Owners & Installation Manual
www.regency-fi re.com
MODELS: I2403M
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
919-051
07/16/13
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency I2403M
Summary of Contents for Regency I2403M
- Page 1 WOOD Fireplace Insert Owners & Installation Manual www.regency-fi re.com MODELS: I2403M Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 919-051 07/16/13 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. Keep those REGENCY FIRES burning.
-
Page 3: Table Of Contents
Installation of the Faceplate and Trim......11 Installation of the Fan/blower........12 WARRANTY Floor Protection ............13 Firebrick Assembly ............13 Warranty ..............23 Draft Control ..............13 Flue Baffl e & Secondary Air Tube Installation .....13 Door Handle ..............13 Screen Door ..............13 First Fire ..............14 Regency I2403M... -
Page 4: Safety Label
SAFETY LABEL SAFETY LABEL FORI2403M This is a copy of the label that accompanies your Regency Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
DIMENSIONS Regency I2403M... -
Page 6: Installation
fi replace re-approved by the authority having to follow instructions may result in property jurisdiction." Regency Inserts are designed to use either a damage, bodily injury or even death. Install 5.5" (140mm) or 6" (152mm) fl ue. and use only in accordance with manufactur- In order for a solid-fuel insert to be certifi... -
Page 7: Installing Your Insert
(2 per side) as shown in the diagrams. View from Rear of Insert Note: The grill has a front and rear, the holes on the front side have rounded edges and the rear holes have fl at edges. Regency I2403M... -
Page 8: Masonry And Factory Built Fireplace Clearances
Compare proposed system R of 1.231 to to R-value. Thermal Resistance: specifi ed R of 0.893. Since proposed system R = 1/k x T = 1/0.84 x .75 = 0.893. R is greater than required, the system is )(hr)( )(K) acceptable. Regency I2403M... -
Page 9: Flue Connector Bracket
Regency highly recommends the use of a full for installing solid fuel inserts in factory liner as the safest installation and provides the built fi... -
Page 10: Stainless Smoke Defl Ector Installation
WARNING: Operation of the unit with out proper installation of smoke defl ector will void warranty. Ensure defector is seated so bolts are situated at the top of the keyhole before tightening. Regency I2403M... -
Page 11: Installation Of The Faceplate And Trim
fl ange on the side shields and the angle iron bar on the insert top. The faceplate trim may be installed to the edge of the faceplate at this time. Faceplate Assembly Regency I2403M... -
Page 12: Installation Of The Fan/Blower
1) Align the fan support with the offset clip cause improper and dangerous on the bottom of the ashlip. 4) Push the Regency logo plate into the two holes in the front bottom left corner of the operation. 2) Slide the supports into the clips. The tension fan. -
Page 13: Floor Protection
Use a pair of vise grips or pliers and tap it into place with a hammer. A tighter fi t will Handle at 10 o'clock position. Regency I2403M... -
Page 14: First Fire
fi re at a When operated with doors open the 7) Your Regency Insert can be very hot. You moderate level. manufacturer supplied screen must may be seriously burned if you touch the be used. -
Page 15: Wood Storage
fi rst year of use and at seasoning process. least once a year thereafter or when a signifi cant layer of creosote has accu- mulated (3mm / 1/8" or more) it should be removed to reduce the risk of a chimney fi re. Regency I2403M... -
Page 16: Maintenance
fi nish and void the warranty. GLASS REPLACEMENT Your Regency Insert is supplied with 5 mm. DOOR GASKET Neoceram ceramic glass (Part #846-304) that will withstand the highest heat that your unit will If the door gasket requires replacement, 7/8"... -
Page 17: Parts List
PARTS LIST MAIN ASSEMBLY & OPTIONS I2403M Part # Description Part # Description Part # Description 850-152 Door Assy - Large Gold 42) 163-932 Convection Grill - Gold (Opt) 142-917 Fan Assembly 850-151 Door Assy - Large Black 163-930 Convection Grill - Blk (Opt) -
Page 18: Faceplates
PARTS LIST FACEPLATES I2403M Part # Description 140-911 Faceplate & Trim Set - Regular 180-570 Black Trim Regular (set of 3) 285) * Trim Right Regular 286) * Trim Top Regular 287) * Trim Left Regular 288) * Faceplate Side Regular... -
Page 19: Brick Panels
PARTS LIST BRICK PANELS I2403M Part # Description 180-960 Firebrick - Complete Set 70) 902-111 Brick Regular Full Size: 1-1/4" x 4-1/2" x 9" 75) * Brick Partial: 1-1/4 x 4-1/2" x 2" 76) * Brick Partial: 1-1/4" x 2" x 9"... - Page 20 NOTES Regency I2403M...
- Page 21 NOTES Regency I2403M...
- Page 22 NOTES Regency I2403M...
-
Page 23: Warranty
The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 24 Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial No.: __________________________________________________________ Regency and Classic are trademarks of FPI Fireplace Products International Ltd. Printed in Canada © Copyright 2013, FPI Fireplace Products International Ltd. All rights reserved.
