8.2: Monostable switches – hold to move
Parameter no. 20 value 1
Example of the switch design:
Roller blind, Awning, Pergola or Curtain
Parameter no. 151 value 0
1 x click switch
1 x click switch
2x click or
Hold
Hold
Venetian blind
Param no. 151 value 1 or 2
1 x click switch
1 x click switch
2x click or
Hold
Hold
✔ Favorite position – available
If you hold down the switch longer than slats movement time +
additional 4 seconds (default 1,5s+4s =5,5s) the device will go limit
position. In that case releasing the switch will do nothing.
operatIng tHe DevIce
10% up movement
10% down movement
Favorite position
Up movement until release
Down movement until release
Slats rotates up by the predefined step
Slats rotates down by the predefined step
Favorite position
Up movement until release
Down movement until release
8.3: Single monostable switch
Parameter no. 20 value 2
Example of the switch design:
Roller blind, Awning, Pergola or Curtain
Parameter no. 151 value 0
1 x click Initiate movement to the limit position
Next click – stop
One more click Initiate movement to the opposite limit position
2x click Favorite position
Hold Initiate movement until release
Venetian blind
Param no. 151 value 1 or 2
1 x click Initiate movement to the limit position
Next click – stop
One more click Initiate movement to the opposite limit position
2x click Favorite position
Hold Turning slats until release
✔ Favorite position – available
