Index Table of Contents INDEX OF FIGURES....................IV INDEX OF TABLES ....................IV INTRODUCTION ......................V INSTALLATION ......................1.1 NETWORK WIRING ..........................1.1 PHYSICAL SIGNALING........................1.2 TOPOLOGIES ............................1.2 BUS TOPOLOGY ..........................1.2 TREE TOPOLOGY ..........................1.2 DAISY CHAIN TOPOLOGY........................1.5 POINT-TO-POINT TOPOLOGY......................1.6 FIELDBUS NETWORK COMPONENTS ....................1.6 POWER SUPPLY ..........................1.6 DEVICE QUANTITY ..........................1.7 TERMINAL BLOCKS ..........................1.7... - Page 4 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual MAINTENANCE PROCEDURES ................4.1 GENERAL.............................4.1 RETURNING SMAR PRODUCTS AND/OR MATERIALS ..............4.1 Index of Figures FIGURE 1.1 – HOUSING ROTATION......................1.1 FIGURE 1.2 – WIRING BLOCK ........................1.1 FIGURE 1.3 – WIRE MEDIA ........................1.2 FIGURE 1.4 –...
-
Page 5: Introduction
Get the best results of the Foundation Fieldbus Series 302 by carefully reading these instructions. 1 Users of SMAR CD600 multi-loop digital controller should be familiar with this, since it was implemented several years ago. 2 For more details, Please look at Function Blocks Instruction Manual... - Page 6 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual WARNING This Manual is compatible with version 3.XX, where 3 denote software version and XX software release. The indication 3.XX means that this manual is compatible with any release of Series 302 field devices with software version 3.
-
Page 7: Installation
Section 1 Installation Network Wiring Access the wiring block by removing the Electrical Connection Cover. This cover can be locked closed by the cover locking screw to release the cover, rotate the locking screw clockwise. (See Figure 1.1 - Housing Rotation). GEREM101.CDR Figure 1.1 - Housing Rotation Cable access to wiring connections is obtained by one of the two outlets. -
Page 8: Physical Signaling
Non Bus-Powered (Field devices gets power over separate wires) GEREM103.CDR Figure 1.3 - Wire Media A Smar fieldbus System consists of several fieldbus networks. A fieldbus network may consist of several segments. Several fieldbus devices may be connected to each segment... -
Page 9: Topologies
Installation GEREM104.CDR Figure 1.4 - Fieldbus Network Topologies Almost any topology is possible. It is mainly a matter of where the terminator is connected. • Bus • Tree (Chicken-foot) • Daisy-chain • Point-to-point As far as fieldbus is concerned that are all alike, what matters is the placement of the terminator. -
Page 10: Bus Topology
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Bus Topology Devices are distributed along the trunk connected through spurs. A spur may be up to 120 m long. GEREM105.CDR Figure 1.5 - Bus Topology Tree topology A main trunk runs from the control room into the field where it branches out to the individual devices. -
Page 11: Daisy Chain Topology
Installation Daisy Chain Topology Cable is chained from device to device. It is important to ensure that a device may be disconnected without other devices also being disconnected. Therefore make sure to use same conduit for ”in” and “out” wires in order to enable removal of device without interrupting bus. -
Page 12: Point-To-Point Topology
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Point-to-Point Topology Only two devices connected to each other. This topology does not take advantage of the multidrop capability of fieldbus. Typically used only on workbench with device and notebook computer. -
Page 13: Device Quantity
Installation Device Quantity Rules of thumb: 32 separately powered or 12 bus-powered plus an interface. 4 per safety barrier in hazardous area (one fieldbus network may have many barriers). More or less devices may be possible depending on wire size and length, power consumption and barrier rating. -
Page 14: Terminator Placement
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Terminator Placement The terminator should be placed at each end of the trunk. The power supply impedance PSI302 has one of the terminators built in. In bus topology the end of the trunk is easy to see. In tree topology the end of the trunk is where the spurs branch out. -
Page 15: Redundant Power
Installation Redundant Power Automatic bumpless switchover between redundant power supplies. Only one PSI302 should have the terminator connected, or a separate power supply-end terminator is used. GEREM112.CDR Figure 1.12 - Redundant Power BT302 Terminator Intrinsically safe, equivalent unprotected capacitance. PS302 Power Supply •... -
Page 16: Cable Options
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Cable Options Type A is recommended for best possible performance. Pair Shield Twist Size Max Length Type Single 0.75 mm2 1900 m Multi 0.32 mm2 1200 m Multi 0.13 mm2 400 m Multi 1.25 mm2... -
Page 17: Figure 1.14 - Cable Entity Parameters
Installation Segment Length Trunk 240 m Spur 1 80 m Spur 2 120 m Spur 3 40 m Total 480 m Table 1.2 - Total Cable Length Example Entity Parameter Example It is good practice to make a table for each segment (barrier) listing the entity parameters for each part for easy analysis Cable Entity Parameters Pay attention to capacitance and inductance of cables. -
Page 18: Figure 1.15 - Grounding The Shield
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual NOTE Mixing Cable Types To check if a combination of cable types is within the specification the below equation may be used: L1/L1max + L2/L2max + … < 1 Where: L1 is length of cable type 1 L2 is length of cable type 2 L1max is the maximum length for cable type 1... -
Page 19: Spur Lenght
Installation Spur Length Remember that in tree like topologies the branches are actually spurs. Spur length is basically independent of cable type as long as the maximum total length is not exceeded, but depends on the number of devices connected to the spur. There should never be more than four devices per spur. -
Page 20: Interface And Bridge
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Interface and Bridge An interface is used to connect a computer to the fieldbus. There are two types: • Permanent installation • Temporary connection A bridge is used to pass data between networks. Bridge Connection Data may be passed between devices on different channels on the same PCI card, or even between different PCI cards. -
Page 21: Intrinsic Safety Connection
Installation Intrinsic Safety Connection Several SB302 may be connected to each channel such that 16 or more devices per safe area channel is possible while there are only 4 device per hazardous area segment. Intrinsic Safety Special considerations for fieldbus installations in hazardous areas. All the normal intrinsic safety limitations apply. -
Page 22: Table 1.4 - Temperature Classifications
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Area Classifications IEC & CENELEC FM & CSA Division 1: Hazardous concentrations of flammable gases Zone 0: or vapors - or combustible dusts in Explosive gas-air mixture continuously suspension - continuously, intermittently or present, or present for long periods. - Page 23 Installation Barrier Entity Parameters “o” Maximum external capacitance (Co), the permitted total capacitance on hazardous area side of barrier Maximum external inductance (Lo), the permitted total inductance on hazardous area side of barrier Maximum output voltage (Uo), the open circuit output voltage from hazardous area side of barrier Maximum output current (Io), the short circuit output current from hazardous area side of barrier...
-
Page 24: Figure 1.19 - Repeater Connection
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual GEREM119.CDR Figure 1.19 - Repeater Connection GEREM120.CDR Figure 1.20 - IF302 Connection GEREM121.CDR Figure 1.21 - FI302 Connection 1-18... -
Page 25: Attaching Devices To The Fieldbus
Installation Attaching Devices to the fieldbus Fieldbus devices may be attached to and removed from an operating fieldbus. When removing a device ensure that fieldbus wires are not short-circuited or come in contact with other wires, shield or ground. Fieldbus devices with different communication speeds cannot be mixed on the same network. -
Page 26: Intrinsic Safety Galvanic Isolator
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Intrinsic Safety Galvanic Isolator May be used instead of safety barrier. A special fieldbus isolator with repeater is required. Does not require safety earth like a barrier. Functions as a repeater allowing several hazardous areas segment to be connected to the safe area segment of a network. -
Page 27: Computer Installation
Installation GEREM124.CDR Figure 1.24 - FI302 in I. S. Installation Computer Installation PCI Internal fieldbus Interface • Four fieldbus channels • Up to eight per station • Galvanically isolated • Plugs into ISA slot • Up to four redundant cards/stations in parallel •... -
Page 28: Interface Addresing
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Interface Addressing The PCI card has a network address like all devices. No two devices on the network must have the same address. This of course applies to PCI too. GEREM126.CDR Figure 1.26 - Interface Addressing Interface Configuration... -
Page 29: Basic Troubleshooting
Installation Basic Troubleshooting Communication errors are automatically detected and indicated in operator console and engineering tools. As for all troubleshooting, removing parts one-by-one until it works finding the fault through elimination, is a useful way. It is also a good idea to test a problem device on its own on the workbench. - Page 30 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual 1-24...
-
Page 31: Operation
Section 2 Operation The Series 302 device has an optional digital LCD display that works as a local operator interface. It can be used for some basic configuration and operation. However, all configuration, operation and diagnostics may also be done remotely using for example a configurator or operator console. -
Page 32: Normal Display Operation
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual Normal Display Operation During normal operation, the Series 302 device stays in the normal display mode. In this mode, it shows a variable indicated by user configuration. (See Figure 2.1 - Typical Normal Display Showing PV, in this case 50.0 %). -
Page 33: Table 2.1 - Display Messages
Operation DISPLAY DESCRIPTION INIT The device is in initializing mode after power on. BOUT The sensor is open or not connected properly. (When it is applicable). FAIL The device presents some fail or malfunctioning FACT The device is recovering default configuration to non-volatile memory. Table 2.1 - Display Messages... - Page 34 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual...
-
Page 35: Configuration
Section 3 Configuration The way to configure the communication and function block for the Series 302 devices is using a system configuration device, commonly called Host. The heaviest and most difficult task is automated and the risk of a configuration mistake is reduced. In this system, the addressing of a device is first done using the physical device tag of that device. -
Page 36: Figure 3.2 - Transducer Display - Configuration
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual The device was instantiated as LD302 As you can see the Transducer and Display are treated as special type of Function Blocks, called Transducer Blocks. Here, you can see all blocks instantiated. -
Page 37: Local Programming Tree
Configuration The transducer display is treated as a common function block. It means, its block can be configured by SYSCON setting parameters by choosing values according to customer's needs. The LCD display can be used for monitoring or acting purpose, a parameter present on the fieldbus network or inside a function block can be shown at LCD or be acted as for example: Calibration and Tuning parameters. -
Page 38: Table 3.2 - Transducer Display Parameters
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual BLOCK TAG Tag assigned to the Function Blocks RELATIVE INDEX Relative Index of the parameter in the object dictionary SUB INDEX The logical sub-address of the member MNEMONIC Mnemonic name representing each parameter FLOAT INC_DEC Step for Incrementing or decrementing in float or integer format DECIMAL POINT... -
Page 39: Programming Using Local Adjustment
Configuration Each time when you modify the settings of Display Block you should update your settings choosing Update Display. operation configurating Display can be done On_Line or Off_line by SYSCON GEREM306.CDR Figure 3.6 - The Settings of Transducer Display parameters II parameters II Programming Using Local Adjustment The device must be fitted with the digital display for this function to be enabled. - Page 40 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual NOTE SUMMARY: Zero (z) Browses Span (s) Selects / Enters. To browse the available options for parameters, move the tool to the ZERO hole to go to the specific menu option. See Figure 3.7 - Local Adjustment Switches. Then make a selection by moving the tool to SPAN when the choice is displayed.
-
Page 41: Transducer Block
Configuration When incrementing a variable, and go beyond the value desired, move the tool to ZERO and wait until the decrement option of the same variable appears. By moving the tool to SPAN, reduce it to the desired value. For "undershoot" the opposite applies. To exit from any menu, remove the tool from any hole and for time-out that an escape sequence will return back to normal display. -
Page 42: Channel
Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual The transducer block has an algorithm, a set of contained parameters and a channel connecting it to a function block. The algorithm describes the behavior of the transducer as a data transfer function between the I/O hardware and other function block. -
Page 43: Maintenance Procedures
Maintenance Procedures General SMAR Series 302 devices are extensively tested and inspected before delivery to the end user. Nevertheless, during their design and development, consideration was given to the possibility of repairs being made by the end user, if necessary. - Page 44 Foundation Fieldbus Series 302 – Installation, Operation and Maintenance Manual...
