Integration into KNX Systems
Object name
Control_Operation mode
Status_Operation mode
Control_Mode Cool/Heat
Status_Mode Cool/Heat
Control_Heat mode&ON
Control_Cool mode&ON
Control_Auto mode
Status_Auto mode
Control_Heat mode
Status_Heat mode
Control_Cool mode
Status_Cool mode
Control_Fan mode
Status_Fan mode
Control_Dry mode
Status_Dry mode
Control_Fan speed enumerated
Status_Fan speed enumerated
Control_Fan speed scaling
Status_Fan speed scaling
USER MANUAL Version 1.0.7
Possible values DPT
0: Auto
1: Heat
2: Dry 5.x (1byte)
3: Fan
4: Cool
0: Auto
1: Heat
2: Dry 5.x (1byte)
3: Fan
4: Cool
0: Cool
1.100-DPT_Heat/Cool (1bit)
1: Heat
0: Cool
1.100-DPT_Heat/Cool (1bit)
1: Heat
0 %:Off
5.001-DPT_Scaling (1byte)
1 .. 100 %: On+Heat
0 %: Off
5.001-DPT_Scaling (1byte)
1 ..100 %: On+Cool
1: Set auto mode 1.001-DPT_Switch (1bit)
1: Auto mode active
1.001-DPT_Switch (1bit)
0: Auto mode not active
1: Set heat mode 1.001-DPT_Switch (1bit)
1: Heat mode active
1.001-DPT_Switch (1bit)
0: Heat mode not active
1: Set cool mode 1.001-DPT_Switch (1bit)
1: Cool mode active
1.001-DPT_Switch (1bit)
0: Cool mode not active
1: Set fan mode 1.001-DPT_Switch (1bit)
1: Fan mode active
1.001-DPT_Switch (1bit)
0: Fan mode not active
1: Set dry mode 1.001-DPT_Switch (1bit)
1: Dry mode active
1.001-DPT_Switch (1bit)
0: Dry mode not active
1: Quiet
2: Low
5.010 (DPT_Value_1_Ucount)
3: Med
4: High
1: Quiet
2: Low
5.010 (DPT_Value_1_Ucount)
3: Med
4: High
Thresholds:
0 .. 37 %
38 .. 62 % 5.001-DPT_Scaling (1byte)
63 .. 87 %
88 .. 100 %
Thresholds:
25 %
50 % 5.001-DPT_Scaling (1byte)
75 %
100 %
Fujitsu VRF systems with KNX, Serial and IP support
Flags
W
R, T
W
R, T
W
W
W
R, T
W
R, T
W
R, T
W
R, T
W
R, T
W
R, T
W
R, T
