8.4: Bistabile switches
Parameter no. 20 value 3
Example of the switch design:
Roller blind, Awning, Pergola or Curtain
Parameter no. 151 value 0
1x click (circuit closed)
Next click on the same
switch (circuit opened)
Venetian blind
Param no.151 value 1 or 2
1x click (circuit closed)
Next click on the same
switch (circuit opened)
❌ Favorite position – unavailable
operatIng tHe DevIce
Initiate movement to the limit position
Stop
Initiate the slats rotation then blind
movement to the limit position
Stop
8.5: Single bistabile switch
Parameter no. 20 value 4
Example of the switch design:
Roller blind, Awning, Pergola or Curtain
Parameter no. 151 value 0
1x click Initiate movement to the limit position
Next click – stop
One more click Initiate movement to the opposite limit
position
Next click - stop
Venetian blind
Param no. 151 value 1 or 2
1x click Initiate the slats rotation then blind movement
Next click – stop
One more click Initiate the slats rotation and blind movement to
the opposite direction
Next click - stop
❌ Favorite position – unavailable
