Fujitsu VRF systems with KNX, Serial and IP support
Register name
Fan Speed Med-High (all the units)
Fan Speed High (all the units)
Temperature Setpoint (all the units)
(x10°C/°F)
Table 3. Outdoor units signals
Register name Possible values
0: Not set
1: 100 %
2: 90 %
3: 80 %
Capacity save
4: 70 %
5: 60 %
6: 50 %
7: 40 %
0: Not forced
Forced Off
1: Forced off
0: No error
Error
1: Error
0: No error
Error code
X: Error
Table 4. Individual units signals
Register name
On/Off
Operation Mode
Fan Speed
Fan Speed*
*For models allowing med-low
and med-high values
Vane Position U-D
Page 22 of 41
Possible values
1: Set Fan Speed Med-High
1: Set Fan Speed High
Cool: 18 .. 30°C / 64 .. 86°F
Heat: 16 .. 30 °C / 61 .. 86°
Modbus address formula
(OU ID[0 .. 11]+1)*25+10000+0
(OU ID[0 .. 11]+1)*25+10000+1
(OU ID[0 .. 11]+1)*25+10000+2
(OU ID[0 .. 11]+1)*25+10000+3
Possible values Modbuss address formula
0: Off
(IU address[0 .. 63]+1)*100+0
1: On
0: Auto
1: Heat
2: Dry (IU address[0 .. 63]+1)*100+1
3: Fan
4: Cool
0: Auto
1: Quiet
2: Low (IU address[0 .. 63]+1)*100+2
3: Med
4: High
0: Auto
1: Quiet
2: Low
(IU address[0 .. 63]+1)*100+2
3: Med-Low
4: Med-High
5: High
1: Pos1
2: Pos2
3: Pos3 (IU address[0 .. 63]+1)*100+3
4: Pos4
10-Swing
Integration into Modbus Systems
Modbus
R/W
address
14 T
15 T
16 T
R/W
R
R
R
R
R/W
RW
RW
RW
RW
RW
