RGBlink mini-edge User Manual page 44

3) Connect camera and computer to the switch.
4) Connect mini-edge and camera to the switch via Ethernet cables (It is recommended to use
RGBlink CAT6 cable with order code as 940-0001-00-11-0). Then use mini-edge for PTZ control.
Warning:
1. The computer IP, mini-edge IP and the tested IP must be in the same LAN.
2. It is suggested to use ping command to check IP addresses of four cameras one by one to ensure
5)
Select HDMI 1/HDMI 2/HDMI 3/HDMI 4 to switch camera control interface.
normal communication.
3. ONLY VISCA via IP protocol is supported. Protocols including NDI PTZ/CGI/HTTP/Pelco-D/Pelco-P are
Use Toggle on the front panel to adjust zoom and focus. Automatic adjustment can be achieved
not supported.
by choosing AUTO.
