Fujitsu VRF systems with KNX, Serial and IP support
Object name
Control_Vanes L-R swing
Status_Vanes L-R swing
Control_Temperature setpoint
Status_Temperature setpoint
Status_AC Ambient
temperature
Control_KNX ambient
temperature
Status_Unit error
Status_Unit error code
Status_Emergency
Status_FilterSign
Control_FilterReset
Control_Remote control
disablement (all)
Status_Remote control
disablement (all)
Control_On/Off Remote control
disablement
Status_On/Off Remote control
disablement
Control_Mode Remote control
disablement
Status_Mode Remote control
disablement
Control_Setpoint Remote
control disablement
Status_Setpoint Remote control
disablement
Control_Thermostat off
Status_Thermostat off
Status_Consumption Yesterday
Status_Consumption Today
Status_Consumption Total
Status_Consumption
Yesterday_Heat
Status_Consumption
Today_Heat
Page 30 of 41
Possible values DPT
0: Swing off
1.001-DPT_Switch (1bit)
1: Swing on
0: Swing off
1.001-DPT_Switch (1bit)
1: Swing on
Celsius: 0 .. 63.5°C
9.001-DPT_Value_Temp (2byte)
Fahrenheit: 32 .. 146°F
Celsius: 0 .. 63.5°C
9.001-DPT_Value_Temp (2byte)
Fahrenheit: 32 .. 146°F
Celsius: 0 .. 63.5°C
9.001-DPT_Value_Temp (2byte)
Fahrenheit: 32 .. 146°F
°C / °F 9.001-DPT_Value_Temp (2byte)
0: No error
1.005-DPT_Alarm (1bit)
1: Error
0: No Error
8.x (2 byte)
X: Error
0: Off
1.001-DPT_Switch (1bit)
1: On
0: Normal
1.005-DPT_Alarm (1bit)
1: Alarm
0: No reset
1.015-DPT_Reset (1bit)
1: Reset
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled,
1.002 DPT_Bool (1bit)
1: Disabled
0: No disabled
1.002 DPT_Bool (1bit)
1: Disabled
0: Thermostat on
1.001-DPT_Switch (1bit)
1: Thermostat off
0: Thermostat on
1.001-DPT_Switch (1bit)
1: Thermostat off
13.010-DPT_ActiveEnergy (Wh)
Wh/KWh
(4byte)
13.010-DPT_ActiveEnergy (Wh)
Wh/KWh
(4byte)
13.010-DPT_ActiveEnergy (Wh)
Wh/KWh
(4byte)
13.010-DPT_ActiveEnergy (Wh)
Wh/KWh
(4byte)
13.010-DPT_ActiveEnergy (Wh)
Wh/KWh
(4byte)
Integration into KNX Systems
Flags
W
R, T
W
R, T
R, T
W
R, T
R, T
R, T
R, T
W
W
R, T
W
R, T
W
R, T
W
R, T
W
R, T
R, T
R, T
R, T
R, T
R, T
