruction that must be followed to avoid a risk of reduced functionality and/or damage to the equipment or to avoid a network security risk. NOTE Additional information which may facilitate installation and/or operation. Helpful advice and suggestions.

  • Page 8: Overview

    Overview Fujitsu VRF systems with KNX, Serial and IP support 4. Overview This IN775FGL00xO000 gateway supports four applications. Gateway's client interface ↔ Gateway's server interface Modbus TCP and RTU KNX TP Fujitsu VRF HVAC systems BACnet/IP or MS/TP Home Automation IMPORTANT This document assumes that the user is familiar with these technologies.

  • Page 9: Inside The Package

    Figure 3. Integration of Fujitsu AC systems into BACnet installations Figure 4. Integration of Fujitsu AC systems into Home Automation installations 4.1. Inside the Package Items included: • Intesis IN775FGL00xO000 Gateway • USB Mini-B type to USB Type-A cable • Installation Sheet 4.2. Main Features •...

  • Page 10: Gateway General Functionality

    10). 4.3. Gateway General Functionality With this Intesis IN775FGL00xO000 gateway, you can easily integrate Fujitsu systems into an installation based on Modbus TCP, Modbus RTU, KNX, BACnet/IP, BACnet MS/TP, or Home Automation. To do so, the gateway acts as a server device of the installation itself, accessing all signals from each air conditioner unit and controlling the whole AC network.

  • Page 11: Hardware

    Fujitsu VRF systems with KNX, Serial and IP support Hardware 5. Hardware 5.1. Mounting IMPORTANT Before mounting, please ensure that the chosen installation place preserves the gateway from direct solar radiation, water, high relative humidity, or dust. IMPORTANT Maximum mounting height: below 2 meters (6.5 feet). NOTE Mount the gateway on a wall or over a DIN rail.
  • Page 12 Mounting Fujitsu VRF systems with KNX, Serial and IP support DIN rail mounting Fit the gateway’s top-side clips in the upper edge of the DIN rail. Press the low side of the gateway gently to lock it in the DIN rail. Make sure the gateway is firmly fixed.

  • Page 13: Connection

    Fujitsu VRF systems with KNX, Serial and IP support Connection 5.2. Connection CAUTION Disconnect all systems from power before manipulating and connecting them to the gateway. IMPORTANT Keep communication cables away from power and ground wires. 5.2.1. Gateway Connectors Figure 5. Wiring diagram Page 10 of 41 USER MANUAL Version 1.0.7...
  • Page 14 Connection Fujitsu VRF systems with KNX, Serial and IP support Connectors' wiring: IMPORTANT For all connectors, use solid or stranded wires (twisted or with ferrule). Cross-section/gauge per terminal: • One core: 0.2 .. 2.5 mm / 24 .. 11 AWG •...

  • Page 15: Connection Procedure For The Ac Unit

    Fujitsu VRF systems with KNX, Serial and IP support Connection IMPORTANT • Use SELV-rated NEC class 2 or limited power source (LPS) power supply. • Respect the polarity. • Connect the gateway's ground terminal to the installation grounding. • A wrong connection may cause earth loops and damage the Intesis gateway and/or other system equipment.

  • Page 16: Connection Procedure For Knx

    Connection Fujitsu VRF systems with KNX, Serial and IP support IMPORTANT Observe polarity. IMPORTANT Remember the characteristics of the standard EIA-485 bus: • Maximum distance of 1200 meters (0.75 miles). • Maximum of 32 devices connected to the bus. • A 120 ohms (Ω) termination resistor is needed at each end of the bus. The gateway has an internal bus biasing circuit already incorporating the termination resistor.
  • Page 17 Fujitsu VRF systems with KNX, Serial and IP support Connection • Connecting to a hub or switch of the LAN of the building: use a straight Ethernet UTP/FTP CAT5 or higher cable. NOTE Some devices detect the difference automatically and adjust themselves. NOTE When commissioning the gateway for the first time, DHCP will be enabled for 30 seconds.

  • Page 18: Connection Procedure For Home Automation

    Connection Fujitsu VRF systems with KNX, Serial and IP support 5.2.6. Connection Procedure for Home Automation Connect the Home Automation Ethernet cable to the gateway's Ethernet Port. The correct cable to use depends on where the gateway is connected: • Connecting directly to a Home Automation device: use a crossover Ethernet UTP/FTP CAT5 or higher cable. •...

  • Page 19: Gateway Layout

    Fujitsu VRF systems with KNX, Serial and IP support Gateway Layout 5.3. Gateway Layout Figure 6. Disposition of hardware elements in the gateway Plastic covers numbered in the image as ①, ②, ③, and ④ can be easily disassembled. The following sections explain each element in more detail: LEDs, DIP switches, and the push button. Page 16 of 41 USER MANUAL Version 1.0.7...

  • Page 20: Led Indicators

    LED Indicators Fujitsu VRF systems with KNX, Serial and IP support 5.4. LED Indicators Table 1. LEDs location and behavior Cover Color Description Top side LED 1 (PWR) Green Power on (not programmable) LED 2 (ERR) Blinking: Hardware error Under frontal cover ① LED 3 Green 485 Tx (RS485 for BACnet or Modbus)

  • Page 21: Push Button

    Fujitsu VRF systems with KNX, Serial and IP support Push Button 5.6. Push Button Find the push button at the top side, between the KNX and the Ethernet connectors (see the figure Disposition of hardware elements in the gateway (page 16)).

  • Page 22: Technical Specifications

    Technical Specifications Fujitsu VRF systems with KNX, Serial and IP support 5.7. Technical Specifications Plastic, type PC (UL 94 V-0). Color: Light Grey. RAL 7035 Housing Net dimensions (dxwxh): Millimeters: 90 x 106 x 58 mm / Inches: 3.5 x 4.2 x 2.3" Wall: Use M3 25 mm (1") length screws.

  • Page 23: Dimensions

    Fujitsu VRF systems with KNX, Serial and IP support Dimensions 5.8. Dimensions • Net dimensions (DxWxH) Millimeters: 90 x 106 x 58 mm Inches: 3.5 x 4.2 x 2.3" IMPORTANT Leave enough clear space to wire the gateway easily and for the subsequent manipulation of elements such as connectors, DIP switches, etc.

  • Page 24: Available Applications

    Available Applications Fujitsu VRF systems with KNX, Serial and IP support 6. Available Applications 6.1. Integration into Modbus Systems 6.1.1. Modbus Registers NOTICE This part is common for Modbus RTU and TCP. Functions to read Modbus registers: • 03 Read Holding Registers. •...
  • Page 25 Fujitsu VRF systems with KNX, Serial and IP support Integration into Modbus Systems Modbus Register name Possible values address Fan Speed Med-High (all the units) 1: Set Fan Speed Med-High Fan Speed High (all the units) 1: Set Fan Speed High Cool: 18 ..
  • Page 26 Integration into Modbus Systems Fujitsu VRF systems with KNX, Serial and IP support Register name Possible values Modbuss address formula 1: Pos1 2: Pos2 3: Pos3 Vane Position L-R (IU address[0 .. 63]+1)*100+4 4: Pos4 5: Pos5 10: Swing Temperature Setpoint (x10) °C / °F (IU address[0 ..
  • Page 27 Fujitsu VRF systems with KNX, Serial and IP support Integration into Modbus Systems Register name Possible values Modbuss address formula Consumption Yesterday Cool Wh/KWh (IU address[0 .. 63]+1)*100+37 Consumption Today Cool Wh/KWh (IU address[0 .. 63]+1)*100+39 Consumption Total Cool Wh/KWh (IU address[0 ..

  • Page 28: Integration Into Knx Systems

    Integration into KNX Systems Fujitsu VRF systems with KNX, Serial and IP support 6.2. Integration into KNX Systems 6.2.1. KNX Signals The following tables list all available KNX signals for this gateway. NOTE Physical Address: The gateway supports (P/S) and (P/I/S) format levels. NOTICE Communication object flags: •...
  • Page 29 Fujitsu VRF systems with KNX, Serial and IP support Integration into KNX Systems Object name Possible values Flags Cool: 19 .. 30°C / 66 .. 86°F Temperature Setpoint (all units) 9.001-DPT_Value_Temp (2byte) Heat: 17 .. 30°C / 63 .. 86°F 0: No disabled Remote control disablement 1.002-DPT_Boolean (1bit)
  • Page 30 Integration into KNX Systems Fujitsu VRF systems with KNX, Serial and IP support Object name Possible values Flags 0: Auto 1: Heat Control_Operation mode 2: Dry 5.x (1byte) 3: Fan 4: Cool 0: Auto 1: Heat Status_Operation mode 2: Dry 5.x (1byte) R, T 3: Fan...
  • Page 31 Fujitsu VRF systems with KNX, Serial and IP support Integration into KNX Systems Object name Possible values Flags 1: Quiet 2: Low Control_Fan speed enumerated 3: Med-Low 5.010 (DPT_Value_1_Ucount) 4: Med-High 5: High Thresholds: 25 % Status_Fan speed enumerated 50 % 5.010 (DPT_Value_1_Ucount) R, T 75 %...
  • Page 32 Integration into KNX Systems Fujitsu VRF systems with KNX, Serial and IP support Object name Possible values Flags Thresholds: 25 % Status_Vanes U-D scaling 50 % 5.001-DPT_Scaling (1byte) R, T 75 % 100 % Control_Vanes U-D pos-1 1: Set pos-1 vanes U-D 1.001-DPT_Switch (1bit) 1: Vanes U-D pos-1 active Status_Vanes U-D pos-1...
  • Page 33 Fujitsu VRF systems with KNX, Serial and IP support Integration into KNX Systems Object name Possible values Flags 0: Swing off Control_Vanes L-R swing 1.001-DPT_Switch (1bit) 1: Swing on 0: Swing off Status_Vanes L-R swing 1.001-DPT_Switch (1bit) R, T 1: Swing on Celsius: 0 ..
  • Page 34 Integration into KNX Systems Fujitsu VRF systems with KNX, Serial and IP support Object name Possible values Flags Status_Consumption 13.010-DPT_ActiveEnergy (Wh) Wh/KWh R, T Total_Heat (4byte) Status_Consumption 13.010-DPT_ActiveEnergy (Wh) Wh/KWh R, T Yesterday_Cool (4byte) Status_Consumption 13.010-DPT_ActiveEnergy (Wh) Wh/KWh R, T Today_Cool (4byte) 13.010-DPT_ActiveEnergy (Wh)

  • Page 35: Integration Into Bacnet Systems

    Fujitsu VRF systems with KNX, Serial and IP support Integration into BACnet Systems 6.3. Integration into BACnet Systems NOTICE You can see the Protocol Implementation Conformance Statement (PICS) document on 6.3.1. BACnet Objects NOTICE This part is common for BACnet MS/TP and BACnet/IP. Input object types: •...
  • Page 36 Integration into BACnet Systems Fujitsu VRF systems with KNX, Serial and IP support Table 9. Outdoor units signals Object name Possible values Object type Object instance 1: Not set 2: 100% 3: 90% 4: 80% 14-Multistate (OU[0..63]×25) + OUXX_CapacitySave_C Output 10000+0 5: 70% 6: 60%...
  • Page 37 Fujitsu VRF systems with KNX, Serial and IP support Integration into BACnet Systems Object name Possible values Object type Object instance 1: Cool 2: Heat 13-Multistate IUXX_OperationMode_S 3: Fan (U[1..64]×100 )+0 Input 4: Dry 5: Auto 1: Low 2: High 3: Med 14-Multistate IUXX_FanSpeed_C...
  • Page 38 Integration into BACnet Systems Fujitsu VRF systems with KNX, Serial and IP support Object name Possible values Object type Object instance IUXX_SetTemp_C °C / °F 1-Analog Output (U[1..64]×100 )+0 IUXX_SetTemp_S °C / °F 0-Analog Input (U[1..64]×100 )+0 IUXX_SpaceTemp_S °C / °F 0-Analog Input (U[1..64]×100 )+1 1 ..
  • Page 39 Fujitsu VRF systems with KNX, Serial and IP support Integration into BACnet Systems Object name Possible values Object type Object instance IUXX_Consumption (U[1..64]×100 ) Wh/KWh 0-Analog Input Yesterday Cool IUXX_Consumption Today (U[1..64]×100 ) Wh/KWh 0-Analog Input Cool IUXX_Consumption Total (U[1..64]×100 ) Wh/KWh 0-Analog Input Cool...

  • Page 40: Integration Into Home Automation Systems

    Integration into Home Automation Systems Fujitsu VRF systems with KNX, Serial and IP support 6.4. Integration into Home Automation Systems 6.4.1. Home Automation Signals The following tables list all available Home Automation signals for this gateway. NOTE • SET: Command used to control the indoor unit. It is sent by the client. •...
  • Page 41 Fujitsu VRF systems with KNX, Serial and IP support Integration into Home Automation Systems NOTE This index must be set according to the Unit ID Index. For outdoor units, the acNum value must be the same as the minimum indoor unit associated in the CONFIGURATION section.

  • Page 42: Late Configuration: Change The Gateway's Protocol

    Late Configuration: Change the Gateway's Protocol Fujitsu VRF systems with KNX, Serial and IP support 7. Late Configuration: Change the Gateway's Protocol Reconfiguring the gateway with a different protocol is very easy: Connect the gateway to the PC and open the configuration tool Intesis MAPS. Select the new template you need.

  • Page 43: Error Codes

    Fujitsu VRF systems with KNX, Serial and IP support Error Codes 8. Error Codes NOTE These error codes are the same for all applications. Modbus/KNX/Home BACnet value Error code Description automation value Remote controller communication error Communication error between Outdoor unit Network communication error Scan error Peripheral device communication error...
  • Page 44 Error Codes Fujitsu VRF systems with KNX, Serial and IP support Modbus/KNX/Home BACnet value Error code Description automation value Compressor start up error Trip detection Compressor motor control error Outdoor unit fan motor 1 error Outdoor unit fan motor 2 error 4-way valve error Outdoor unit coil (Expansion Valve) error Outdoor unit error...
