8: Operating the device
The device allows for connecting switch to the S1 and S2 terminals.
These may be monostable or bistable switches.
Switch buttons are responsible for managing the blind's movement.
Description:
– Switch connected to the S1 terminal
– Switch connected to the S2 terminal
General tips:
• You can perform/stop movement or change direction using
switch/es
• If you set flowerpot protection option the down movement
action will perform only to defined level
• If you control only a venetian blind position (not slats rotation)
the slats will back to their previous position (in aperture level
0-95%).
operatIng tHe DevIce
8.1: Monostable switches – click to move
Parameter no. 20 value 0
Example of the switch design:
Roller blind, Awning, Pergola or Curtain
Parameter no. 151 value 0
1 x click switch Initiate up movement to the limit position
Next click - stop
1 x click switch Initiate down movement to the limit position
2x click or Favorite position
Hold Up movement until release
Hold Down movement until release
Venetian blind
Param no.151 value 1 or 2
1 x click switch Initiate up movement to the limit position
Next click - stop
1 x click switch Initiate down movement to the limit position
2x click or Favorite position
Hold Turning slats up until release
Hold Turning slats down until release
✔ Favorite position – available
