400-0837 L2 1 0 W
400-0837 L2 1 0 W
Notes:
Meets NACE MR – 01 – 75/ISO 15156 recommendations.
(1)
(1a) Meets NACE MR103
(2) Silicone Oil is not recommended for Oxygen (O2) or Chlorine service.
(3) Not applicable for vacuum service.
(4) Drain/Vent not applicable.
O'Ring should be Viton or Kalrez.
(5)
(6) Maximum pressure 24 bar.
(7) Inert fill fluid (Fluorolube) is not available for Monel diaphragm.
(8) Explosion proof approvals do not apply to adapter, only to transmitter.
(9) Attention, check corrosion rate for the process, tantalum plate 0.1 mm, AISI
316L extension 3 to 6mm.
(10) Degrease cleaning not available for carbon steel flanges.
0 I B A 0
0 I B A 0
1 I 0 1
COD Type and Flange Material (High Side)
I 316L SST (Integral Flange)
H Hastelloy C276 (Integral Flange)
User's specification
Z
COD Flange Facing Finish
0
1
2
1 P 0 1
I 0
(11) Only enable for flange ASME B16.5.
(12) For this option consult Smar.
(13) Effective for hydrogen migration processes
(14) Inert Fluid: Oxygen Compatibility, safe for oxygen service.
(15) Not applicable for saline atmosphere.
(16) Not available for flange JIS B2220.
Continued from Sensor Main Code
Raised Face – RF (Default)
Flat Face – FF
Ring Joint Face – RTJ (Only available for ASME standard flange)
COD Extension Length
0 0 mm (0")
1 50 mm (2")
2 100 mm (4")
Note: Extension Material 316L SST.
3 150 mm (6")
4 200 mm (8")
Z User´s specifications
COD Diaphragm Material
A 304L SST / 304L SST
L 316L SST /316 SST
H Hastelloy C276 / 316 SST
M Monel 400 / 316 SST (9)
T Tantalum / 316 SST (9)
X Titanium / 316 SST (9)
316L SST with Teflon Lining (For 2"and 3")
1
2 316L SST Gold plated
3 Tantalum with Teflon Lining
COD Fill Fluid
1 Silicone DC-200/20 Oil (2)
2 Fluorolube MO-10 Oil (3) (7) (14)
3 Silicone DC704 Oil (2)
4 Krytox Oil (14)
N Neobee M20 Propylene Glycol Oil
T Syltherm 800 Oil
Z User´s specifications
TYPICAL MODEL NUMBER
1 L 1
Maintenance
(11)
5.17
