Cascades™
I2500-1 Wood
Fireplace
Insert
Owners & Installation Manual
www.regency-fire.com
French Manual: https://bit.ly/2YuraWc
Manuel en français : https://bit.ly/2YuraWc
MODEL:
I2500-1
Tested & listed by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WN029S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-647a
01.29.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cascades I2500-1 and is the answer not in the manual?

Questions and answers
