13: Advanced parameters
The device allows customizing its operation to user's needs using
configurable parameters.
The settings can be adjusted via the Z-Wave controller to which the
device is added. The way of adjusting them might differ depending
on the controller.
In the FIBARO interface device configuration is available as a simple
set of options in the Advanced Settings section.
To configure the device:
1. Go to Settings
2. Go to Devices.
3. Select the relevant device from the list.
4. Select the Advanced or Parameters tab.
5. Change the appropriate settings or values.
6. Save your changes.
Available parameters:
20.
This parameter determines with which switches
Description types and in which mode the S1 and S2 inputs
operate.
Parameter size 1B
Default value 0
0 - Monostable switches – click to move
1 - Monostable switches – hold to move
2 - Single monostable switch
Available
values
3 - Bistable switches
4 - Single bistable switch
5 - Three-state switch
aDvanceD parameters
Switch type
24. Buttons orientation
This parameter allows reversing the operation
Description
of the buttons.
Parameter size 1B
Default value 0
0 – default (1st button UP, 2nd button DOWN)
Available
values
1 – reversed (1st button DOWN, 2nd button UP)
25. Outputs orientation
This parameter allows reversing the operation
Description
of O1 and O2 without changing the wiring (e.g.
in case of invalid motor connection).
Parameter size 1B
Default value 0
0 - default (O1 – UP, O2 – DOWN)
Available
values
1 - reversed (O1 – DOWN, O2 – UP)
40. First button – scenes sent
This parameter determines which actions result
in sending scene IDs assigned to them. Values
can be combined (e.g. 1+2=3 means that scenes
Description
for single and double click are sent).
Enabling scenes for triple click disables entering
the device in learn mode by triple clicking.
Parameter size 1B
Default value 15 (All scenes active)
0 - No scene active
1 – Key pressed 1 time
Available
2 – Key pressed 2 times
values
4 – Key pressed 3 times
8 – Key hold down and key released
31
