  • Page 1 O P E R AT I N G M A N U A L FIBARO ROLLER SHUTTER 4 FGR-224 v1.1...

  • Page 2: Table Of Contents

    Table of contents 1: Important safety information 2: Description and features 2.1: Description 2.2: Main features 3: Specifications 4: Installation 4.1: Before installation 4.2: Installation 5: Adding to Z-Wave network 5.1: Adding manually 5.2: Adding using SmartStart 6: Removing from Z-Wave network 7: Calibration 8: Operating the device 8.1: Monostable switches – click to move 8.2: Monostable switches –...

  • Page 3: 1: Important Safety Information

    Failure to observe recommendations included in this manual may be dangerous or cause a violation of the law. The FIBARO ROLLER SHUTTER 4 is a device designed to control roller manufacturer, Fibar Group S.A. will not be held responsible for any blinds, awnings, venetian blinds, curtains and pergolas.

  • Page 4: 3: Specifications

    3: Specifications 4: Installation 4.1: Before installation Power supply 100-240V~ 50/60 Hz NOTE Rated load current 2A for motors with compensated power radio frequency factor (inductive loads) Connecting the device in a manner inconsistent with this of individual de- vice must be same manual may cause risk to health, life or material damage.

  • Page 5: 5: Adding To Z-Wave

    5: Adding to Z-Wave network 4.2: Installation 1. Switch off the mains voltage (disable the fuse). Adding (Inclusion) – Z-Wave device learning mode, allowing to add NOTE the device to existing Z-Wave network. 2. Open the wall switch box. If you are using yubii Home, Hc3l 3.

  • Page 6: Adding Using Smartstart

    6: Removing from Z-Wave network 5.2: Adding using SmartStart SmartStart enabled products can be added into a Z-Wave network Removing (Exclusion) – Z-Wave device learning mode, allowing to NOTE by scanning the Z-Wave QR Code present on the product with a remove the device from existing Z-Wave network. controller providing SmartStart inclusion.

  • Page 7: 7: Calibration

    7: Calibration Manual positioning of slats in venetian blinds mode 1. Set parameter 151 to 1 (90°) or 2 (180°), depending on the Calibration is a process during which a device learns the position of rotation capability of the slats. the limit switches and a motor characteristic. 2.

  • Page 8: 8: Operating The Device

    8: Operating the device 8.1: Monostable switches – click to move Parameter no. 20 value 0 The device allows for connecting switch to the S1 and S2 terminals. These may be monostable or bistable switches. Example of the switch design: Switch buttons are responsible for managing the blind’s movement. Description: –...

  • Page 9: Monostable Switches - Hold To Move

    8.2: Monostable switches – hold to move 8.3: Single monostable switch Parameter no. 20 value 1 Parameter no. 20 value 2 Example of the switch design: Example of the switch design: Roller blind, Awning, Pergola or Curtain Roller blind, Awning, Pergola or Curtain Parameter no.

  • Page 10: Bistabile Switches

    8.4: Bistabile switches 8.5: Single bistabile switch Parameter no. 20 value 3 Parameter no. 20 value 4 Example of the switch design: Example of the switch design: Roller blind, Awning, Pergola or Curtain Roller blind, Awning, Pergola or Curtain Parameter no. 151 value 0 Parameter no.

  • Page 11: Three-State Switch

    8.6: Three-state switch 8.7: Favorite position Parameter no. 20 value 5 Example of the switch design: Your device has a built-in mechanism for setting favorite positions. You can activate it by double-clicking on the monostable switch(es) connected to the device or from the mobile interface (mobile app). Favorite roller blind position You can define the favorite position of the blinds.

  • Page 12: 9: Menu

    9: Menu 10: Resetting the device to factory defaults Menu allows to perform actions. In order to use the menu: 1. Switch off the mains voltage (disable the fuse). Resetting the device to factory defaults: 2. Remove the device from the wall switch box. Reset procedure allows to restore the device back to its factory settings, which means all information about the Z-Wave controller 3.

  • Page 13: 11: Energy Metering

    11: Energy metering 12: Configuration The device allows for the energy consumption monitoring. Data is 12.1: Associations sent to the main Z-Wave controller. Measuring is carried out by the most advanced micro-controller Association (linking devices) – direct control of other devices technology, assuring maximum accuracy and precision (+/- 5% for within the Z-Wave system network.
  • Page 14 Association Group 2: „Window Covering” Switch type Switch Hold Release Window covering calibration status and command Id value. Parametr (20) Value Name Command Command Window Covering Window Calibration status name Covering id Monostable switches – click Device is not OUT_BOTTOM_1 12 (0x0C) to move calibrated...
  • Page 15 Operating mode: Venetian blind 90° (param 151 = 1) or Venetian Switch state change Switch state change Switch type blind 180° (param 151 = 2) Switch when roller is not when roller is not Parametr (20) moving moving Switch type Switch Single Click Double Click...

  • Page 16: 13: Advanced Parameters

    1 – reversed (1st button DOWN, 2nd button UP) on the controller. Outputs orientation In the FIBARO interface device configuration is available as a simple set of options in the Advanced Settings section. This parameter allows reversing the operation Description of O1 and O2 without changing the wiring (e.g.
  • Page 17 Second button – scenes sent 151. Operating mode This parameter determines which actions result This parameter allows you to adjust the in sending scene IDs assigned to them. Values operation, depending on the connected device. Description can be combined (e.g. 1+2=3 means that scenes In the case of venetian blinds, the angle of Description for single and double click are sent).

  • Page 18: 14: Z-Wave Specification

    14: Z-Wave specification 158. Virtual limit switch. The pot protection This parameter allows you to set a fixed Indicator CC - available indicators minimum level of lowering the shutter. For Description Indicator ID – 0x50 (Identify) example, to protect a flowerpot located on a windowsill.
  • Page 19 Supported Command Classes Basic CC Command Class Version Secure Command Value Mapping command Mapping value Basic Set [0xFF] Multilevel Switch Set [0xFF] COMMAND_CLASS_APPLICATION_STATUS [0x22] Multilevel COMMAND_CLASS_ZWAVEPLUS_INFO [0x5E] Basic Set [0x00] Multilevel Switch Set Switch Set COMMAND_CLASS_WINDOW_COVERING [0x6A] Start Level Change [0x00], Basic Set [0x00] to [0x63]...
  • Page 20 Protection CC Altering capabilities Protection Command Class allows to prevent local or remote control FGR-224 uses different set of Window Covering Parameter IDs of the outputs. depending on the values of the 2 parameters: • Calibration status (parameter 150), Type State Description Hint •...

  • Page 21: 15: Regulations

    0x03] obligation to notify any individual or entity. WINDOW_COVERING_REPORT [0x6A General: FIBARO and Fibar Group logo are trademarks of Fibar Group S.A. All 0x04] Lifeline Lifeline other brands and product names referred to herein are trademarks (0x00: 0x01) of their respective holders.
