1: Important safety information
Read this manual before attempting to install the device!
Failure to observe recommendations included in this manual
!
may be dangerous or cause a violation of the law. The
manufacturer, Fibar Group S.A. will not be held responsible for any
loss or damage resulting from not following the instructions of
operating manual.
DANGER OF ELECTROCUTION!
The device is designed to operate in electrical home
installation. Faulty connection or use may result in fire or
electric shock.
All works on the device may be performed only by a qualified
and licensed electrician. Observe national regulations.
Even when the device is turned off, voltage may be present at
its terminals. Any maintenance introducing changes into the
configuration of connections or the load must be always performed
with disabled fuse.
To avoid risk of electrical shock, do not operate the device
with wet or moist hands.
Do not modify!
Do not modify this device in any way not included in this
!
manual.
Other devices
The manufacturer, Fibar Group S.A. will not be held
!
responsible for any damage or loss of warranty privileges for
other connected devices if the connection is not compliant with
their manuals.
This product is intended for indoor use only in dry locations.
Do not use in damp or wet locations, near a bathtub, sink,
!
shower, swimming pool, or anywhere else where water or
moisture are present.
CAUTION!
It is not recommended to operate all of the roller blinds
!
simultaneously. For safety reasons, at least one roller blind
should be controlled independently, providing safe escape route in
case of emergency.
Not a toy!
This product is not a toy. Keep away from children and
!
animals!
Important safety InformatIon
2: Description and features
2.1: Description
FIBARO ROLLER SHUTTER 4 is a device designed to control roller
blinds, awnings, venetian blinds, curtains and pergolas.
FIBARO ROLLER SHUTTER 4 allows precise positioning of roller
blinds or venetian blind slats. The device is equipped with energy
monitoring. It allows to control connected devices either via the
Z-Wave network or via a switch connected directly to it.
TM
2.2: Main features
• Can be used with:
» roller blinds,
» venetian blinds,
» pergolas,
» curtains,
» awnings,
» blind motors with electronic or mechanical limit switches.
• Active energy metering.
• Supports Z-Wave network Security Modes: S0 with AES-128
encryption and S2 Authenticated with PRNG-based encryption.
• Works as a Z-Wave signal repeater (all non-battery operated
devices within the network will act as repeaters to increase
reliability of the network).
• May be used with all devices certified with the Z-Wave Plus
certificate and should be compatible with such devices produced
by other manufacturers.
• Works with different types of switches; for comfort of use, it is
recommended to use switches dedicated to the roller shutter
operation (monostable, roller shutter switches).
5
i
NOTE
the device is a
security enabled
Z-Wave plus prod-
uct and a security
enabled Z-Wave
controller must
be used in order
to fully utilize the
product.
TM
DescrIptIon anD features
