7: Calibration
Calibration is a process during which a device learns the position of
the limit switches and a motor characteristic.
Calibration is mandatory in order for the device to correctly
recognize a roller blind position.
The procedure consists of an automatic, full movement between the
limit switches (up, down, and up again).
Automatic calibration using the menu
i
NOTE
1. Press and hold PROG button to enter the menu.
If you are using
yubii Home, Hc3l
2. Release button when the device glows blue.
or Hc3 Hub, you
can perform cali- 3. Quickly click the button to confirm.
bration from the
4. The device will perform the calibration process, completing full
wizard or device
cycle – up, down and up again. During the calibration the LED
settings in the
mobile app.
blinks blue.
i 5. If the calibration is successful, the LED indicator will glow green,
NOTE
if the calibration is failed, the LED indicator will glow red.
you can stop the
6. Test whether the positioning works correctly.
calibration pro-
cess at any mo-
ment by clicking
prog button or
Automatic calibration using the parameter
external keys.
1. Set parameter 150 to 3.
i
NOTE
2. The device will perform the calibration process, completing full
cycle – up, down and up again. During the calibration the LED
If the calibra-
blinks blue.
tion is failed, you
can manually set
3. If the calibration is successful, the LED indicator will glow green,
times of up and
if the calibration is failed, the LED indicator will glow red.
down movements
(parameters 156
4. Test whether the positioning works correctly.
and 157).
calIbratIon
Manual positioning of slats in venetian blinds mode
1. Set parameter 151 to 1 (90°) or 2 (180°), depending on the
rotation capability of the slats.
2. By default, time of transition between extreme positions is set to
15 (1.5 seconds) in parameter 152.
3. Turn slats between extreme positions using
• If after full cycle a blind starts moving up or down - decrease
value of parameter 152,
• If after full cycle the slats does not reach end positions -
increase value of parameter 152,
4. Repeat previous step until satisfactory positioning is achieved.
5. Test whether the positioning works correctly. Correctly
configured slats should not force the blinds to move up or down.
