Integration into Modbus Systems
Register name
Vane Position L-R
Temperature Setpoint (x10)
Ambient Temperature (x10)
Temperature Limit Valid
Heat Setpoint Up Limit (x10)
Heat Setpoint Low Limit (x10)
Cool Setpoint Up Limit (x10)
Cool Setpoint Low Limit (x10)
Auto Setpoint Up Limit (x10)
Auto Setpoint Low Limit (x10)
Unit Error
Unit Error code
Filter Alarm
Filter Alarm Reset
Communication Error IU
Emergency
Allow full control from RC
Allow On/Off from RC
Allow Mode from RC
Allow Setpoint from RC
Thermo Off
Consumption Yesterday
Consumption Today
Consumption Total
Consumption Yesterday Heat
Consumption Today Heat
Consumption Total Heat
USER MANUAL Version 1.0.7
Possible values Modbuss address formula
1: Pos1
2: Pos2
3: Pos3
(IU address[0 .. 63]+1)*100+4
4: Pos4
5: Pos5
10: Swing
°C / °F (IU address[0 .. 63]+1)*100+5
Celsius: 0 .. 63.5°C
(IU address[0 .. 63]+1)*100+6
Fahrenheit: 32 .. 147°F
0: Invalid
(IU address[0 .. 63]+1)*100+7
1: Valid
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+8
Fahrenheit: 50 .. 86°F
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+9
Fahrenheit: 50 .. 86°F
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+10
Fahrenheit: 50 .. 86°F
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+11
Fahrenheit: 50 .. 86°F
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+12
Fahrenheit: 50 .. 86°F
Celsius: 10 .. 30°C
(IU address[0 .. 63]+1)*100+13
Fahrenheit: 50 .. 86°F
0: No error
(IU address[0 .. 63]+1)*100+14
1: Error
0: No Error
(IU address[0 .. 63]+1)*100+15
X-Error
0: Normal
(IU address[0 .. 63]+1)*100+16
1: Alarm
1: Reset (IU address[0 .. 63]+1)*100+17
0: No error
(IU address[0 .. 63]+1)*100+18
1: Error
0: Off
(IU address[0 .. 63]+1)*100+19
1: On
0: Allow
(IU address[0 .. 63]+1)*100+20
1: Not allow
0: Allow
(IU address[0 .. 63]+1)*100+21
1: Not allow
0: Allow
(IU address[0 .. 63]+1)*100+22
1: Not allow
0: Allow
(IU address[0 .. 63]+1)*100+23
1: Not allow
0: Thermo Off
(IU address[0 .. 63]+1)*100+24
1: Thermo On
Wh/KWh (IU address[0 .. 63]+1)*100+25
Wh/KWh (IU address[0 .. 63]+1)*100+27
Wh/KWh (IU address[0 .. 63]+1)*100+29
Wh/KWh (IU address[0 .. 63]+1)*100+31
Wh/KWh (IU address[0 .. 63]+1)*100+33
Wh/KWh (IU address[0 .. 63]+1)*100+35
