Integration into BACnet Systems
Table 9. Outdoor units signals
Object name Possible values
1: Not set
2: 100%
3: 90%
4: 80%
OUXX_CapacitySave_C
5: 70%
6: 60%
7: 50%
8: 40%
1: Not set
2: 100%
3: 90%
4: 80%
OUXX_CapacitySave_S
5: 70%
6: 60%
7: 50%
8: 40%
0: Reset
OUXX_ForcedOff_C
1: Set
0: Reset
OUXX_ForcedOff_S
1: Set
1: Stop
2: Lev1_Quiet
3: Lev1_Ability
OUXX_LowNoiseOp_C 4: Lev2_Quiet
5: Lev2_Ability
6: Lev3_Quiet
7: Lev3_Ability
1 .. 16 (Consult the AC user
OUXX_LowNoiseOp_S
manual)
0: Normal
OUXX_Error_S
1: Fault
1: No error
OUXX_ErrorCode_S
X: Error
Table 10. Indoor unit signals
Object name Possible values
0: Not Exist
IUXX_Exists_S
1: Exist
0: Off
IUXX_Operation_C
1: On
0: Off
IUXX_Operation_S
1: On
1: Cool
2: Heat
IUXX_OperationMode_C 3: Fan
4: Dry
5: Auto
USER MANUAL Version 1.0.7
Fujitsu VRF systems with KNX, Serial and IP support
Object type Object instance
14-Multistate (OU[0..63]×25) +
Output 10000+0
13-Multistate (OU[0..63]×25) +
Input 10000+0
(OU[0..63]×25) +
4-Binary Output
10000+0
(OU[0..63]×25) +
3-Binary Input
10000+0
14-Multistate (OU[0..63]×25) +
Output 10000+1
13-Multistate (OU[0..63]×25) +
Input 10000+1
(OU[0..63]×25) +
3-Binary Input
10000+1
13-Multistate (OU[0..63]×25) +
Input 10000+2
Object type Object instance
3-Binary Input (U[1..64]×100 )+0
4-Binary Output (U[1..64]×100 )+0
3-Binary Input (U[1..64]×100 )+1
14-Multistate
(U[1..64]×100 )+0
Output
